EU-27i User's manual

EU DECLARATION OF CONFORMITY

Hereby, we declare under our sole responsibility that EU-27i manufactured by TECH, head-quartered in

Wieprz Biała Droga 31, 34-122 Wieprz, is compliant with Directive 2014/35/EU of the European Parliament and of

the Council of 26 February 2014 on the harmonisation of the laws of Member States relating to the making available

on the market of electrical equipment designed for use within certain voltage limits (EU OJ L 96, of 29.03.2014, p.

357), Directive 2014/30/EU of the European Parliament and of the Council of 26 February 2014 on the

harmonisation of the laws of Member States relating to electromagnetic compatibility (EU OJ L 96 of 29.03.2014,

p.79), Directive 2009/125/EC establishing a framework for the setting of ecodesign requirements for energy-related

products as well as the regulation by the MINISTRY OF ENTREPRENEURSHIP AND TECHNOLOGY of 24 June 2019

amending the regulation concerning the essential requirements as regards the restriction of the use of certain

hazardous substances in electrical and electronic equipment, implementing provisions of Directive (EU) 2017/2102

of the European Parliament and of the Council of 15 November 2017 amending Directive 2011/65/EU on the

restriction of the use of certain hazardous substances in electrical and electronic equipment (OJ L 305, 21.11.2017,

p. 8).

For compliance assessment, harmonized standards were used:

PN-EN IEC 60730-2-9:2019-06, PN-EN 60730-1:2016-10.

Wieprz, 22.07.2021

TECH

I. Safety

Before using the device for the first time the user should read the following regulations carefully. Not

obeying the rules included in this manual may lead to personal injuries or controller damage. The

user’s manual should be stored in a safe place for further reference. In order to avoid accidents and

errors it should be ensured that every person using the device has familiarized themselves with the

principle of operation as well as security functions of the controller. If the device is to be sold or put

in a different place, make sure that the user’s manual is there with the device so that any potential

user has access to essential information about the device.

The manufacturer does not accept responsibility for any injuries or damage resulting from negligence;

therefore, users are obliged to take the necessary safety measures listed in this manual to protect

their lives and property.

WARNING

•High voltage! Make sure the regulator is disconnected from the mains before per-

forming any activities involving the power supply (plugging cables, installing the de-

vice etc.)

•The device should be installed by a qualified electrician.

•Before starting the controller, the user shoud measure earthing resistance of the

electric motors as well as the insulation resistance of the cables.

•The regulator should not be operated by children.

WARNING

•The device may be damaged if struck by a lightning. Make sure the plug is discon-

nected from the power supply during storm.

•Any use other than specified by the manufacturer is forbidden.

•Before and during the heating season, the controller should be checked for condition

of its cables. The user should also check if the controller is properly mounted and clean

it if dusty or dirty.

We are committed to protecting the environment. Manufacturing electronic

devices imposes an obligation of providing for environmentally safe disposal

of used electronic components and devices. Hence, we have been entered

into a register kept by the Inspection For Environmental Protection. The

crossed-out bin symbol on a product means that the product may not be

disposed of to household waste containers. Recycling of wastes helps to

protect the environment. The user is obliged to transfer their used

equipment to a collection point where all electric and electronic components

will be recycled.

EU-27i User's manual

II. Control panel description

III. Working rule

EU-27 regulator is intended to control the operation of CH circulation pump and the operation of

additional pump (HCW or floor pump). The task of the regulator is to switch the CH pump on, if the

temperature exceeds the threshold activation value and to switch the pump off when the boiler cools

down (as a result of extinguishing). For the second pump, apart from activation temperature, the user

adjusts the set temperature to which the pump will operate.

The regulator is equipped with a system preventing from a stoppage of CH and HCW pumps, the so-

called. anti-stop. If the pump works for a longer period (e.g.. beyond the season), then the pump is

turned on every 7 days for 1 minute. Additionally, time is saved every hour in a non - volatile EEPROM

memory, thanks to which, after possible stoppage in supply, time measurement is continued.

The controller has been also equipped with the function of protection against water freezing, the so-

called anti--freezing. After the sensor temperature of the CH HCW pump decreases below 7oC, the

pump is switched on. The pump will work until the moment when the sensor temperature reaches the

value of 9oC.

A user makes every change of parameters by means of pulse generator knob. Turning the knob

allows to mark the requested function or change its value, while pressing the knob causes entering a

given function or a confirmation of change in its value. To exit any function, use exit button.

IV. Controller functions

IV.a) Manual operation

Using this function, a user may start each active executive

device of each regulator manually, independently of the others,

and control alarm work.

CH pump

pump 2

Pulse

generator

knob (entering

MENU, selection

and approval of

settings)

Exit,

cancellation

of settings

Standby mode

(standby)

Current CH,

HCW

temperature

Manual

operation

Temp. HCW

preset

temperatur

48oC 40oC 45oC

CH HCW set.HCW

TECH

Pressing PULSE GENERATOR switches CH water pump on/off:

Pressing PULSE GENERATOR switches HTW water pump

on/off:

Pressing PULSE GENERATOR switches the alarm on/off :

IV.b) Pump type 2

This setting allows to choose (activate) the proper type of the second pump between HCW and floor

pump. If an additional pump is not connected, No pump option should be chosen.

Depending on the settings, additional functions will be available for the selected pumps and the

appropriate screen view will be visible:

•No pump (CH view)

It is possible to change the activation threshold temperature

directly from the main screen, using plus and minus buttons.

•HCW pump (CH and HCW view)

It is possible to change the preset HCW temperature directly

from the main screen, using plus and minus buttons.

•Floor pump (CH and floor view)

It is possible to change the preset floor temperature directly

from the main screen, using plus and minusbuttons.

IV.c) Working mode

If pump 2 is not selected, the regulator will run

according to CH pump settings (see chapter 3).

In the case of choosing the second pump as HCW, the following working modes will appear:

Manual operation

Pump type 2

CH pump*

HTW pump

CH pump

HTW pump*

HTW pump

Alarm test *

No pump *

HCW pump

48o C, 40o C,

CH act.threshold

HCW pump*

Floor pump

48o C, 40o C, 45o C,

CH HCW HCWpreset

HCW pump

Floor pump *

48oC 40oC 45oC

CH Floor preset.

EU-27i User's manual

•CH only

In this mode, only CH pump will work, HCW pump will not be activated.

•Simultaneous pumps

In this mode, both pumps will be active at the same time, each according to their own settings

activation.

•HCW priority

After selecting this mode, HCW pump will be activated first, and after reaching the preset temperature,

HCW pump will be deactivated then, CH circulation pump will be activated. Re-switching to HCW

pump will take place, when the reboiler temperature falls below the preset value by HCW hysteresis

value.

•Lukewarm mode

After activating this function, CH pump is deactivated and HCW pump works according to the preset

activation parameters.

In the case of selecting the second pump as floor pump, the following operating modes will

appear:

•CH only

In this mode, only CH pump will work, floor pump will not be activated.

•Simultaneous pumps

In this mode, both pumps will be active at the same time, each according to their own settings

activation.

•Only floor

After activating this function, CH pump is deactivated and floor pump works according to the preset

activation parameters.

ATTENTION

In the event when there are two circulation pumps active, pump 2 (HCW or floor) is turned off, if their

temperatures become equal. Re-activation will take place when the CH circulation temperature is

greater by at least 2°C.

IV.d) CH pump (settings)

With this function, activation parameters of CH pump should be configured:

•CH pump temperature

This is a threshold activation temperature value, after reaching it, a pump starts working. The pump

will be deactivated when the CH temperature falls below the activation temperature by CH hysteresis

value.

•CH hysteresis

CH pump will be deactivated after the decrease in circulation temperature below the activation

temperature by CH hysteresis.

IV.e) HCW pump (settings)

This setting shall be active, after choosing HCW pump (MENU> pump type 2). Using this

function, activation parameters of HCW pump should be configured:

•HCW activation temperature

This is a threshold activation temperature value, after reaching it, a pump starts working. The pump

will be deactivated when HCW temperature falls below the activation temperature by HCW hysteresis

or reaches the preset temperature.

•Preset HCW

It is a temperature value of a reboiler, after reaching it, HCW is turned off. The pump will be activated

TECH

again, when the temperature falls below the preset one by HCW hysteresis value.

•HCW hysteresis

The HCW pump will be deactivated after the decrease in the temperature in circulation below the

activation temperature by HCW hysteresis. In the event when the preset temperature is reached

and the pump is deactivated, pump re-activation will take place, when the temperature falls below the

preset one, by HCW hysteresis.

IV.f) Floor pump (settings)

this setting shall be active, after choosing the floor pump (MENU> pump type 2). Using this function,

parameters switching on the floor pump should be configured:

•Floor pump activation temperature

This is a threshold activation temperature value, after reaching it, a pump starts working. The pump

will be deactivated when floor temperature falls below the activation temperature by floor hysteresis

value or reaches the preset temperature

•Preset floor pump temperature

It is a floor pump temperature value, after reaching it, the floor pump is deactivated. The pump will

be activated again, when the temperature falls below the preset one by floor hysteresis value.

•Floor pump hysteresis (floor hysteresis)

Floor pump will be deactivated after the decrease in temperature in the circulation below the activation

temperature by floor hysteresis value. In the event when the preset temperature is reached and the

pump will be deactivated, pump re-activation will take place, when the temperature falls below the

preset one by floor hysteresis value.

IV.g) Factory settings

By activating the option factory settings, all user's own device settings are replaced the

settings saved by the manufacturer (it does not apply to servicing menu settings). From that moment,

the own controller parameters may be set once again.

V. Servicing menu

In order to enter the servicing mode settings, network switch should be switched to the item O,

then output button should be pressed and, without the interval, network switch should be switched to

the item I. After a few seconds, the regulator enters the servicing mode. In order to return to user

menu (exit servicing menu), the controller should be deactivated and activated again.

1. Alarm temperature

This function applies to securing temperature circulation. It is a critical temperature value, at

which the alert sound occurs along with the respective message on the display.

2. Alarm hysteresis

After the occurrence of an alert temperature, the possibility of switching it off takes place, after

the decrease of temperature below alarm value by alarm hysteresis value.

3.Anti-stop

This setting allows for deactivating/activating anti-stop function.

4.Anti--freezing

This setting allows for deactivating/activating anti--freezing function.

EU-27i User's manual

VI. Alarms

Each alarm controller is signaled with the sound, red "Alarm" diode lit on the panel, flashing

screen, and the appropriate message on the screen. Leaving alarm mode proceeds by pressing any

button, after the removal of the defect (or after cooling the circulation).

Below, the operated alarms are shown subsequently, according to priority:

1. No CH sensor

Text on a display:

The activation of CH pump takes place, also HCW pump is

activated, if the 2nd pump is HCW.

2. Shorted CH sensor

Text on a display:

The activation of CH pump takes place, also HCW pump is

activated, if the 2nd pump is HCW.

3. No CHW sensor

Text on a display:

The activation of CH pump takes place. Working mode switched

to "CH only". The second pump type is switched to "No pump".

4. Shorted sensor 2

Text on a display:

The activation of CH pump takes place. Working mode switched

to "CH only". The second pump type is switched to "No pump".

5. CH temperature above the alarm value

Text on a display:

The activation of CH pump takes place, and HCW pump is also

activated, if pump 2 is HCW pump.

6.Temperature 2 above the alarm value

Text on a display:

The activation of CH pump takes place, also HCW pump is

activated, if the 2nd pump is HCW.

7. Temperature 2 below 7°C

Text on a display:

The alarm is active only when anti-freezing option is activated.

The activation of CH pump takes place, and if pump 2 is HCW,

HCW pump is also activated until reaching 9°C.

!NO!

!CH sensor!

!Shorted!

!CH sensor!

!NO!

!Sensor 2!

!Shorted!

!Sensor 2!

!Temperature!

!CH sensor!

!Temperature!

!Sensor 2!

!Below 7⁰C!

!Sensor 2!

TECH

8. CH temperature below 7°C

Text on a display:

The alarm is active only when anti-freezing option is activated.

The activation of CH pump takes place, and if pump 2 is HCW,

HCW pump is also activated until reaching 9°C.

9. Test alarm

Text on a display:

VII. Fuse

The regulator is equipped with WT 3.15 A tubular cartridge fuse, protecting the network. Using a

fuse with a higher value may cause damage to the controller.

VIII. Maintenance

In EU-27i Controller, technical condition of wires should be checked before the heating season and

throughout its duration. Fastening of the controller should be also checked, it should be cleaned from

dust and other dirt. Earthing effectiveness of the engines should be also measured.

Technical Data EU-27i

Specification

Unit

Power supply

230V +/-10% / 50Hz

Power consumption

Ambient Temperature

5÷50

CH Pump max. output load

0,5

Second Pump max. output load

0,5

Measurement Accuracy

Sensor Thermal Resistance

-30÷99

Fuse Insert

3,15

for

Temperature

Adjustment Range

ON threshold

OFF threshold

hysteresis

From

Max

Fact.

30 oC

70 oC

40 oC

2 oC

CHW

20 oC

60 oC

30 oC

55 oC

60 oC

2 oC

Floor

20 oC

50 oC

30 oC

45 oC

50 oC

2 oC

ALARM

70 oC

90 oC

85 oC

5 oC

2 oC

!Below 7⁰C!

!CH sensor!

!Alarm!

EU-27i User's manual

IX. Assembly

Attention: The assembly should be done only by the person with proper qualifications! The

device in this time must not be live (you should ensure that plug is disconnected from the grid)!

ATTENTION: wrong connection of wires can cause the damage of the regulator!

IX.a) The diagram of connecting cables to the

controller.

While assembly of wiring of the controller you should pay special attention to correct connecting

ground wires.

PE - earthing (yellow and green)

N – neutral (blue)

L – phase (brown)

Inhaltsverzeichnis

Andere Tech Controllers Controller Handbücher

Tech Controllers

Tech Controllers EU-800 PID Bedienungsanleitung

Tech Controllers

Tech Controllers EU-L-7E Bedienungsanleitung

Tech Controllers

Tech Controllers STT-869 Bedienungsanleitung

Tech Controllers

Tech Controllers EU-T-4.1 Bedienungsanleitung

Tech Controllers

Tech Controllers EU-F-4z v2 Bedienungsanleitung

Tech Controllers

Tech Controllers EU-28N Bedienungsanleitung

Tech Controllers

Tech Controllers EU-20 Bedienungsanleitung

Tech Controllers

Tech Controllers EU-C-8r Bedienungsanleitung

Tech Controllers

Tech Controllers EU-R-10S PLUS Bedienungsanleitung

Tech Controllers

Tech Controllers EU-3910 SIGMA Bedienungsanleitung

Tech Controllers

Tech Controllers EU-L-12 Bedienungsanleitung

Tech Controllers

Tech Controllers EU-WiFi 8s mini Bedienungsanleitung

Tech Controllers

Tech Controllers EU-C-8f Bedienungsanleitung

Tech Controllers

Tech Controllers EU-F-2z v2 Bedienungsanleitung

Tech Controllers

Tech Controllers EU-294v1 Bedienungsanleitung

Tech Controllers

Tech Controllers EU-294 v2 Bedienungsanleitung

Tech Controllers

Tech Controllers EU-ML-12 Bedienungsanleitung

Tech Controllers

Tech Controllers EU-88 zPID Bedienungsanleitung

Tech Controllers

Tech Controllers EU-24 SIGMA Bedienungsanleitung

Tech Controllers

Tech Controllers EL480zPID Bedienungsanleitung

Tech Controllers

Tech Controllers EU-28 SIGMA Bedienungsanleitung

Tech Controllers

Tech Controllers i-2 Bedienungsanleitung

Tech Controllers

Tech Controllers EU-WIFI L Bedienungsanleitung

Tech Controllers

Tech Controllers L-7 Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
