USB-100BASE-T1 Converter User Manual

Content

1GENERAL INFORMATION .................................................................................... 3

1.1 Functionality and Features of the USB-100BASE-T1 Converter .................... 3

1.2 Warranty and Safety Information .................................................................. 4

2HARDWARE INTERFACES ................................................................................... 5

2.1 Connectors.................................................................................................... 5

2.1.1 Black MQS Connector............................................................................. 5

2.1.2 Universal Serial Bus Connector .............................................................. 6

2.2 Other Interfaces ............................................................................................ 6

2.2.1 Status LED .............................................................................................. 6

3INSTALLATION.................................................................................................... 7

3.1 Driver Installation .......................................................................................... 7

4CONFIGURATION .............................................................................................. 14

4.1 NIC settings (information)........................................................................... 16

5ADDITIONAL INFORMATION............................................................................. 20

6LIST OF FIGURES............................................................................................... 21

7CHANGELOG ..................................................................................................... 22

8CONTACT.......................................................................................................... 23

USB-100BASE-T1 Converter User Manual

1GENERAL INFORMATION

1.1 Functionality and Features of the USB-100BASE-T1

Converter

Figure 1-1: USB-100BASE-T1 Converter

The Technica Engineering USB-100BASE-T1 Converter transmits data frames from

the physical layer BroadR-Reach (100BASE-T1) to USB 2.0-LAN.

Features:

•1 port 100BASE-T1 with Broadcom BroadR-Reach Technology

•1 port USB 2.0 mini B

•1 Status LED

USB-100BASE-T1 Converter User Manual

General Information:

Power requirement:

Power consumption:

2,5 Watt

LINKS:

The User can download the latest firmware and documentation for the USB-100BASE-

T1 Converter here:

https://technica-engineering.de/en/produkt/usb-100base-t1-converter/

1.2 Warranty and Safety Information

Before operating the device, read this manual thoroughly and retain

it for your reference.

The latest documentation for the USB-100BASE-T1 Converter here:

https://technica-engineering.de/en/produkt/usb-100base-t1-

converter/

Use the device only as described in this manual.

Use only in dry conditions.

Do not apply power to a damaged device.

Do not open the device. Otherwise warranty will be lost.

This device is designed for engineering purpose only.

Special care has to be taken for operation.

Do not use this device in a series production car.

As this device is likely to be used under rough conditions, warranty

is limited to 1 year.

Manufacturer liability for damage caused by using the device is

excluded.

USB-100BASE-T1 Converter User Manual

2HARDWARE INTERFACES

2.1 Connectors

On the label on top of the device you can see an overview about all HW-Interfaces of

the USB-100BASE-T1 Converter.

2.1.1 Black MQS Connector

The pinning of the ECU connectors is listed on the label on top of the device as well.

(See FIGURE 2-1)

The Connector color is black.

Figure 2-1: Label of USB-100BASE-T1 Converter with pinning information

USB-100BASE-T1 Converter User Manual

The Tyco Electronics (TE) Micro Quad Lock System (MQS) is used.

Name


Part Number

Tyco, MQS Buchsengehäuse 3 Pol

4-1718346-1

Tyco crimp contact

928999-1

Table 2-1: Parts of black MQS connector

Note: You can use the official Tyco tool for these crimp contacts. A cheap variant is

the crimp tool for “PSK” contacts.

Function

n.c.

100BASE-T1 port, positive

100BASE-T1 port, negative

Table 2-2: Pinning of black MQS connector

2.1.2 Universal Serial Bus Connector

There is one USB 2.0 mini B Port for connection to a laptop or PC. Since the chip used

is a USB-LAN chip, your PC will identify a new Ethernet Network Interface Card.

2.2 Other Interfaces

2.2.1 Status LED

The USB-100BASE-T1 Converter has one status LED at the frontside of the case for

the 100BASE-T1 Port.

It is lit when there is linkup. It is toggling when there is communication.

Note: There is a bug in the used BroadR-Reach PHY. When the BR Plus and Minus

lines are swapped, and the 100BASE-T1 port is set to Slave then the Link LED is lit,

but there is no data transmission possible. So please ensure that the 100BASE-T1

lines (positive/positive and negative/negative) are connected correctly.

USB-100BASE-T1 Converter User Manual

3INSTALLATION

3.1 Driver Installation

A driver is available for following operating Systems (version 1.4):

•Linux x64

•Windows x32

•Windows x64

Download-link

https://technica-engineering.de/en/produkt/usb-100base-t1-converter/

For Windows, please follow the described steps for installation:

1) Connect your USB-100BASE-T1 Converter device to your computer

2) browse your driver installation data folder and double click on the setup called

“USB-BR_1.4”

Figure 3-1: Driver Installation Data Folder

Accept the prompt to install the application.

3) Follow through the Wizard menus as shown below:

USB-100BASE-T1 Converter User Manual

Figure 3-2: Driver Installation Start Up screen

USB-100BASE-T1 Converter User Manual

Figure 3-3: Driver Installation Terms and Conditions

USB-100BASE-T1 Converter User Manual

Figure 3-4: Driver Installation
