Technisonic Industries Limited TMS-110 Bedienungsanleitung

TMS-110

VHF AM TRANSCEIVER

Installation and Operating

Instructions

TiL Document No. 15RE532

Rev. D

November 2018

Technisonic Industries Limited

240 Traders Boulevard, Mississauga, Ontario L4Z 1W7

Tel: (905) 890-2113 Fax: (905) 890-5338

www.til.ca

TECHNISONIC INDUSTRIES LIMITED

TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D

This page is intentionally left blank.

TECHNISONIC INDUSTRIES LIMITED

TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D

iii

REVISION HISTORY

[ 15RE532 ]

REV SECTION

- PAGE - DESCRIPTION DATE EDITED

N/C

All

Original Document Release.

Updated to final installation and operation for

production release.

8 Jan 2016

24 May 2018

B All Updated for IC and FCC conformance. 22 June 2018 SM

C All Changed maximum power to 10 watts 24 Sept 2018 SM

D 1, 20 Added -1 and -2 part number information. 14 Nov 2018 SM

TECHNISONIC INDUSTRIES LIMITED

TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D

This page is intentionally left blank.

TECHNISONIC INDUSTRIES LIMITED

TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D

ESD CAUTION

This unit contains static sensitive devices. Wear a grounded wrist strap and/or conductive gloves

when handling printed circuit boards.

FCC COMPLIANCE INFORMATION

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference and (2) this device must accept any interference

received, including interference that may cause undesired operation.

WARNING: For compliance with FCC RF Exposure Requirements the mobile transmitter

antenna installation shall comply with the following two conditions:

1. The transmitter antenna gain shall not exceed 3 dBi.

2. The transmitter antenna is required to be located outside of a vehicle and kept at a separation distance of

115 cm or more between the transmitter antenna of this device and persons during operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

—Consult the dealer or an experienced radio/TV technician for help.

WARNING AND DISCLAIMER

Changes or modifications not expressly approved by Technisonic Industries could void the user’s

authority to operate the equipment.

This manual is designed to provide information about the TDAM-1000. Every effort has been made to

make this manual as complete and accurate as possible.

WARRANTY INFORMATION

The Model TMS-110 is under warranty for one year from date of purchase. Failed units caused by

defective parts or workmanship should be returned to:

Technisonic Industries Limited

240 Traders Boulevard

Mississauga, Ontario L4Z 1W7

Tel: (905) 890-2113

Fax: (905) 890-5338

NOTES

TECHNISONIC INDUSTRIES LIMITED

TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D

SECTION

TITLE

PAGE

1 GENERAL DESCRIPTION B

1.1 INTRODUCTION ............................................................................................................... 1

1.2 DESCRIPTION .................................................................................................................. 1

1.3 SYSTEM COMPONENTS ................................................................................................. 1

2 INSTALLATION INSTRUCTIONS B

2.1 GENERAL ......................................................................................................................... 3

2.2 EQUIPMENT PACKING LOG ........................................................................................... 3

2.3 TDAM-1000 INSTALLATION ............................................................................................ 3

2.4 INSTALLATION CONNECTIONS ..................................................................................... 5

2.5 INSTALLATION - WIRING INSTRUCTIONS .................................................................... 6

2.6 INSTALLATION - ANTENNA ............................................................................................ 7

2.7 INSTALLATION - BRACKET ............................................................................................ 10

2.8 INSTALLATION - MICROPHONE ..................................................................................... 10

2.9 INSTALLATION - WIRING INSTRUCTIONS .................................................................... 11

3 OPERATING INSTRUCTIONS B

3.1 GENERAL ......................................................................................................................... 12

3.2 FEATURES ....................................................................................................................... 12

3.3 FRONT PANEL ................................................................................................................. 12

3.4 NORMAL OPERATION ..................................................................................................... 13

3.5 FUNCTION MENU ............................................................................................................ 15

3.6 CONFIGURATION MENU ................................................................................................. 16

3.7 25 AND 8.33 kHz CHANNEL SPACING ........................................................................... 17

4 SPECIFICATIONS B

4.0 DIMENSIONS .................................................................................................................... 18

4.1 GENERAL SPECIFICATIONS .......................................................................................... 18

4.2 RECEIVER SPECIFICATIONS ......................................................................................... 19

4.3 TRANSMITTER SPECIFICATIONS .................................................................................. 20

WARRANTY ...................................................................................................................... 21

FIGURE

TITLE

PAGE

1 Outline Drawing for Model TDAM-1000 ............................................................................ 4

2 Wiring Connections and Notes for the TDAM-1000 .......................................................... 5

3 TDAM-1000 Front Panel Controls ..................................................................................... 12

TABLE OF CONTENTS

LIST OF FIGURES

TECHNISONIC INDUSTRIES LIMITED

TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D

vii

TABLE

TITLE

PAGE

1 Power Connections (2 Pin D-Connections – J1) ............................................................... 5

2 Accessory Connections (26 Pin HDD-Connections – J7) ................................................. 5

3 Configuration Menu Commands ....................................................................................... 16

4 ICAO 25 kHz and 8.33 kHz Channel Spacing .................................................................. 17

LIST OF TABLES

TECHNISONIC INDUSTRIES LIMITED

TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D

1.1 INTRODUCTION

This publication provides information on the installation and operation of the TMS-110

Transceiver System.

1.2 DESCRIPTION

The TMS-110 (TiL system number 180001) includes the TDAM-1000 VHF AM mobile transceiver

(Product Marketing Name (PMN) TDAM-1000) operates in the aeronautical VHF AM band and is

designed for ground vehicle installation.

1.3 SYSTEM COMPONENTS

The following components make up the system:

Component Part Number

TDAM-1000 VHF AM Transceiver

151286-1

Microphone Assembly

181298-1

Mounting Bracket

169676

Mobile Antenna Assembly

181299-1

Power Cord

183043-1

Installation Kit

189729

SECTION 1: GENERAL DESCRIPTION

TECHNISONIC INDUSTRIES LIMITED

TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D

This page is intentionally left blank.

TECHNISONIC INDUSTRIES LIMITED

TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D

2.1 GENERAL

This section contains information and instructions for the correct installation of the TMS-110 VHF

AM mobile transceiver system.

2.2 EQUIPMENT PACKING LOG

Unpack the equipment and check for any damage that may have occurred during transit. Save

the original shipping container for returns due to damage or warranty claims. Check that each

item on the packing slip has been shipped in the container.

2.3 INSTALLATION

The TDAM-1000 is designed to be used in land mobile applications. A mounting bracket, hand

microphone, power cable and antenna are supplied. The TDAM-1000 will operate on both

standard 13.8 VDC or 28 VDC special purpose or military vehicle power without modification. The

built in speaker is sufficient for most installations however a 10 watt external speaker output is

supplied for high noise environments.

SECTION 2: INSTALLATION INSTRUCTIONS
