TechnoKom AutoGRAPH STEALTH Bedienungsanleitung
2.
2
VERSION
© TechnoKom
2015
AutoGRAPH-ST •USER MANUAL
2
TechnoKom © 2015
AutoGRAPH-ST •USER MANUAL
TechnoKom © 2015
3
Table of contents
Introduction................................................................................................................................................................4
Basic information ............................................................................................................................................. 4
Scope of Supply....................................................................................................................................................6
Technical Specication....................................................................................................................................7
ComponentsofAutoGRAPH-ST...............................................................................................................9
Getting Started.....................................................................................................................................................11
Installation of a SIM card....................................................................................................................... 11
Inserting the battery....................................................................................................................................12
Settings..................................................................................................................................................................13
Device Functions...............................................................................................................................................15
«Test» button....................................................................................................................................................15
Coordinate acquisition..............................................................................................................................16
Recording the data......................................................................................................................................16
Data transmission .......................................................................................................................................16
Motion detection............................................................................................................................................17
Additional functions.....................................................................................................................................17
Real-time tracking........................................................................................................................................18
Proles........................................................................................................................................................................19
Device Indicators..............................................................................................................................................22
Drivers Installation...........................................................................................................................................23
Connection to PC.............................................................................................................................................24
AutoGRAPH-STMessages.......................................................................................................................25
Recommendations on proper operation........................................................................................28
AutoGRAPH-ST •USER MANUAL
4
TechnoKom © 2015
Introduction
This User Manual applies to the AutoGRAPH-ST autonomous anti-thief device
(hereafter - device, AutoGRAPH-ST) produced by TechnoKom Ltd. It contains
installation and connection procedures of this device, as well as its function
and control. This Manual constitutes the Operating Rules to be observed to
ensure successful operation of the controller and its compliance with TU 6811-
004-12606363-2013 and warranty provisions.
All information on functions, functional capabilities and other specications related to
AutoGRAPH-ST tracking devices as well as all information contained in this User Manual is based
on current data (at time of writing) and is deemed to be valid as of the date of publication.
TechnoKom reserves the right to modify the information or specications without prior notice
or commitment.
IMPORTANT
Basic information
• AutoGRAPH-ST is an autonomous anti-thief device intended for acquisition
of the exact coordinates of assets and delivery of the coordinates to the
customer by SMS, Email and GPRS.
• The customer can track asset in real-time using the AutoGRAPH-Web
application.
• The compact form factor makes the device easy to install and difcult to
detect.
• The autonomous power supply is enough to send 1200 messages. Under
normal usage the battery life time is up to 2 years.
• Operation of the device is organized in such way that the device is in
Standby mode most of time. The AutoGRAPH-ST switches to Operation
mode for acquisition of asset coordinates and delivery to the customer.
The device will then switch to Standby mode until next period of Operation
mode. First of all such behaviour extends battery life time. Secondly, it makes
detection by GSM/GPS scanners more difcult by limiting operational time.
AutoGRAPH-ST •USER MANUAL
TechnoKom © 2015
5
• All operation parameters of AutoGRAPH-ST are congurable, so the
device can be customized for a great number of applications. Standard
proles provide quick setup of the device for most common applications by
sending a short command to device.
• Remote setting allows the customer to control the device by sending
settings in an SMS from anywhere without device removal and connection
to a PC.
• In addition to location, the AutoGRAPH-ST sends information on current
battery voltage, SIM balance, ambient temperature and asset speed to the
customer.
• A built-in accelerometer detects start of motion, overturning, vibrations and
other forces on the device which could be an attempt at wilful damage of the
asset. The AutoGRAPH-ST can be customized to send a notication to the
customer if the device detects acceleration above a preset threshold.
AutoGRAPH-ST •USER MANUAL
6
TechnoKom © 2015
Scope of Supply
№Description Qty
1«AutoGRAPH-ST» 1 pc.
2Battery Set (Li-SOCI2)* 1 pc.
3Password Card 1 pc.
4User Sheet 1 pc.
5Warranty Certicate 1 pc.
12
* installed in device.
AutoGRAPH-ST •USER MANUAL
TechnoKom © 2015
7
Technical Specification
Description Value
GNSS chipset Mediatek MT3333
Supported GNSS GPS+GLONASS /
GALILEO / Beidou
Accuracy, when using GPS/GLONASS GNSS*:
• position, m
• velocity, m/s
• time (typ), µs
3.0
0.02
1
Type of GPS/GLONASS antenna Internal
Position accuracy when using LBS**:
• in city
• in the countryside
200...1000 m
1...30 km
Communication GSM / GPRS / SMS /
SMTP (Email)
SIM holders 1
Type of GSM antenna Internal
Connection to PC USB 2.0
Internal FLASH memory, records > 270.000
Built-in accelerometer Optional
Power consumption in Standby mode, µA 15
Battery type Li /SOCI2
Rated battery voltage, V 7.2
Battery capacitance, mА/h 1700
AutoGRAPH-ST •USER MANUAL
8
TechnoKom © 2015
Description Value
Battery life up to 2 years / approx.
1200 messages***
Time to rst position x (typ.), s 23*
Operating temperature, °С от - 40 до + 85
Dimensions, mm 74 х 48 х 21
Weight (with battery), g 80
* With nominal signal levels - 130 dBm.
** A wide specied range is supplied as the position accuracy when using LBS depends on base stations location around asset.
*** Battery capacity is enough to send 1200 messages with coordinates (Email, SMS and data to server). Under normal use battery
life time amounts up to 2 years.
AutoGRAPH-ST •USER MANUAL
TechnoKom © 2015
9
Components of AutoGRAPH-ST
The small form factor of the device makes it easy to install and prevents easy
discovery.
Battery placement
(projected part)
GPS/GLONASS
antenna placement
Fastening screws
(4 pc.)
Manufacturer’s label
(with device’s serial number)
Front view
Back view
AutoGRAPH-ST •USER MANUAL
10
TechnoKom © 2015
Internal view
Operation Mode LED
(red)
GPS/GLONASS LED
(green)
Power connector
Battery
GSM LED
(blue)
GPS / GLONASS
antenna
«Test» button
For more information see the
«Device Functions» section
SIM card holder
Insert SIM matching the key
displayed under the holder
Unscrew four fastening screws and remove the back cover of the device.
Remove device PCB from the case. The following components are on the
rear:
Micro USB
connector
Detailed information on LEDs’indication is given in the «AutoGRAPH-ST Indication» section of the User Manual.
