TechVision PVS5P1W2-I/A Bedienungsanleitung
5MP IP Vandal Dome W/ Audio
PVS5P1W2-I/A
Notes on Safety
This product is intended to be supplied by a Listed Power Unit, marked with 'Limited
Power Source', 'LPS' on unit, output rated minimum 12V/2 A or POE 48V/
350mA(depending on models), no more than 2000m altitude of operation and Tma=60
Deg.C.
As for the modes with PoE function, the function of the ITE being investigated to IEC
60950-1 standard is considered not likely to require connection to an Ethernet network
with outside plant routing, including campus environment and the ITE is to be
connected only to PoE networks without routing to the outside plant.
Do not attempt to disassemble the camera; in order to prevent electric shock, do not
remove screws or covers.
There are no user-serviceable parts inside. Please contact the nearest service center as
soon as possible if there is any failure.
Avoid from incorrect operation, shock vibration, heavy pressing which can cause damage
to product.
Do not use corrosive detergent to clean main body of the camera. If necessary, please use
soft dry cloth to wipe dirt; for hard contamination, use neutral detergent. Any cleanser for
high grade furniture is applicable.
Avoid aiming the camera directly towards extremely bright objects, such as, sun, as this
may damage the image sensor.
Please follow the instructions to install the camera. Do not reverse the camera, or the
reversing image will be received.
Do not operate it in case temperature, humidity and power supply are beyond the limited
stipulations.
Keep away from heat sources such as radiators, heat registers, stove, etc.
Do not expose the product to the direct airflow from an air conditioner.
This manual is for using and managing the product. We may reserve the rights of
amending the typographical errors, inconsistencies with the latest version, software
upgrades and product improvements, interpretation and modification. These changes will
be published in the latest version without special notification.
All pictures, charts, images in this manual are only for description and explanation of our
products. The ownerships of trademarks, logos and other intellectual properties related to
Microsoft, Apple and Google belong to the above-mentioned companies.
This manual is suitable for IR water-proof network cameras.
Disclaimer & Regulatory Information
Disclaimer
With regard to the product with internet access, the use of product shall be wholly at
your own risks. Our company shall be irresponsible for abnormal operation, privacy
leakage or other damages resulting from cyber attack, hacker attack, virus inspection, or
other internet security risks; however, Our company will provide timely technical support
if necessary.
Surveillance laws vary from country to country. Check all laws in your local region
before using this product for surveillance purposes. We shall not take the responsibility
for any consequences resulting from illegal operations.
FCC Marking
The products have be tested and found in compliance with the council FCC rules
and regulations part 15 subpart B. Operation of this product is subject the following two
conditions: (1) this device may not cause harmful interface, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
CE Marking
The products have been manufactured to comply with the following directives.
EMC Directive 2014/30/EU
RoHS Marking
The products have designed and manufactured in accordance with Directive EU RoHS
Directive 2011/65/EU and its amendment Directive EU 2015/863 on the restriction of the
use of certain hazardous substances in electrical and electronic equipment.
Table of Contents
1Introduction ...................................................................................................................1
2Network Configuration .................................................................................................2
2.1 LAN...................................................................................................................2
2.1.1 Access through IP-Tool ............................................................................2
2.1.2 Directly Access through IE.......................................................................4
2.2 WAN..................................................................................................................5
3Live View........................................................................................................................9
4Network Camera Configuration.................................................................................11
4.1 System Configuration ......................................................................................11
4.1.1 Basic Information ...................................................................................11
4.1.2 Date and Time ........................................................................................11
4.1.3 Local Config...........................................................................................12
4.2 Image Configuration........................................................................................12
4.2.1 Display Configuration ............................................................................12
4.2.2 Video Configuration...............................................................................14
4.2.3 OSD Configuration.................................................................................16
4.2.4 Video Mask ............................................................................................16
4.2.5 ROI Configuration..................................................................................17
4.2.6 Lens Control...........................................................................................18
4.3 Alarm Configuration........................................................................................18
4.3.1 Motion Detection....................................................................................18
4.3.2 Alarm Server ..........................................................................................20
4.4 Event Configuration (Optional) .......................................................................21
4.4.1 Object Removal......................................................................................21
4.4.2 Exception................................................................................................22
4.4.3 Line Crossing..........................................................................................23
4.4.4 Intrusion..................................................................................................25
4.5 Network Configuration....................................................................................26
4.5.1 TCP/IP....................................................................................................26
4.5.2 Port .........................................................................................................28
4.5.3 Server Configuration ..............................................................................28
4.5.4 DDNS.....................................................................................................28
4.5.5 802.1x.....................................................................................................30
4.5.6 RTSP.......................................................................................................31
4.5.7 UPNP......................................................................................................32
4.5.8 Email ......................................................................................................32
4.5.9 FTP.........................................................................................................33
4.5.10 HTTPS………………… ........................................................................33
4.5.11 P2P (Optional)........................................................................................35
4.5.12 QoS.........................................................................................................35
Network Camera User Manual
4.6 Security Configuration.....................................................................................35
4.6.1 User Configuration .................................................................................35
4.6.2 Online User.............................................................................................37
4.6.3 Block and Allow Lists ............................................................................37
4.6.4 Security Management.............................................................................37
4.7 Maintenance Configuration..............................................................................38
4.7.1 Backup and Restore................................................................................38
4.7.2 Reboot ....................................................................................................39
4.7.3 Upgrade ..................................................................................................39
4.7.4 Operation Log.........................................................................................39
5Search ...........................................................................................................................40
5.1 Image Search ...................................................................................................40
5.2 Video Search....................................................................................................41
Appendix................................................................................................................................43
Appendix 1 Q & A.................................................................................................................43
Appendix 2 Specifications ....................................................................................................45
1
Network Camera User Manual
1Introduction
This IP-CAMERA (short for IP-CAM) is designed for high performance CCTV solutions. It
adopts state of the art video processing chips, integrated with the most advanced technologies
(like video encoding and decoding technology) to make the image transmission more stable
and smooth. Moreover, the built-in WEB server of this series improves the performance of the
traditional surveillance system so that users can be easy to operate and monitor.
This product is widely used in banks, telecommunication systems, electricity power
departments, law systems, factories, storehouses, uptowns, etc. In addition, it is also an ideal
choice for surveillance sites with middle or high risks.
Main Features
ICR auto switch, true day/night
3D DNR, digital WDR
ROI coding
Support BLC, Defog, Anti-flicker
Support smart phone, iPad, remote monitoring
Surveillance Application
2
Network Camera User Manual
2Network Configuration
Connect IP-Cam via LAN or WAN. Here only take IE browser for example. The details are as
follows:
2.1 LAN
In LAN, there are two ways to access IP-Cam: 1. access through IP-Tool; 2. directly access
through IE browser.
2.1.1 Access through IP-Tool
Network connection:
①Make sure the PC and IP-Cam are connected to the local network and the IP-Tool is installed
in the PC from the CD.
②Double click the IP-Tool icon on the desktop to run this software as shown below:
③Modify the IP address. The default IP address of this camera is 192.168.226.201. Click the
information of the camera listed in the above table to show the network information on the right
hand. Modify the IP address and gateway of the camera and make sure its network address is in
the same local network segment as the computer’s. Please modify the IP address of your device
according to the practical situation.
3
Network Camera User Manual
For example, the IP address of your computer is 192.168.1.4. So the IP address of the camera
shall be changed to 192.168.1.X. After modification, please enter the password of the
administrator and click the “Modify” button to modify the setting.
④Double click the IP address and then the system will pop up the IE browser to connect
IP-CAM. Follow directions to download, install and run the Active X control.
Enter the username and password in the login window to log in.
The default password of the administrator is “123456”.
The default username is “admin”; the default password is “123456”.
4
Network Camera User Manual
The system will pop up the above-mentioned textbox to ask you to change the default password.
It is strongly recommended to change the default password for account security. If “Do not
show again”is checked, the textbox will not appear next time.
2.1.2 DirectlyAccess through IE
The default network settings are as shown below:
IP address: 192.168.226.201
Subnet Mask: 255.255.255.0
Gateway: 192.168.226.1
HTTP: 80
Data port: 9008
Use the above default settings when logging in the camera for the first time. Directly connect
the camera to the computer through network cable.
①Manually set the IP address of the PC and the network segment should be as the same as
the default settings of the IP camera. Open the network and share center. Click “Local Area
Connection” to pop up the following window.
5
Network Camera User Manual
Select “Properties” and then select internet protocol according to the actual situation (for
example: IPv4). Next, click the “Properties” button to set the network of the PC.
②Open the IE browser and enter the default address of IP-CAM and confirm.
③Follow directions to download and install the Active X control.
④Enter the default username and password in the login window and then enter to view.
2.2 WAN
Access through the router or virtual server
