Basic documentation for CP-1014 module
1. DESCRIPTION AND PARAMETERS
The CP-1014 module is a part of an assortment of Tecomat Foxtrot series modular program-
mable controller basic modules. It differs from other basic modules by the number and type of
inputs and outputs and indication or operation elements.
The CP-1014 basic module is equipped with 8 digital inputs 24 V, four of which can be used
as analog inputs with a range 0÷10 V and four as a special function inputs (fast counter, incre-
mental encoder connection etc.). Then, the module is equipped with 6 relay outputs. The basic
operation and displaying elements are enlarged about LCD 4×20 characters and 6 user push
buttons.
The CP-1014 module contains a central unit (CPU) of series K designed for applications
where a higher power is required. It contains backed-up CMOS RAM memory for user program,
data and tables, user registers and DataBox, Flash memory for user program back-up, a slot for
MMC/SD/SDHC memory card, RTC, Ethernet interface, two serial channels (one with a fixed
RS-232 interface and the second with a position for optional submodules), one communication
channel with CIB interface for the connection of external peripheries and a system TCL2 inter-
face designed for the connection of expansion modules which increase system I/O number.
1.1 BASIC PARAMETERS
Product standard ČSN EN 61131-2:2005 (idt IEC 61131-2:2003)
Type of equipment Built-in
Protection class of electrical ob ect
ČSN EN 61140:2003 (idt IEC 61140:2001) II
Coverage
ČSN EN 60529:1993 (idt IEC 529:1989) IP20
Power supply (SELV) 24 VDC, +25 %, - 15 %
Module power input max. 8 W
Connection screw terminals, max. 2.5 mm2 conductor per ter-
minal, RJ-45 (ETHERNET TP)
Weight
Dimensions 90 × 105 × 58 mm
1.2 OPERATIONA CONDITIONS
Class of ambient influence -
ČSN 33 2000-3:1995 (mod IEC 364-3:1993) normal
Operating temperature range –20 °C to +55 °C
Permissible temperatures during transport –25 °C to +70 °C
Relative humidity 10 % to 95 % without condensation
Atmospheric pressure min. 70 kPa (< 3000 m over the sea level)
Degree of pollution -
ČSN EN 60664-1:2004 (mod IEC 60664-1:1992) 1
Overvoltage category of installation -
ČSN EN 60664-1:2004 (mod IEC 60664-1:1992) II
Working position vertical
Type of operation continuous
Electromagnetic compatibility /Emissions
ČSN EN 55011 ed. 2:2007 (mod CISPR11:)
Group 1, class A
Electromagnetic compatibility/Immunity min. according to requirements
ČSN EN 61131-2:2008
Sinusoidal vibration resistance ** 10 Hz to 57 Hz, amplitude 0.075 mm,
