Tektronix MTS400 Series Bedienungsanleitung

MTS4UP Upgrades

MTS400 Series and MTS400P MPEG Test Systems

ZZZ

Instructions

*P075097902*

075-0979-02

MTS4UP Upgrades

MTS400 Series and MTS400P MPEG Test Systems

ZZZ

Instructions

Warning

The servicing instructions are for use by qualiﬁed personnel

only. To avoid personal injury, do not perform any servicing

unless you are qualiﬁed to do so. Refer to all safety summaries

prior to performing service.

www.tektronix.com

075-0979-02

or suppliers, and are protected by national copyright laws and international treaty provisions.

Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication

supersedes that in all previously published material. Speciﬁcations and price change privileges reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

Contacting Tektronix

Tektronix, Inc.

14150 SW Karl Braun Drive

P.O. Box 500

Beaverton, OR 97077

USA

For product information, sales, service, and technical support:

In North America, call 1-800-833-9200.

Worldwide, visit www.tektronix.com to ﬁnd contacts in your area.

Table of Contents

General Safety Summary .......................................................................................... ii

Service Safety Summary.......................................................................................... iv

Kit Description...................................................................................................... 1

Upgrade Kits Covered by These Instructions............................................................... 1

Minimum Tool and Equipment List ......................................................................... 3

Kit Parts Lists .................................................................................................. 4

Upgrade Instructions Overview................................................................................... 8

Option UPG Software Upgrade................................................................................... 9

Software Option Upgrade......................................................................................... 14

Hardware Upgrade (MTS400, MTS415, and MTS430)....................................................... 16

Access the Module Bay ...................................................................................... 16

MTS4UP IPTVD Upgrade................................................................................... 18

MTS4UP GBE Upgrade ..................................................................................... 21

MTS4UP CF, EP, QB2, or VS Upgrade.................................................................... 22

Replace the Cabinet .......................................................................................... 24

Restore the Operating System............................................................................... 24

Software Upgrade............................................................................................. 31

Software Key Upgrade....................................................................................... 37

Hardware Upgrade (MTS400P).................................................................................. 38

Software Upgrade............................................................................................. 38

Access the Module Bay ...................................................................................... 43

MTS4UP IPTVP Upgrade ................................................................................... 47

SFP Module Upgrade (Option LX, Option SX, or Option ZX) .............................................. 53

MTS4UP Upgrades Instructions i

General Safety Summary

General SafetySummary

Review the following safety precautions to avoid injury and prevent damage to

this product or any products connected to it.

To avoid potential hazards, use this product only as speciﬁed.

Only qualiﬁed personnel should perform service procedures.

To Avoid Fire or Personal

Injury

Use proper power cord. Use only the power cord speciﬁed for this product and

certiﬁed for the country of use.

Ground theproduct. This product is grounded through the grounding conductor

of the power cord. To avoid electric shock, the grounding conductor must be

connected to earth ground. Before making connections to the input or output

terminals of the product, ensure that the product is properly grounded.

Observe all terminal ratings. To avoid ﬁre or shock hazard, observe all ratings

and markings on the product. Consult the product manual for further ratings

information before making connections to the product.

Power disconnect. The power cord disconnects the product from the power source.

Donotblockthepowercord;itmustremain accessible to the user at all times.

Do not operate without covers. Do not operate this product with covers or panels

removed.

Do not operate with suspected failures. If you suspect that there is damage to this

product, have it inspected by qualiﬁed service personnel.

Avoid exposed circuitry. Do not touch exposed connections and components when

power is present.

Use proper fuse. Use only the fuse type and rating speciﬁed for this product.

Do not operate in wet/damp conditions.

Do not operate in an explosive atmosphere.

Keep product surfaces clean and dry.

Provide proper ventilation. Refer to the manual's installation instructions for details

on installing the product so it has proper ventilation.

ii MTS4UP Upgrades Instructions

General Safety Summary

TermsinThisManual These terms may appear in this manual:

WARNING. Warning statements identify conditions or practices that could result

in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in

damage to this product or other property.

Symbols and Terms on the

Product

These terms may appear on the product:

DANGER indicates an injury hazard immediately accessible as you read

the marking.

WARN IN G indicates an injury hazard not immediately accessible as you

read the marking.

CAUTION indicates a hazard to property including the product.

The following symbol(s) may appear on the product:

MTS4UP Upgrades Instructions iii

Service Safety Summary

Only qualiﬁed personnel should perform service procedures. Read this Service

Safety Summary and the General Safety Summary before performing any service

procedures.

Do Not Service Alone. Do not perform internal service or adjustments of this

product unless another person capable of rendering ﬁrst aid and resuscitation is

present.

Disconnect Power. To avoid electric shock, switch off the instrument power, then

disconnect the power cord from the mains power.

Use Care When Servicing With Power On. Dangerous voltages or currents may

exist in this product. Disconnect power, remove battery (if applicable), and

disconnect test leads before removing protective panels, soldering, or replacing

components.

To avoid electric shock, do not touch exposed connections.

iv MTS4UP Upgrades Instructions

Kit Description

This document provides instructions for performing hardware and/or software and

option key upgrades on the following Tektronix products:

MTS400 Series MPEG Test Systems (MTS400, MTS415, and MTS430)

MTS4SA MPEG Test System

MTS400P MPEGTestSystem

Upgrade Kits Covered by These Instructions

MTS4UP UPG -This kit provides a software upgrade for your MTS4xx

systems. This upgrade is included with all of the hardware updates, or may

be ordered separately.

As the user of an MTS400 Series MPEG Test System, you will be familiar with

the software key (or dongle) that must be attached to your unit before you can

open any of the MTS400 Series applications. Two styles of software key are

available, each performs the same function: parallel port or USB (MTS4SA only).

The option key string supplied with this upgrade kit is generated using the serial

number of the software key and the list of options to be licensed.

NOTE. Only the software applications already installed on your MPEG test

system will be available after the upgrade. If additional applications are required,

contact your Tektronix representative.

MTS4UP IPTVD - This kit adds an IPTV Gigabit Ethernet interface with a

10/100/1000Base-T electrical port to your MTS400, MTS415, or MTS430

instrument. When you install the IPTV interface card you must remove any

other installed optional interface cards (options GBE, CF, EP, QB2, or VS).

There are three optical length input options available for option IPTVD:

MTS4UP LX - Adds a 1000Base-LX wavelength optical port with LC

connector (single mode 1310 nm).

MTS4UP SX - Adds a 1000Base-SX short wavelength optical port with

LC connector (multimode 850 nm).

MTS4UP ZX - Adds a 1000Base-ZX wavelength optical port with LC

connector (multimode 1550 nm).

MTS4UP Upgrades Instructions 1

Kit Description

MTS4UP GBE - This kit adds a Gigabit Ethernet interface and IP Analysis

software to your MTS400, MTS415, or MTS430 instrument (SFP required).

This kit may be combined with any of the following hardware upgrade kits.

There are also four optical length input options available with option GbE:

MTS4UP LX - Adds a 1000Base-LX wavelength optical port with LC

connector (single mode 1310 nm).

MTS4UP SX - Adds a 1000Base-SX short wavelength optical port with

LC connector (multimode 850 nm).

MTS4UP ZX - Adds a 1000Base-ZX wavelength optical port with LC

connector (multimode 1550 nm).

MTS4UP CU - adds a 1000Base-T electrical port with RJ45 connector.

MTS4UP CF - This kit adds a COFDM DVB-T interface to your MTS400,

MTS415, or MTS430 instrument. This kit may only be combined with the

MTS4UP GBE kit.

MTS4UP EP - This kit adds a QPSK/8PSK interface to your MTS400 Series

instrument. This kit may only be combined with the MTS4UP GBE kit.

MTS4UPQB2-This kit adds a QAM B interface to your MTS400 Series

instrument. This kit may only be combined with the MTS4UP GBE kit.

MTS4UP VS - This kit adds an 8VSB interface to your MTS400 Series

instrument. This kit may only be combined with the MTS4UP GBE kit.

MTS4UP IPTVP - This kit adds an IPTV Gigabit Ethernet interface with a

10/100/1000Base-T electrical port to your MTS400P.

There are three optical length input options available for option IPTVP:

MTS4UP LX - Adds a 1000Base-LX wavelength optical port with LC

connector (single mode 1310 nm).

MTS4UP SX - Adds a 1000Base-SX short wavelength optical port with

LC connector (multimode 850 nm).

MTS4UP ZX - Adds a 1000Base-ZX wavelength optical port with LC

connector (multimode 1550 nm).

2MTS4UP Upgrades Instructions
