In most cases the AURUS-OLED PLUS will have a page, dedicated to sensors
(temperature, light, humidity, wind, …).
Heating, now = 21°C
Selected sensor + zone: This field shows the selected sensor
zone and displays the measured value in that zone.
The target value of the selected sensor can be set using the
up/down arrows. When you click the up or down arrow, the
measured value displayed will change to the target value
(underlined).
If your system is cooling, the LED at the down arrow will be lit,
if your system is heating, the LED at the up arrow is lit!
After 10 seconds, it shifts back to the measured temperature.
The ‘Presets’ of the Sensor Zone: Here you can select the
most suitable preset. In case of a temperature sensor, you can
choose between: <DAY>, <NIGHT>, <ECO>
Day: This is the normal temperature setting during the day,
also called the ‘comfort’ temperature.
ECO: The ‘ECO’ value is a value which is a predefined number
of degrees different than the ‘day’ preset. In heating mode, the
ECO temperature is lower than the ‘day’ preset. In cooling
mode, the ECO temperature is higher than the ‘day’ preset.
[ENERGY SAVING PRESET]
Night: In case of cooling/heating this is your preferred
temperature setting during the night.
The ‘Mode’ of the Sensor Zone: With this button you select
the mode of the sensor if applicable. Normally only available
when using cool/heat air-
