Cat M/NB-IoT Quick Start Guide

80529NT11661A Rev. 3 –2020-07-22

2 of 33

SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE

NOTICE

While reasonable efforts have been made to assure the accuracy of this document, Telit

assumes no liability resulting from any inaccuracies or omissions in this document, or fromuse

of the information obtained herein. The information in this document has been carefully

checked and is believed to be reliable. However, no responsibility is assumed for inaccuracies

or omissions. Telit reserves the right to make changes to any products described herein and

reserves the right to revise this document and to make changes from time to time in content

hereof with no obligation to notify any person of revisions or changes. Telit does not assume

any liability arising out of the application or use of any product, software, or circuit described

herein; neither does it convey license under its patent rights or the rights of others.

It is possible that this publication may contain references to, or information about Telit products

(machines and programs), programming, or services that are not announced in your country.

Such references or information must not be construed to mean that Telit intends to announce

such Telit products, programming, or services in your country.

COPYRIGHTS

This instruction manual and the Telit products described in this instruction manual may be,

include or describe copyrighted Telit material, such as computer programs stored in

semiconductor memories or other media. Laws in the Italy and other countries preserve for

Telit and its licensors certain exclusive rights for copyrighted material, including the exclusive

right to copy, reproduce in any form, distribute and make derivative works of the copyrighted

material. Accordingly, any copyrighted material of Telit and its licensors contained herein or in

the Telit products described in this instruction manual may not be copied, reproduced,

distributed, merged or modified in any manner without the express written permission of Telit.

Furthermore, the purchase of Telit products shall not be deemed to grant either directly or by

implication, estoppel, or otherwise, any license under the copyrights, patents or patent

applications of Telit, as arises by operation of law in the sale of a product.

COMPUTER SOFTWARE COPYRIGHTS

The Telit and 3rd Party supplied Software (SW) products described in this instruction manual

may include copyrighted Telit and other 3rd Party supplied computer programs stored in

semiconductor memories or other media. Laws in the Italy and other countries preserve for

Telit and other 3rd Party supplied SW certain exclusive rights for copyrighted computer

programs, including the exclusive right to copy or reproduce in any form the copyrighted

computer program. Accordingly, any copyrighted Telit or other 3rd Party supplied SW

computer programs contained in the Telit products described in this instruction manual may

not be copied (reverse engineered) or reproduced in any manner without the express written

permission of Telit or the 3rd Party SW supplier. Furthermore, the purchase of Telit products

shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any

license under the copyrights, patents or patent applications of Telit or other 3rd Party supplied

SW, except for the normal non-exclusive, royalty free license to use that arises by operation

of law in the sale of a product.

3 of 33

USAGE AND DISCLOSURE RESTRICTIONS

I. License Agreements

The software described in this document is the property of Telit and its licensors. It is furnished

by express license agreement only and may be used only in accordance with the terms of such

an agreement.

II. Copyrighted Materials

Software and documentation are copyrighted materials. Making unauthorized copies is

prohibited by law. No part of the software or documentation may be reproduced, transmitted,

transcribed, stored in aretrievalsystem, or translated into any language or computer language,

in any form or by any means, without prior written permission of Telit

III. High Risk Materials

Components, units, or third-party products used in the product described herein are NOT fault-

tolerant and are NOT designed, manufactured, or intended for use as on-line control

equipment in the following hazardous environments requiring fail-safe controls: the operation

of Nuclear Facilities, Aircraft Navigation or Aircraft Communication Systems, Air Traffic

Control, Life Support, or Weapons Systems (High Risk Activities"). Telit and its supplier(s)

specifically disclaim any expressed or implied warranty of fitness for such High Risk Activities.

IV. Trademarks

TELIT and the Stylized T Logo are registered in Trademark Office. All other product or service

names are the property of their respective owners.

V. Third Party Rights

The software may include Third Party Right software. In this case you agree to comply with all

terms and conditions imposed on you in respect of such separate software. In addition to Third

Party Terms, the disclaimer of warranty and limitation of liability provisions in this License shall

apply to the Third Party Right software.

TELIT HEREBY DISCLAIMS ANY AND ALL WARRANTIES EXPRESS OR IMPLIED FROM

ANY THIRD PARTIES REGARDING ANY SEPARATE FILES, ANY THIRD PARTY

MATERIALS INCLUDED IN THE SOFTWARE, ANY THIRD PARTY MATERIALS FROM

WHICH THE SOFTWARE IS DERIVED (COLLECTIVELY “OTHER CODE”), AND THE USE

OF ANY OR ALL THE OTHER CODE IN CONNECTION WITH THE SOFTWARE,

INCLUDING (WITHOUT LIMITATION) ANY WARRANTIES OF SATISFACTORY QUALITY

OR FITNESS FOR A PARTICULAR PURPOSE.

NO THIRD PARTY LICENSORS OF OTHER CODE SHALL HAVE ANY LIABILITY FOR ANY

DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL

DAMAGES (INCLUDING WITHOUT LIMITATION LOST PROFITS), HOWEVER CAUSED

AND WHETHER MADE UNDER CONTRACT, TORT OR OTHER LEGALTHEORY, ARISING

IN ANY WAY OUT OF THE USE OR DISTRIBUTION OF THE OTHER CODE OR THE

EXERCISE OF ANY RIGHTS GRANTED UNDER EITHER OR BOTH THIS LICENSE AND

THE LEGAL TERMS APPLICABLE TO ANY SEPARATE FILES, EVEN IF ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES.

4 of 33

APPLICABILITY TABLE

PRODUCTS

ME910C1 SERIES

ME910G1 SERIES

ML865C1 SERIES

ML865G1 SERIES

ME310G1 SERIES


 5 of 33
Reproduction forbidden without Telit Communications PLC written authorization –All Rights Reserved
CONTENTS
1INTRODUCTION...........................................................................6
1.1 Scope............................................................................................6
1.2 Audience .......................................................................................6
1.3 Contact Information, Support.........................................................6
1.4 Related Documents.......................................................................6
2GENERAL DESCRIPTION............................................................7
2.1 ME910C1, ML865C1 Main Features..............................................7
2.2 ME910G1, ML865G1,ME310G1 Main Features ............................8
2.3 USB/UART port configuration.......................................................9
2.4 Warning on Windows Cellular connection....................................10
3APPLICATION MAIN FLOW.......................................................11
4NETWORK REGISTRATION ......................................................12
4.1 CAT-M1 / NB-IoT Registration AT script example........................12
4.2 2G Registration AT script example ..............................................14
4.3 Access technology selection........................................................15
4.4 Speed up registration...................................................................16
5CHECK/SET DATA SERVICE ....................................................17
6UDP SCRIPT...............................................................................18
7TCP SCRIPT...............................................................................20
8PSM AND EDRX.........................................................................22
8.1 PSM/eDRX overview...................................................................22
8.2 PSM script...................................................................................23
8.3 eDRX script .................................................................................27
8.4 PSM in between eDRX script.......................................................30
8Document History......................................................................32



6 of 33

1 Introduction

1.1 Scope

Scope of this document is to give an overview and basic instructions of how to start using the follwing

product series: ME910C1, ME910G1, ML865C1, ML865G1, ME310G1.

1.2 Audience

This document is intended for customers who want to use and test the NE866 product.

1.3 Contact Information, Support

For general contact, technical support services, technical questions and report documentation errors

contact Telit Technical Support at:

TS[email protected]

For detailed information about where you can buy the Telit modules or for recommendations on

accessories and components visit:

http://www.telit.com

Our aim is to make this guide as helpful as possible. Keep us informed of your comments and

suggestions for improvements.

Telit appreciates feedback from the users of our information.

1.4 Related Documents

●1VV0301351 ME910C1 HW User Guide Rev.12

●1VV0301588 ME310G1 Hardware Design Guide Rev. 5

●80529ST10815A ME910C1/NE910C1/ML865C1 AT Commands Reference Guide Rev. 12

●80617ST10991A ME310G1/ME910G1/ML865G1 AT Commands Reference Guide Rev. 5

●80529NT11643A ME910C1/NE910C1/ML865C1 PSM Application Note Rev. 1

●80617NT11830A ME310G1/ME910G1/ML865G1 PSM Application Note Rev. 0

7 of 33

2 General Description

2.1 ME910C1, ML865C1 Main Features

•LTE UE Category M1/NB1 3GPP release 13 compliant

•Half Duplex FDD

•Single Rx, single antenna

•3GPP Rel. 12 Power Saving Mode (PSM)

•3GPP Rel. 13 Extended Discontinuous Reception (eDRX)

•3GPP Rel. 13 Extended coverage

•Control via AT commands according to 3GPP TS27.005, 27.007 and customized AT

commands

•SIM application Tool Kit 3GPP TS 51.01

•SMS over NAS

•IPv4/IPv6 stack with TCP and UDP protocol

•OMA Lightweight M2M (LWM2M)

•Firmware Over-the-Air Update (FOTA) using delta upgrade techniques

•Telit Application Development Environment: AppZone C (for future release)

•SSL

•Optional embedded GNSS (GPS, GLONASS, Beidou, Galileo)

8 of 33

2.2 ME910G1,

ML865G1,ME310G1

Main Features

•LTE UE Cat M1 (1.4 MHz)/NB2 (200 KHz)

•3GPP Rel. 14 compliant

•Half-duplex FDD

•Single Rx, single antenna

•3GPP Rel. 12 PSM

•3GPP Rel. 13 eDRX

•3GPP Rel. 13 Extended Coverage

•Control via AT commands according to 3GPP TS 27.005, 27.007 and customized Telit

AT commands

•SIM application tool kit 3GPP 51.01

•VoLTE (planned)

•SMS over NAS

•IPv4/IPv6 stack with TCP and UDP protocol

•Firmware Over-the-Air Update (FOTA) using delta upgrade techniques

•TLS/DTLS

•Embedded GNSS (GPS, GLONASS, Beidou, Galileo)

•OMA Lightweight M2M (LwM2M)

9 of 33

2.3 USB/UART port

configuration

ME910C1, ME910G1, ML865C1, ML865G1, ME310G1 are equipped with 2 asynchronous

serial port (CMOS 1.8) and one integrated universal serial bus (USB 2.0 HS) transceiver with

the following composition:

•2 Telit USB Modem ports

•1 Telit HS-USB WWAN

•1 Telit Serial Diagnostic Interface

The screenshot below reports an example of the port composition listed on Windows 10 Device

Manager.

USB Modem ports are ACM devices and can

be used as AT Command interface.

Telit HS-USB WWAN is an RMNET adapter

that can beusedwith LinuxModemManager

and NetworkManager.

On Windows 10 WWAN Adapter should be

automatically loaded as Cellular Connection

in Network & Internet settings (see image

below).

Telit Serial Diagnostic Interface is used for

debugging purposes and for firmware

upgrade.

10 of 33

2.4 Warning on Windows

Cellular connection

When the module is recognized as a Cellular device, Windows uses the WWAN interface to

set up internet connection (NCSI). This could lead to connectivity issues using the module AT

interface: registration to the network, APN management, socket creation and data exchange,

PSM and eDRX functionalities can be affected.

If you do not need your PC is connected via WWAN interface, we strongly suggest to disable

it. Go to:

Control Panel ►Network and Sharing Center ► change Adapter settings ► right-click on

Cellular connection ►disable.

Andere Handbücher für ME910C1 Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Telit Wireless Solutions Steuereinheit Handbücher

Telit Wireless Solutions

Telit Wireless Solutions UC864-E Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions GE910 Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions BlueMod+S42M Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions WE922-3GR Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions GE864-QUAD V2 Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions DE910 Series Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions NE310L2 Leitfaden

Telit Wireless Solutions

Telit Wireless Solutions UL865N3G Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions LE910C1-NA Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions UE910 series Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions SL871 Technisches Datenblatt

Telit Wireless Solutions

Telit Wireless Solutions GE864 DUAL V2 Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions GE864 DUAL V2 Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions NE310L2 Leitfaden

Telit Wireless Solutions

Telit Wireless Solutions xE50-868 series Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions LE51-868S DemoUnit Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions G30 Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions GE310-GNSS Leitfaden

Telit Wireless Solutions

Telit Wireless Solutions E922-3GR Series Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions DE910-DUAL Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions GM862GPS Series Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions GL865-DUAL V3 Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions ME50-868 Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869T3-I Technisches Datenblatt

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
