Teltonika FMP100 Installationsanleitung

Quick Manual

V1.4

Plug and Play tracker

FMP100

FMP100 | Wiki

Table of Contents

Table of Contents .......................................................................... 2

Know your device .......................................................................... 3

Know your device .......................................................................... 4

Set up your device......................................................................... 5

How to insert Nano-SIM card .......................................................... 5

PC Connection (Windows)................................................................ 6

Configuration (Windows) ................................................................. 6

Quick SMS configuration.................................................................. 8

User Interface................................................................................ 9

Keyboard ........................................................................................ 9

Basic characteristics ..................................................................... 9

Safety information...................................................................... 12

Certification and Approvals ....................................................... 13

Warranty ...................................................................................... 14

Warranty Disclaimer ....................................................................... 14

FMP100 | Wiki

Know your device

Figure 1 FMP100 device view (With covers)

Business/Private

or Panic Button

FMP100 | Wiki

Know your device

FMP100 | Wiki

Set up your device

How to insert Nano-SIM card

1. Insert the SIM tray removal tool into the hole on the SIM card

tray and then push until the tray pops out.

2. Insert Nano-SIM card as shown with PIN request disabled or

read our Wiki how to enter it later in Teltonika Configurator.

Make sure that Nano-SIM card is fitted properly into the tray.

3. Insert the SIM card tray back.

4. After configuration, see “PC Connection (Windows)”.

Device is ready to be mounted.

Figure 4 SIM tray insert

Figure 3 Nano-SIM card insert

Figure 2 SIM tray removal

Figure 3 SIM tray removal

FMP100 | Wiki

PC Connection (Windows)

•Connection by using Bluetooth:

1) Power-up FMP100 with DC voltage (12 –30 V) power

supply. LED’s should start blinking, see “Error! Reference s

ource not found.”.

2) FMP100 Bluetooth is enabled by default. Turn on

Bluetooth on your PC, then select Add Bluetooth or

other device > Bluetooth. Choose your device named –

“FMBxxx_last_7_imei_digits”, without LE in the end.

Enter default password 5555, press Connect and then

select Done.

•If Bluetooth connection is not possible, please refer to the

FMP100 Wiki page on how to open the device casing and

connect it via Micro-USB.

Configuration (Windows)

At first FMP100 device will have default factory settings set. These

settings should be changed according to the user's needs. Main

configuration can be performed via Teltonika Configurator

software. Get the latest Configurator version from here.

Configurator operates on Microsoft Windows OS and uses

prerequisite MS .NET Framework. Make sure you have the correct

version installed.

Table 1 MS .NET requirements

MS.NETrequirements

Operating

system

MS .NET Framework

version

Version

Links

Windows Vista

Windows 7

Windows 8.1

Windows 10

MS .NET Framework

4.6.2

32 and 64 bit

www.microsoft.com

Downloaded Configurator will be in compressed archive. Extract it

and launch Configurator.exe. After launch software language can

be changed by clicking in the right bottom corner (Figure 5

Language selection).

FMP100 | Wiki

Configuration process begins by pressing on connected device

(Figure 6 Device connected via Bluetooth).

After connection to Configurator Status window will be displayed

(Figure 7 Configurator Status window).

Various Status window tabs display information about GNSS,

GSM, I/O, Maintenance and etc. FMP100 has one user editable

modification of configuration the changes need to be saved to

device using Save to device button. Main buttons offer following

functionality:

1. Load from device –loads configuration from device.

2. Save to device –saves configuration to device.

3. Load from file –loads configuration from file.

4. Save to file –saves configuration to file.

5. Update firmware –updates firmware on device.

6. Read records –reads records from the device.

7. Reboot device –restarts device.

8. Reset configuration –sets device configuration to

default.

Most important configurator section is GPRS –where all your

server and GPRS settings can be configured and Data Acquisition

–where data acquiring parameters can be configured.

More details about FMP100 configuration using Configurator can

be found in our Wiki.

Figure 5 Language selection

Figure 6 Device connected via Bluetooth

Figure 7 Configurator Status window

FMP100 | Wiki

Quick SMS configuration

Default configuration has optimal parameters present to ensure

best performance of track quality and data usage.

Quickly set up your device by sending this SMS command to it:

Note: Before SMS text, two space symbols should be inserted.

GPRS settings:

•

2001

–APN

•

2002

–APN username (if there

are no APN username, empty

field should be left)

•

2003

–APN password (if there

are no APN password, empty

field should be left)

Server settings:

•

2004

–Domain

•

2005

–Port

•

2006

–Data sending protocol

(0 –TCP, 1 –UDP)

Default configuration settings

Movement and ignition detection:

Vehicle movement will

be detected by

accelerometer

Ignition will be detected

by vehicle power voltage

between 13,2 –30 V

Device makes a record On Moving if one of these events happen:

300 seconds passes

Vehicle turns 10 degrees

Vehicle drives 100

meters

Speed difference

between last coordinate

and current position is

greater than 10 km/h

Device makes a record On Stop if:

1 hour passes while

vehicle is stationary

and ignition is off

Records sending to server:

If device has made a

record it is sent to the

server every 120

seconds

After successful SMS configuration, FMP100 device will

synchronize time and update records to configured server.

Time intervals and default I/O elements can be changed by

using Teltonika Configurator or SMS parameters.

" setparam

2001

:APN;

2002

:APN_username;

2003

:APN_password;

2004

:Domain;

2005

:Port;

2006

:0"

FMP100 | Wiki

User Interface

Table 3 User interface LED indication scenarios

SCENARIO

Indication

Meaning

GSM error

Red LED 500 ms

blink 3 times +

Buzzer

SIM is not inserted, device

can’t connect to the

operator or GSM signal is

being jammed

No GNSS fix

Red LED 1000 ms

blink 1 time

Device doesn’t have valid

GNSS fix and is searching

for coordinates

GNSS fix

Green LED 1000 ms

blink 1 time

Device has valid GNSS fix

Key pressed

1000 ms interval

Buzzer while active

Key is pressed and held

Private Trip

Green LED 500 ms

blink 3 times +

Buzzer

Battery is almost fully

discharged

Business Trip

Blue LED 500 ms

blink 3 times +

Buzzer

Indication used to remind

the user that device is still

operational

Note! This table contains only the default scenarios. Additional

scenarios/default ones can be modified using Teltonika

Configurator. User is able to select different indication color (Red,

Green or Blue), frequency of LED blinking and buzzer status.

Keyboard

Table 4 Keyboard default actions

Action

Function

1 Click

Check Trip Mode

2 Clicks

Change Trip Mode

Long Click

Alarm

Basic characteristics

Table 5 Basic characteristics

Module

Name

Teltonika TM2500

Technology

GSM/GPRS/GNSS/BLUETOOTH

GNSS

GPS, GLONASS, GALILEO, BEIDOU,

SBAS, QZSS, DGPS, AGPS

Receiver

33 channel

Tracking sensitivity

-165 dBM

Position accuracy

< 2.5 CEP

Velocity accuracy

< 0,1 m/s (within +/- 15% error)

Hot start

< 1 s

Warm start

< 25 s

Cold start

< 35 s

FMP100 | Wiki

Cellular

Technology

GSM

2G bands

Quad-band 850 / 900 / 1800 / 1900

MHz

Data transfer

GPRS Multi-Slot Class 12 (up to 240

kbps)

Data support

SMS (text/data)

Power

Input voltage range

10 - 30 V DC with overvoltage

protection

Back-up battery

3.7 V 170 mAh (0.63 Wh)

Power consumption

At 12V < 5 mA (Ultra Deep Sleep)

At 12V < 7 mA (Deep Sleep)

At 12V < 7 mA (Online Deep Sleep)

At 12V < 8 mA (GPS Sleep)

At 12V < 28 mA (nominal)

Bluetooth

Specification

4.0 + LE

Supported peripherals

Temperature and Humidity sensor,

Hands-free headset, Inateck Barcode

Scanner, Universal BLE sensor

support

Interface

Connection

Cigarette lighter socket

Configurable buttons

GNSS antenna

Internal High Gain

GSM antenna

Internal GSM High Gain

USB

1 x USB 2.0 Micro-USB for

configuration

1 x USB type A for external device

charging (5V 1A)

LED indication

RGB LED

SIM

Nano-SIM

Memory

128MB internal flash memory

Physicalspecification

Dimensions

96,7 x 33,4 x 27,5 mm (L x W x H)

Operatingenvironment

Operating temperature (without

battery)

-40 °C to +85 °C

Storage temperature (without battery)

-40 °C to +85 °C

Operating humidity

5% to 95% non-condensing

Ingress Protection Rating

IP41

Battery charge temperature

0 °C to +45 °C

Battery discharge temperature

-20 °C to +60 °C

Battery storage temperature

-20 °C to +45 °C for 1 month

-20 °C to +35 °C for 6 months

Features

Sensors

Accelerometer

Scenarios

Green Driving, Over Speeding

detection, Jamming detection, GNSS

Fuel Counter, Excessive Idling

detection, Unplug detection, Towing

detection, Crash detection, Auto

Geofence, Manual Geofence, Trip

Sleep modes

GPS Sleep, Online Deep Sleep, Deep

Sleep, Ultra Deep Sleep

Andere Handbücher für FMP100

Inhaltsverzeichnis

Andere Teltonika GPS Handbücher

Teltonika

Teltonika FMB910 Installationsanleitung

Teltonika

Teltonika TAT140 Installationsanleitung

Teltonika

Teltonika FM5500 Bedienungsanleitung

Teltonika

Teltonika FMM920 Installationsanleitung

Teltonika

Teltonika GH3000 Montageanleitung

Teltonika

Teltonika FMB964 Installationsanleitung

Teltonika

Teltonika GH1200 Bedienungsanleitung

Teltonika

Teltonika FMB920 Installationsanleitung

Teltonika

Teltonika FTC961 Installationsanleitung

Teltonika

Teltonika FM1000 ST Bedienungsanleitung

Teltonika

Teltonika FMA120 Bedienungsanleitung

Teltonika

Teltonika TMT250 Bedienungsanleitung

Teltonika

Teltonika FMB965 Installationsanleitung

Teltonika

Teltonika Telematics FMC880 Bedienungsanleitung

Teltonika

Teltonika FMB001 Bedienungsanleitung

Teltonika

Teltonika FMB125 Bedienungsanleitung

Teltonika

Teltonika Telematics FMC880 Installationsanleitung

Teltonika

Teltonika TST100 Bedienungsanleitung

Teltonika

Teltonika FMB930 Installationsanleitung

Teltonika

Teltonika FMB001 Installationsanleitung

Teltonika

Teltonika FMB900 Installations- und Benutzerhandbuch

Teltonika

Teltonika Telematics FMC150 Bedienungsanleitung

Teltonika

Teltonika FM1100 Bedienungsanleitung

Teltonika

Teltonika FMB130 Installationsanleitung

Beliebte GPS Handbücher anderer Marken

Raven

Raven Cruizer II Handbuch

Hama

Hama 53118 Bedienungsanleitung

Garmin

Garmin SOUNDER 125 Bedienungsanleitung

Garmin

Garmin DEZL 580 Bedienungsanleitung

Jigabot

Jigabot EX Bedienungsanleitung

Pointer

Pointer Cellocator CelloTrack XT LTE Installationsanleitung

Queclink

Queclink GV55LITE Bedienungsanleitung

Voxson

Voxson Voxtrack GPS500 Gebrauchsanweisung

Garmin

Garmin ECHOMAP PLUS Bedienungsanleitung

Starcom Systems

Starcom Systems Kylos Compact Bedienungsanleitung

Garmin

Garmin 15 H Series Bedienungsanleitung

Cobra

Cobra Marine MC 600Ci Bedienungsanleitung

Cellocator

Cellocator CelloTrack T Bedienungsanleitung

Enfora

Enfora Mini-MT GSM2228UG001 Bedienungsanleitung

Magellan

Magellan eXplorist 100 Bedienungsanleitung

LTE

LTE G50B Bedienungsanleitung

Garmin

Garmin DEZL OTR500 Bedienungsanleitung

SkyGolf

SkyGolf SkyCaddie SG1 Bedienungsanleitung
