Model T3 – Product Guide

Walk-Behind Scrubber

Provides Details on:

Features, Advantages, and Benefits

Model T3

Walk-Behind Scrubber

SOLUTION DELIVERY SYSTEM

Feature Advantage Benefit

Hygenic™ Solution Tank

Totally accessible solution tank.

Solution tank has 3 separate

large access points for cleaning.

1. The front access area

2. The rear access area

3. The rear solution drain cap

Improved air quality by preventing

mold and bacteria growth inside

dirty tanks.

Increases corporate health and

safety.

Solution Tank

•10.5 gallon/40 liter solution tank

•Easy fill feature

•Rotationally-molded

polyethylene construction

•10 year warranty on all

rotationally-molded

polyethylene components

Larger capacity for reduced

empty-fill requirement.

Durable construction for long life

and dependable performance.

Extended warranty coverage.

Increases operator productivity.

Ease of use.

Reduces long-term repair &

operating life cycle costs.

Features, Advantages, and Benefits

Model T3

Walk-Behind Scrubber

Solution Sight Tube

Sight tube at rear of machine

allows operator to see remaining

solution so they can better judge

the time they need to refill the

machine.

Increased productivity by good

water management.

Easier to use.

Optional FaST™ System

FaST ―Foam-activated

Scrubbing Technology extends

operating scrub time per tank of

solution by minimizing the amount

of water used during the scrubbing

process.

This greatly reduces empty/fill

cycles and creates less

wastewater.

Overcomes the need for the

operators to handle detergent.

Easy replacement of FaST-PAK™

in special tilt out storage area.

Increases operator productivity.

Is very easy to use.

Environmentally friendly.

Decreases detergent handling and

measuring.

Features, Advantages, and Benefits

Model T3

Walk-Behind Scrubber

SCRUBBING SYSTEM

Feature Advantage Benefit

Scrubbing Path

•20-inch/ 510 mm

Narrow width for superior

maneuverability and access to

hard to reach obstructed areas.

Ease of operation.

Uses 20-inch (510 mm)

Standard Diameter Pads

Readily available pad size and

types.

Versatile applications.

Saves money and time buying

spare pads.

Brushes

3 brush types available:

•Soft Dyna Scrub

•Medium Poly

•Aggressive Grit

Bush configurations for all types

of hard floor surfaces.

Versatile applications.

Features, Advantages, and Benefits

Model T3

Walk-Behind Scrubber

Easy-to-Install Pad Drivers and

disc brushes

Push button removal feature

allows operators to remove the

brush by just pressing one button

to lock the drive motor, and then a

quick twist on the pad or brush

and it will release.

The brush or pad then falls to the

ground.

To refit the brush or pad, rotate

the mounting under the brush

deck until you can see the

mounting holes through the slots

in the brush deck. (Arrowed)

Align pins with slot, twist into

place. Lock motor by pressing lock

button if necessary.

Reduces operator training

requirements.

Saves time and is more

convenient for the operators

Easy replacement, or removal for

cleaning of the brushes and pads.

Features, Advantages, and Benefits

Model T3

Walk-Behind Scrubber

Scrub Deck Lowering Pedal

Manual pedal raises and lowers

scrub deck.

Easy to use.

Decreases maintenance costs.

Brush Drive Motor

•1.0 horse power/.75 kW

brush/pad drive motor

•230 rpm

Powerful brush/pad drive motor(s)

for superior soil removal from hard

floor surfaces. Suitable for use on

all types of hard floor surfaces.

Cleaner, safer floor surfaces.

Versatile applications.

Brush/Pad Pressure

50 lb (23 kg) normal

90 lb (41 kg) maximum

Place brush pressure handle in

down position for normal scrubbing

pressure.

Place handle in up position for

aggressive down pressure for

superior soil removal from hard

floor surfaces.

Cleaner, safer floor surfaces.

Machine can be tailored for different

cleaning needs which increases

versatility.

Features, Advantages, and Benefits

Model T3

Walk-Behind Scrubber

RECOVERY SYSTEM

Feature Advantage Benefit

Parabolic Squeegee

The parabolic squeegee

maintains equal suction pressure

across the entire width of the

squeegee to ensure full pick-up of

all water.

Cleaner, drier, safer floor surfaces.

Quick Release, Break-away

Squeegee Design

Squeegee dislodges from

mounting when squeegee hits an

immovable object. This protects

the squeegee assembly from

damage.

Reduces squeegee maintenance

and replacement costs.

Squeegee Raise and Lower

Handle

Simple mechanical raise and

lower of the squeegee.

Decreases maintenance costs and

is very easy to use.

180 Degree Pick-up Squeegee

Squeegee follows machine

around 180 degree turns to

completely pick-up all water.

Increases safety and leaves

cleaner, drier floors.

Features, Advantages, and Benefits

Model T3

Walk-Behind Scrubber

Factory Set Squeegee No adjustments required for the

squeegee.

Makes operation and maintenance

easier and less costly.

No Tool Squeegee Change

Allows for quick and easy

replacement of squeegee blades.

Decreases maintenance costs and

increases productivity from less

downtime.

Vacuum System

•.5 hp / .37 kW vacuum motor

•2 stage

•65 cubic feet of airflow (cfm)

(1.84 cmm)

Powerful vacuum for superior

solution recovery from all types of

floor surfaces.

Easy-to-access, easy-to-maintain

vacuum motor.

Turns on automatically when

squeegee is lowered to the floor.

Increases operator productivity.

Cleaner, drier, safer floor surfaces.

Versatile applications.

Ease of operation.

Hygenic™ Recovery Tank

Accessible recovery tank for full

cleaning if required.

Improves air quality by preventing

mold and bacteria growth inside

dirty tanks.

Increases corporate health and

safety.

Recovery tank debris tray

Eliminates immersion of

operator’s hand into recovery

waste water

Collects debris from the dirty

water as it is vacuumed from the

floor

Reduces potential for cross-

contamination and operator illness

Decreases possibility of clogged

drain hoses

Features, Advantages, and Benefits

Model T3

Walk-Behind Scrubber

Recovery Tank

•15 gallon / 57 liter recovery

tank (includes demisting

chamber)

•Rotationally-molded

polyethylene construction

•Easy-to-clean tank design

•Built-in, easy-to-maintain float

shut-off assembly

Larger recovery capacity for

greater cleaning productivity.

Polyethylene construction for long

tank life, dependability, and

extended warranty.

Easy recovery tank access for

daily emptying and cleaning.

Built-in float shut-off assembly to

protect vacuum motor.

Increases operator productivity.

Reduces maintenance costs and

parts replacement.

Easy to maintain.

Easy-to-Use Drain Hoses

Drop down drain hoses for quick

evacuation of both recovery and

solution tank.

Ease of use.

Increases operator productivity.

Features, Advantages, and Benefits

Model T3

Walk-Behind Scrubber

PROPULSION SYSTEM

Feature Advantage Benefit

Battery System

•24 volt system

•Approx. 2.5 hour run time per

charge

•Fully automatic battery

charger (standard)

•Easy to charge battery pack

Longer continuous run time for

greater productivity.

Easy-to-access and maintain

batteries.

On-Board Battery Charger fitted

to the machine allows operator to

charge machine at any

convenient power outlet

One knob to release charger from

recovery tank

Easy-to-access and maintain the

On-Board Battery Charger

(shown released from recovery

tank)

Increases operator productivity.

Ease of maintenance.

Easy to service.

Saves time and is more convenient.

Eliminates need for dedicated

charger storage space

Ease of operation.

Self-Propelled Machine

Power driven version available

with variable speed up to 230

ft/min (70 m/min).

Easy use for longer cleaning shifts.

Brush Assist Transport Drive

System Standard

No separate motors to propel

machine.

Brush/pad drive system provides

forward drive for comfort and

fatigue reduction.

Simple to use and operate.

Reduces maintenance costs.

Increases operator productivity.

Ease of operation.
