LARDER

RS0880H

User Manual

SLOGRBG HR HU ROENG BiH/

CG SRB

ENG

In the interest of your safety and to ensure the correct use,

before installing and ﬁrst using the appliance, read this

user manual carefully, including its hints and warnings. To

avoid unnecessary mistakes and accidents, it is important

to ensure that all people using the appliance are

thoroughly familiar with its operation and safety features.

Save these instructions and make sure that they remain

with the appliance if it is moved or sold, so that everyone

using it through its life will be properly informed on

appliance use and safety.

For the safety of life and property keep to the precautions

of these user instructions as the manufacturer is not

responsible for damages caused by omission.

Children and vulnerable people safety

• This appliance can be used by children aged of 8

years and above and persons with reduced physical,

sensory or mental capabilities, or lack of experience and

knowledge if they have supervision or have been given

instructions concerning the use of the appliance in a

safe way and understand the hazards involved.

• Children aged from 3 to 8 years are allowed to load and

unload this appliance.

• Children should be supervised to ensure that they do

not play with the appliance.

• Cleaning and user maintenance should not be done by

children unless they are aged from 8 years and above

and supervised.

• Keep all packaging well away from children. There is risk

of suffocation.

• If you are discarding the appliance pull the plug out

of the socket, cut the connection cable (as close to the

appliance as you can) and remove the door to prevent

SAFETY INFORMATION

ENG

playing children from suffering electric shock or closing

themselves in.

• If this appliance features a magnetic door seal to replace

an older appliance having a spring lock (latch) on the

door or lid, be sure to make that spring lack unusable

before you discard the old appliance. This will prevent it

from becoming a death trap for a child.

General safety

Keep ventilation openings, in the appliance enclosure or

in the built-in structure, clear of obstruction.

Do not use mechanical devices or other means to

accelerate the defrosting process, other than those

recommended by the manufacturer.

Do not damage the refrigerant circuit.

Do not use other electrical appliances (such as ice cream

makers) inside of refrigerating appliances, unless they are

approved for this purpose by the manufacture.

Do not touch the light bulb if it has been on for a long

period of time because it could be very hot.1

When positioning the appliance, ensure the supply cord

is not trapped or damaged.

Do not locate multiple portable socket-outlets or portable

power suppliers at the rear of the appliance.

• Do not store explosive substances such as aerosol cans

with a ﬂammable propellant in this appliance.

• The refrigerant isobutene (R600a) is contained within

the refrigerant circuit of the appliance, a natural gas with

a high level of environmental compatibility, which is

nevertheless ﬂammable.

• During transportation and installation of the appliance,

be certain that none of the components of the

refrigerant circuit become damaged.

ENG

- avoid open ﬂames and sources of ignition

- thoroughly ventilate the room in which the appliance is

situated

• It is dangerous to alter the speciﬁcations or modify this

product in any way. Any damage to the cord may cause

a short circuit, ﬁre and/or electric shock.

• This appliance is intended to be used in a household

and similar applications such as

- staff kitchen areas in shops, ofﬁces and other working

environments;

- farm houses and by clients in hotels, motels and other

residential type environments;

- bed and breakfast type environments;

- catering and similar non-retail applications.

Any electrical components (plug, power cord,

compressor and etc.) must be replaced by a certiﬁed

service agent or qualiﬁed service personnel.

The light bulb supplied with this appliance is a “special

use light bulb” usable only with the appliance supplied.

This “special use lamp” is not usable for domestic

lighting.1

• Power cord must not be lengthened.

• Make sure that the power plug is not squashed or

damaged by the back of the appliance. A squashed or

damaged power plug may overheat and cause a ﬁre.

• Make sure that you can come to the main plug of the

appliance.

• Do not pull the main cable.

• If the power plug socket is loose, do not insert the

power plug. There is a risk of electric shock or ﬁre.

• You must not operate the appliance without the lamp.

ENG

• This appliance is heavy. Care should be taken when

moving it.

• Do not remove nor touch items from the freezer

compartment if your hands are damp/wet, as this could

cause skin abrasions or frost/freezer burns.

• Avoid prolonged exposure of the appliance to direct

sunlight.

Daily use

• Do not put hot things on the plastic parts in the

appliance.

• Do not place food products directly against the rear

wall.

• Frozen food must not be re-frozen once it has been

thawed out. 2

• Store pre-packed frozen food in accordance with the

frozen food manufacture, s instructions. 2

• Appliance, s manufactures storage recommendations

should be strictly adhered to. Refer to relevant

instructions.

• Do not place carbonated of ﬁzzy drinks in the freezer

compartment as it creates pressure on the container,

which may cause it to explode, resulting in damage to

the appliance.2

• Ice lollies can cause frost burns if consumed straight

from the appliance.2

To avoid contamination of food, please respect the

following

instructions

• Opening the door for long periods can cause

a signiﬁcant increase of the temperature in the

compartments of the appliance.

• Clean regularly surfaces that can come in contact with

ENG

food and accessible drainage systems.

• Clean water tanks if they have not been used for 48h;

ﬂush the water system connected to a water supply if

water has not been drawn for 5 days.

• Store raw meat and ﬁsh in suitable containers in the

refrigerator, so that it is not in contact with or drip onto

other food.

• Two-star frozen-food compartments (if they are

presented in the appliance) are suitable for storing pre-

frozen food, storing or making ice-cream and making

ice cubes.

• One-, two- and three -star compartments (if they are

presented in the appliance) are not suitable for the

freezing of fresh food.

• If the appliance is left empty for long periods, switch off,

defrost, clean, dry and leave the door open to prevent

mount developing within the appliance.

Care and cleaning

• Before maintenance, switch off the appliance and

disconnect the main plug from the power socket.

• Do not clean the appliance with metal objects.

• Do not use sharp objects to remove frost from the

appliance. Use a plastic scraper. 2

• Regularly examine the drain in the refrigerator for

defrosted water. If necessary, clean the drain. If the

drain is blocked, water will collect at the bottom of the

appliance. 3

Installation

• For electrical connection carefully follow the instructions

given in speciﬁc paragraphs.

• Unpack the appliance and check if there are damages

ENG

on it. Do not connect the appliance if it is damaged.

Report possible damages immediately to the place you

bought it. In that case retain packing.

• It is advisable to wait at least four hours before

connecting the appliance to allow the oil to ﬂow back in

the compressor.

• Adequate air circulation should be provided around the

appliance, lacking this leads to overheating. To achieve

sufﬁcient ventilation, follow the instructions relevant to

installation.

• Wherever possible the spacers of the product should

be against a wall to avoid touching or catching warm

parts (compressor, con- denser) to prevent possible

burn.

• The appliance must not be located close to radiators or

cookers.

• Make sure that the main plug is accessible after the

installation of the appliance.

Service

• Any electrical work required to do the servicing of

the appliance should be carried out by a qualiﬁed

electrician or competent person.

• This product must be serviced by an authorized Service

Center, and only genuine spare parts must be used.

Energy saving

• Do not put hot food in the appliance;

• Do not pack food close together as this prevents air

circulating;

• Make sure food does not touch the back of the

compartment(s);

• If electricity goes off, do not open the door(s);

ENG

• Do not open the door(s) frequently;

• Do not keep the door(s) open for a long time;

• Do not set the thermostat on exceeding cold

temperatures;

• All accessories, such as drawers, shelves balconies,

should be kept there for lower energy consumption.

1If there is a light in the compartment.

2If there is a freezer compartment.

3If there is a fresh-food storage compartment.

OVERVIEW

Note: Picture is for reference only.

Thermostat and light

Glass Shelf

Crisper Cover

Crisper

Leveling Foot

Door Balconies

ENG

REVERSE DOOR

Tool required: Philips screwdriver, Flat bladed screwdriver, Hexagonal spanner.

• Ensure the unit is unplugged and empty.

• To take the door off, it is necessary to tilt the unit backwards. You should rest the unit on something solid

so that it will not slip during the door reversing process.

• All parts removed must be saved to do the reinstallation of the door.

• Do not lay the unit ﬂat as this may damage the coolant system.

• It’s better that 2 people handle the unit during assembly.

Remove the top right hinge cover. Move the core cover from left side to right side.

And then lift the upper door and place it on a

padded surface to prevent it from scratching.

Undo the screws.Then remove the hinge bracket.

Remove the top left screw cover.

1 4

Unscrew and remove the bottom hinge pin, turn

the bracket over and replace it.

unscrew

ENG

Reﬁt the bracket ﬁtting the bottom hinge pin.

Replace both adjustable feet.

Reﬁt the bracket ﬁtting the bottom hinge pin.

Replace both adjustable feet.

7. Place the door back on. Ensure the door is

aligned horizontally and vertically so that the

seals are closed on all sides before ﬁnally

tightening the top hinge.

8. Insert the hinge bracket and screw it to the top

of the unit.

9. Use a spanner to tighten it if necessary.

Detach the Fridge and the Freezer door gaskets

and then attach them after rotating.

Put the hinge cover and the screw cover back.

789 11

INSTALLATION

Install door external handle (if external handle is present)

Inhaltsverzeichnis

Sprachen:

Andere Tesla Kühlschrank Handbücher

Tesla

Tesla RM6400FMX1 Bedienungsanleitung

Tesla

Tesla RS2400H1 Bedienungsanleitung

Tesla

Tesla RS0906H Bedienungsanleitung

Tesla

Tesla RS1300M1 Bedienungsanleitung

Tesla

Tesla RS0400MB Bedienungsanleitung

Tesla

Tesla RS1100MB Bedienungsanleitung

Tesla

Tesla RD1600H1 Bedienungsanleitung

Tesla

Tesla RC2700H1 Bedienungsanleitung

Tesla

Tesla RB5200FMX1 Bedienungsanleitung

Tesla

Tesla RB5210FHX Bedienungsanleitung

Tesla

Tesla RC3400FHX Bedienungsanleitung

Tesla

Tesla RC3100FHX Bedienungsanleitung

Tesla

Tesla RU1700H Bedienungsanleitung

Tesla

Tesla RC2600HXE Bedienungsanleitung

Tesla

Tesla Larder RS0900H Bedienungsanleitung

Tesla

Tesla RC3200FHX1 Bedienungsanleitung

Tesla

Tesla RC3220FC Bedienungsanleitung

Tesla

Tesla RS1100M1 Bedienungsanleitung

Tesla

Tesla RM4700FHBE Bedienungsanleitung

Tesla

Tesla RS0902M Bedienungsanleitung

Tesla

Tesla RC4200FMX Bedienungsanleitung

Tesla

Tesla RF5100FMB Bedienungsanleitung

Tesla

Tesla RS2400M Bedienungsanleitung

Tesla

Tesla RC3200FHX Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
