Texas Instruments SLOU020A Bedienungsanleitung

2001 Mixed-Signal Products

TPA311 MSOP

Audio Power Amplifier

Evaluation Module

User’s Guide

SLOU020A

IMPORTANT NOTICE

TexasInstrumentsanditssubsidiaries(TI)reservetherighttomakechangestotheirproductsortodiscontinue

any product or service without notice, and advise customers to obtain the latest version of relevant information

to verify, before placing orders, that information being relied on is current and complete. All products are sold

subject to the terms and conditions of sale supplied at the time of order acknowledgment, including those

pertaining to warranty, patent infringement, and limitation of liability.

TI warrants performance of its products to the specifications applicable at the time of sale in accordance with

TI’sstandardwarranty.TestingandotherqualitycontroltechniquesareutilizedtotheextentTIdeemsnecessary

to support this warranty. Specific testing of all parameters of each device is not necessarily performed, except

those mandated by government requirements.

Customers are responsible for their applications using TI components.

In order to minimize risks associated with the customer’s applications, adequate design and operating

safeguards must be provided by the customer to minimize inherent or procedural hazards.

TIassumesnoliabilityforapplicationsassistance or customer product design. TI does not warrantorrepresent

thatanylicense,eitherexpressorimplied,isgrantedunderanypatentright,copyright,maskworkright,orother

intellectual property right of TI covering or relating to any combination, machine, or process in which such

products or services might be or are used. TI’s publication of information regarding any third party’s products

or services does not constitute TI’s approval, license, warranty or endorsement thereof.

Reproduction of information in TI data books or data sheets is permissible only if reproduction is without

alterationandisaccompaniedbyallassociatedwarranties,conditions,limitationsandnotices. Representation

or reproduction of this information with alteration voids all warranties provided for an associated TI product or

service, is an unfair and deceptive business practice, and TI is not responsible nor liable for any such use.

Resale of TI’s products or services with statements different from or beyond the parameters stated by TI for

that product or service voids all express and any implied warranties for the associated TI product or service,

is an unfair and deceptive business practice, and TI is not responsible nor liable for any such use.

Also see: Standard Terms and Conditions of Sale for Semiconductor Products. www.ti.com/sc/docs/stdterms.htm

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

iii

Chapter Title—Attribute Reference

Preface

Related Documentation From Texas Instruments

TI Plug-N-Play Audio Amplifier Evaluation Platform (literature

number SLOU011) provides detailed information on the evaluation

platform and its use with TI audio evaluation modules.

TPA311 350-mW Low-Voltage Audio Power Amplifier (literature

number SLOS207) This is the data sheet for the TPA311 audio

amplifier integrated circuit.

FCC Warning

This equipment is intended for use in a laboratory test environment only. It

generates, uses, and can radiate radio frequency energy and has not been

testedfor compliance with thelimitsof computing devices pursuanttosubpart

Jofpart 15of FCCrules, whicharedesignedtoprovidereasonableprotection

against radio frequency interference. Operation of this equipment in other

environments may cause interference with radio communications, in which

case the user at his own expense will be required to take whatever measures

may be required to correct this interference.

Trademarks

TI is a trademark of Texas Instruments Incorporated.

Running Title—Attribute Reference

Chapter Title—Attribute Reference

Contents

1 Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Feature Highlights 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Description 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 TPA311 MSOP EVM Specifications 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Quick Start 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 Precautions 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Quick Start List for Platform 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Quick Start List for Stand-Alone 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Details 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Precautions 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 The TPA311 MSOP Audio Amplifier Evaluation Module 3-3. . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.1 TPA311 Audio Amplifier IC 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.2 BTL Operation 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.3 Single-Ended Operation 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.4 Module Gain 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.5 Shutdown 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 Using The TPA311 MSOP EVM With The Plug-N-Play Evaluation Platform 3-6. . . . . . . . .

3.3.1 Installing and Removing EVM Boards 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3.2 Signal Routing 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3.3 Mute/Mode 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3.4 Power Requirements 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3.5 Inputs and Outputs 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4 Using The TPA311 MSOP EVM Stand-ALone 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4.1 TPA311 MSOP EVM Connected for BTL Output 3-12. . . . . . . . . . . . . . . . . . . . . . . .

3.4.2 TPA311 MSOP EVM Connected for Single-Ended Output 3-13. . . . . . . . . . . . . . . .

3.5 TPA311 MSOP Audio Amplifier Evaluation Module Parts List 3-14. . . . . . . . . . . . . . . . . . . .

Running Title—Attribute Reference

Figures

1–1 The TI TPA311 MSOP Audio Amplifier Evaluation Module 1-3. . . . . . . . . . . . . . . . . . . . . . . . . .

2–1 Quick Start Platform Map 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–2 Quick Start Module Map 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–1 The TI Plug-N-Play Audio Amplifier Evaluation Platform 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–2 TPA311 MSOP EVM 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–3 TPA311 MSOP EVM Schematic Diagram 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–4 TPA311 Audio Amplifier IC 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–5 Platform Signal Routing and Outputs 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–6 Mute/Mode and Polarity Control 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–7 Typical Headphone Plug 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–8 TPA311 MSOP EVM Connected for Stereo BTL Output 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . .

3–9 TPA311 MSOP EVM Connected for Stereo Single-Ended Output 3-13. . . . . . . . . . . . . . . . . . .

Tables

2–1 Typical TI Plug-N-Play Platform Jumper and Switch Settings for the

TPA311 MSOP EVM 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–2 Platform Jumper and Switch Settings for the TPA311 MSOP EVM 2-3. . . . . . . . . . . . . . . . . . .

3–1 TPA311 MSOP EVM Parts List 3-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1

Introduction

This chapter provides an overview of the Texas Instruments (TI) TPA311

MSOPaudio amplifierevaluationmodule(SLOP123). It includes alistofEVM

features, a brief description of the module illustrated with a pictorial diagram,

and a list of EVM specifications.

Topic Page

1.1 Feature Highlights 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Description 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 TPA311 MSOP EVM Specifications 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1

Feature Highlights

1-2 Introduction

1.1 Feature Highlights

The TI TPA311 MSOP audio amplifier evaluation module and the TI

plug-n-play audio amplifier evaluation platform include the following features:

TPA311 Low-Voltage Audio Power Amplifier Evaluation Module

Single channel, bridge-tied load (BTL) or single-ended operation

3.3-V and 5-V operation

350 mW output power into 8 Ωat 5 V, BTL

Ultra-low current consumption in shutdown/mute mode

Internal thermal and short-circuit protection

Module gain adjustable between approximately 2 and 22

Quick and Easy Configuration With the TI Plug-N-Play Audio Amplifier

Evaluation Platform

Evaluation module is designed to simply plug into the platform, auto-

matically making all signal, control, and power connections

Platform provides flexible power options

Jumpers on the platform select power and module control options

Switches on the platform route signals

Platformprovides quick and easy audio inputand output connections

Platform Power Options

Onboard 9-V battery

External 5-V –15-V (VCC) supply inputs

External regulated VDD supply input

Socket for onboard 5 V/3.3 V VDD voltage regulator EVM

Onboard overvoltage and reverse polarity power protection

Platform Audio Input and Output Connections

Left and right RCA phono jack inputs

Miniature stereo phone jack input

Left and right RCA phono jack outputs

Left and right compression speaker terminal outputs

Miniature stereo headphone jack output

Description

1-3

Introduction

1.2 Description

The TPA311 MSOP audio power amplifier evaluation module is a complete,

low-power single-channel audio power amplifier. It consists of the TI TPA311

350-mWlow-voltage audiopower amplifierICin averysmall MSOPpackage,

along with a small number of other parts mounted on a circuit board that is

approximately one and a quarter inches square (Figure 1–1).

Figure 1–1.The TI TPA311 Audio Amplifier Evaluation Module

OUT+

IN+

GND

Vdd GND

U1 †

Shutdown

OUT–

GND

TEXAS

INSTRUMENTS

SLOP123

TPA311 MSOP EVM

SE\BTL*

†Due to the very small size of the MSOP IC package, the standard part number TPA311 is replaced with the code TIAAB

Single in-line header pins are mounted to the underside of the module circuit

board to allow the EVM to be plugged into the TI plug-n-play audio amplifier

evaluationplatform, or to be wired directlyintoexisting circuitsandequipment

when used stand-alone.

The platform has room for a pair of TPA311 MSOP evaluation modules and is

a convenient vehicle for demonstrating TI’s audio power amplifier and related

evaluation modules. The EVMs simply plug into the platform, which auto-

matically provides power to the modules, interconnects them correctly, and

connectsthemtoaversatilearrayofstandardaudioinputandoutputjacksand

connectors. Easy-to-use configuration controls allow the platform and EVMs

to quickly model many possible end-equipment configurations.

There is nothing to build, nothing to solder, and nothing but the speakers

included with the platform to “hook up.”

1.3 TPA311 EVM Specifications

Supply voltage range, VDD 2.5 V to 5.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Supply current, IDD 250 mA, max. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Continuous output power, PO:8-ΩBTL, VDD=5 V: 350 mW. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

32-ΩBTL, VDD=5 V: 75 mW. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Audio input voltage, VI2 Vpp, max. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Minimum load impedance, RL8 Ω. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-4 Introduction

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Texas Instruments Verstärker Handbücher

Texas Instruments

Texas Instruments TPA751 MSOP Bedienungsanleitung

Texas Instruments

Texas Instruments TAS54 4C Series Leitfaden

Texas Instruments

Texas Instruments SLOU106 Bedienungsanleitung

Texas Instruments

Texas Instruments TPA032D04 Bedienungsanleitung

Texas Instruments

Texas Instruments PurePath TAS5766M Bedienungsanleitung

Texas Instruments

Texas Instruments TPA005D02 Bedienungsanleitung

Texas Instruments

Texas Instruments THS3001 Bedienungsanleitung

Texas Instruments

Texas Instruments TPA2018D1YZFEVM Bedienungsanleitung

Texas Instruments

Texas Instruments TPA3120D2 Bedienungsanleitung

Texas Instruments

Texas Instruments TPA0233 Bedienungsanleitung

Texas Instruments

Texas Instruments TPA3003D2EVM Bedienungsanleitung

Texas Instruments

Texas Instruments TPA6101A2 Bedienungsanleitung

Texas Instruments

Texas Instruments TPA3001D1EVM Bedienungsanleitung

Texas Instruments

Texas Instruments APA100 Bedienungsanleitung

Texas Instruments

Texas Instruments TPA2008D2 Bedienungsanleitung

Texas Instruments

Texas Instruments SLOU023A Bedienungsanleitung

Texas Instruments

Texas Instruments LM4910 Boomer Bedienungsanleitung

Texas Instruments

Texas Instruments CLC520 Bedienungsanleitung

Texas Instruments

Texas Instruments TPA005D12 Bedienungsanleitung

Texas Instruments

Texas Instruments LM3886 Overture Bedienungsanleitung

Texas Instruments

Texas Instruments MSP430F2274 Bedienungsanleitung

Texas Instruments

Texas Instruments TPA3008D2 Bedienungsanleitung

Texas Instruments

Texas Instruments TPA2000D4 Bedienungsanleitung

Texas Instruments

Texas Instruments TAS5102EVM Bedienungsanleitung

Beliebte Verstärker Handbücher anderer Marken

ASTRO

ASTRO HVO V40 P Bedienungsanleitung

Marantz

Marantz SUPERSCOPE BLA-545 Montageanleitung

NAD

NAD CI980 Bedienungsanleitung

Technics

Technics SE-CH770 Bedienungsanleitung

Harman Kardon

Harman Kardon HK6300 Bedienungsanleitung

NAD

NAD T975 Bedienungsanleitung

McIntosh

McIntosh MA6850 Bedienungsanleitung

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Bedienungsanleitung

Viatron

Viatron Autrix Bedienungsanleitung

GME

GME GA9800 Bedienungsanleitung

Atlas

Atlas CP700 Bedienungsanleitung

Roland

Roland KC-1000 Bedienungsanleitung

Pyle

Pyle PFMRA350BW Bedienungsanleitung

Advantage

Advantage S-250 Bedienungsanleitung

IRT Electronics

IRT Electronics DVA-3007 Bedienungsanleitung

Dimavery

Dimavery BA-100 Series Bedienungsanleitung

Sony

Sony XM-S400D Bedienungsanleitung

Schertler

Schertler ROY X Bedienungsanleitung
