1 Introduction

The BIOS USB Package (based on JUNGO USB stack) provides capability to incorporate a

USB host or USB device functionality for an embedded device. This document describes the

USB host and device stack architecture, installation procedure and example use cases in TI

BIOS environment.

The BIOSUSB package supports both CCS3 and CCS4 for the following platforms

C6747/OMAPL137

C6748/OMAPL138

1.1 Terms & Abbreviations

Term Description

API Application Programming Interface

Port Platform and Operating system abstraction layer

JOS USB general services module

USB Device Platform capable of performing USB device functionality

USB Host Platform capable of performing USB host functionality

MSC Mass Storage Class

USB Universal Serial Bus

USBware Product name of Jungo’s USB host and device stack

1.2 References

#Document Description

1usb_device_stack.pdf USBware device stack details

2usb_host_stack.pdf USBware host stack details

3mass_storage_class_driver.pdf USBware mass storage driver details

4mass_storage_fd.pdf USBware mass storage function driver details

5hid_class_driver.pdf HID Class driver details

6hid_keyboard_fd.pdf HID keyboard function driver details

7hid_fd_lib.pdf HID function driver library reference

Page 8 of 21

BIOSUSB User Guide

2 Installation Guide

This chapter discusses the BIOS USB package installation procedure and how to

configure and run the usb host or device sample example provided along with the

package, refer to section-6.

2.1 System Requirements

The following products are required to be installed prior to using the BIOSUSB

Package for C6747/OMAPL37 and C6748/OMAPL138 platform:

For CCS3 Environment

CCS 3.3.80.11 (service release 10)

DSP-BIOS versioned 5.41.02.14

Code Generation Tools 6.1.9

EVM C6747/OMAPL37 (Rev-D recommended) or C6748/OMAPL138 Board

(Beta- version recommended)

XDS 510 USB Emulator (Optional) – EVM has on board emulator

For CCS4 Environment

CCS4 version 4.0.0.16000

DSP-BIOS versioned 5.41.02.14

XDS 510 USB Emulator (Optional) – EVM has on board emulator

Dependent Packages

EDMA 3 LLD – versioned 01.11.00.02

ERTFS File System package versioned 1.10.00.30 or higher version

PSP_DRIVERS Package - The BIOSPSP GA Package with versioned 1.30.00

2.2 Installation and configuration of dependent packages.

BIOS USB package is dependent on the following packages and as such expects

these packages to be installed and configured correctly prior to its installation and

usage.

I. EDMA3 LLD Driver package

II. RTFS package – Required for BIOS USB Host functionality. RTFS package is

needed for supporting MSC devices such as USB sticks, USB HDD’s etc.

III. PSP_DRIVERS Package

1. Install EDMA-3 LLD Driver into preferred drive/folder. Please refer the EDMA3

package installation guide. The environment variable ‘

EDMA3LLD_BIOS5_INSTALLDIR’ is used in the sample application projects for

referring to the EDMA3 driver libraries. This environment variable is created and

updated by the EDMA3 LLD driver during its installation. Please ensure that this

environment variable is pointing to the EDMA3 LLD install directory intended to be

used along with this package. This is more important when there are multiple EDMA

LLD installations as the installer updates this environment variable with latest

installation version. (eg. If EDMA LLD driver is installed into c:\edma3_lld\ the

environment variable is set to EDMA3LLD_BIOS5_INSTALLDIR=c:\edma3_lld).

Page 9 of 21

BIOSUSB User Guide

2. Install the RTFS Driver into preferred drive/folder. Please refer to the RTFS package

installation guide. The environment variable ‘RTFS_INSTALL_DIR’ is used in the

sample application project for referring to RTFS driver libraries. Please ensure that

this environment variable is pointing to the RTFS install directory intended to be used

along with this package.

3. Install BIOSPSP Package Driver into preferred drive/folder. Please refer to PSP

driver’s installation procedure. The environment variable

‘PSP_DRIVERS_INSTALL_DIR’ is used in the sample application project for referring

to libraries of PSP components like block media, PSC, platforms, MMC/SD, NAND, I2C

etc. Please ensure that this environment variable is pointing to the install directory of

PSP component intended to be used along with this package. (eg. If BIOSPSP

package is installed into c:\pspdrivers_1_30_00_06\ the environment variable is set

to PSP_DRIVERS_INSTALL_DIR = c:\pspdrivers_1_30_00_06).

4. Install the BIOS USB package using the self extracting installer. Figure-1 shows the

directory structure of BIOS USB Package after the installation. The installer will

create BIOSUSB_INSTALL_DIR environment variable pointing to BIOSUSB

installation directory. This environment variable is used in USB Host MSC application

examples of RTFS package.

Page 10 of 21

BIOSUSB User Guide

3 Folder Structure

Figure 1 illustrates the folder structure and placement of the BIOS USB package.

Figure 1: BIOSUSB directory structure

The folder ‘biosusb’ contains the following components

Inhaltsverzeichnis

Andere Texas Instruments Steuereinheit Handbücher

Texas Instruments

Texas Instruments DAC38RF8xEVM Series Bedienungsanleitung

Texas Instruments

Texas Instruments SWIFT TPS548A20 Bedienungsanleitung

Texas Instruments

Texas Instruments TPS6227xEVM-306 Bedienungsanleitung

Texas Instruments

Texas Instruments bq27 10EVM Series Bedienungsanleitung

Texas Instruments

Texas Instruments SimpleLink CC3220MOD Series Bedienungsanleitung

Texas Instruments

Texas Instruments DP159RSB Bedienungsanleitung

Texas Instruments

Texas Instruments NA210-214EVM Bedienungsanleitung

Texas Instruments

Texas Instruments TPS53128 Bedienungsanleitung

Texas Instruments

Texas Instruments Stellaris LM3S818 Bedienungsanleitung

Texas Instruments

Texas Instruments TPS65320C-Q1-EVM Bedienungsanleitung

Texas Instruments

Texas Instruments DLPDLCR660TEVM Bedienungsanleitung

Texas Instruments

Texas Instruments SimpleLink CC3200MOD Bedienungsanleitung

Texas Instruments

Texas Instruments TLV320AIC3109EVM-K Bedienungsanleitung

Texas Instruments

Texas Instruments TPS6381xEVM Bedienungsanleitung

Texas Instruments

Texas Instruments BQ25672EVM Bedienungsanleitung

Texas Instruments

Texas Instruments TPS54331 Bedienungsanleitung

Texas Instruments

Texas Instruments TLV320DAC26EVM Bedienungsanleitung

Texas Instruments

Texas Instruments TA 5 1 Q15B5EVM-K Series Bedienungsanleitung

Texas Instruments

Texas Instruments EVMK2E Bedienungsanleitung

Texas Instruments

Texas Instruments DAC1220EVM Bedienungsanleitung

Texas Instruments

Texas Instruments TRF3705EVM Bedienungsanleitung

Texas Instruments

Texas Instruments TPS6101xEVM-157 Bedienungsanleitung

Texas Instruments

Texas Instruments TMS320C6A816 Series Produkthandbuch

Texas Instruments

Texas Instruments TAS3251 Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
