DS125DF111EVM Evaluation Board

User's Guide

Literature Number: SNLU158A

January 2014–Revised January 2016

2SNLU158A–January 2014–Revised January 2016

Submit Documentation Feedback

Table of Contents

Contents

1 Overview............................................................................................................................. 4

2 Features.............................................................................................................................. 5

3 Applications ........................................................................................................................ 5

4 Ordering Information............................................................................................................ 5

5 Setup.................................................................................................................................. 6

5.1 Pin Control Mode......................................................................................................... 6

5.2 SMBus Slave Mode...................................................................................................... 9

5.3 EEPROM Mode......................................................................................................... 12

6 EVM Layout ....................................................................................................................... 13

7 Schematic ......................................................................................................................... 14

8 Bill of Materials .................................................................................................................. 15

9 Example Waveforms........................................................................................................... 16

Revision History.......................................................................................................................... 18

www.ti.com

SNLU158A–January 2014–Revised January 2016

List of Figures

1 DS125DF111EVM........................................................................................................... 4

2 4-Level I/O Control on DS125DF111EVM................................................................................ 6

3 DS1xxDF111EVM Slave Mode Full Setup ............................................................................... 9

4 DS1xxDF111EVM Slave Mode Close-Up ................................................................................ 9

5 DS125DF111 High Level Page........................................................................................... 10

6 DS125DF111 Low Level Page ........................................................................................... 11

7 DS125DF111 Eye Monitor Page......................................................................................... 11

8 DS125DF111 EEPROM Hex File Generation Page................................................................... 12

9 Top Assembly Layer....................................................................................................... 13

10 Bottom Assembly Layer ................................................................................................... 13

11 10.3125 Gbps Output Waveform......................................................................................... 16

12 10.3125 Gbps Rj/Dj Jitter Decomposition............................................................................... 17

List of Tables

1 Four-Level Logic Settings................................................................................................... 6

2 DS125DF111 VOD Levels.................................................................................................. 7

3 DS125DF111 DEM Levels.................................................................................................. 7

4 DS125DF111 Loopback Control........................................................................................... 8

5 SMBus Write Address Assignment ...................................................................................... 10

4SNLU158A–January 2014–Revised January 2016

Submit Documentation Feedback

DS125DF111EVM Evaluation Board

User's Guide

SNLU158A–January 2014–Revised January 2016

DS125DF111EVM Evaluation Board

1 Overview

The Texas Instruments DS125DF111EVM evaluation module provides a high bandwidth platform with an

SMA interface to evaluate the DS125DF111 dual channel retimer with integrated signal conditioning. The

DS125DF111 includes an input Continuous-Time Linear Equalizer (CTLE), Clock and Data Recovery

(CDR), and transmit driver on each channel.

Figure 1. DS125DF111EVM

www.ti.com

Features

SNLU158A–January 2014–Revised January 2016

DS125DF111EVM Evaluation Board

2 Features

• Adjustable Transmit VOD: 600 to 1300 mVp-p

• Settable Transmit De-emphasis Driver to -12 dB

• Low Power Consumption: 200 mW/Channel

• Locks to Half/Quarter/Eighth Data Rates for Legacy Support

• On-chip Eye Monitor (EOM), PRBS Generator

3 Applications

• Front Port Optical Interconnects

• SFF-8431

• 10G/1G Ethernet

• CPRI

4 Ordering Information

EVM ID DEVICE ID DEVICE PACKAGE

DS125DF111EVM DS125DF111SQ 24WQFN

HIGH

SIGNAL

RESISTOR

SIGNAL

LOW

4-LEVEL CONTROL

HIGH RESISTOR FLOAT LOW

PIN HEADER CONNECTION

Setup

www.ti.com

6SNLU158A–January 2014–Revised January 2016

Submit Documentation Feedback

DS125DF111EVM Evaluation Board

5 Setup

This section describes the jumpers and connectors on the EVM as well as how to properly connect, set

up, and use the DS125DF111EVM.

The DS125DF111EVM can be used in three different modes:

1. Pin Control Mode – provides access to selected signal integrity settings.

2. SMBus Slave Mode – provides full access to signal integrity and control settings.

3. EEPROM Mode – provides full access to signal integrity and control settings. EEPROM mode is a

convenient method of programming one or more DS125DF111 devices on system power up when an

SMBus master (microcontroller or similar) is unavailable in the design.

This EVM and documentation focus on Pin Control and SMBus Slave Mode to highlight the ease-of-use

and excellent low-jitter performance of the DS125DF111.

5.1 Pin Control Mode

In Pin Control Mode, the external control pins on the DS125DF111 are used to configure the signal

integrity and control settings of the device. In this mode, only a subset of the VOD and de-emphasis

(DEMA/B) levels are available. Due to the limited number of control pins, a limited bandwidth 4-level input

scheme has been implemented across the control pin interface. This allows for improved DE and VOD

control with fewer physical pins.

The four levels are defined below:

Table 1. Four-Level Logic Settings

Level Input Pin Setting

Low - 0 1 kΩto GND

Resistor - R 20 kΩto GND

Float - F Open

High - 1 1 kΩto VDD

The EVM interfaces to this 4-level I/O using the setup in Figure 2. Only one shunt connection is required

to access any of the four levels. This methodology minimizes the risk of improper connections that could

damage the board or board power supply.

Figure 2. 4-Level I/O Control on DS125DF111EVM

www.ti.com

Setup

SNLU158A–January 2014–Revised January 2016

DS125DF111EVM Evaluation Board

5.1.1 Pin Control Mode Configuration

The DS125DF111EVM is shipped ready-to-use in pin control mode. The EVM requires the following power

supply inputs and jumper settings:

1. J17 – GND

2. J19 – VIN to VIH: 3.3 V supply operation (2.5 V internal regulator is enabled)

3. J15 – VIN = 3.3 V: Use internal regulator to convert 3.3V supply to internal supply level of 2.5 V

NOTE: The 2.5 V level may be observed on J18 (VDD) or the device VDD pins. While in 3.3 V mode,

J18 (VDD) is a regulated output voltage. Do not connect a 2.5 V supply to this pin.

4. J3 – ENSMB = 1 kΩto GND (L): Pin Control Mode

5. J6 – LBK = 1 kΩto VIN (H): Normal operation, INA - to - OUTA and INB - to - OUTB

6. J91 – VODA = 1 kΩto GND (L): 600 mV output VOD on OUTA

7. J10 – VODB = 1 kΩto GND (L): 600 mV output VOD on OUTB

8. J41 – DEMA = 1 kΩto GND (L): 0 dB de-emphasis on OUTA

9. J51 – DEMB = 1 kΩto GND (L): 0 dB de-emphasis on OUTB

10. J161 – LOCK: With shunt installed, LOCK LED will light Green when DS125DF111 CDR is in the

locked state

5.1.2 VOD and De-Emphasis

The DS125DF111EVM uses pin strapping to define the VOD and DE level of the outputs. These are set

by the following jumpers on the DS125DF111EVM:

• VODA – J9 / J91

• VODB – J10

• DEMA – J4 / J41

• DEMB – J5 / J51

See Table 2 and Table 3 for a complete list of VOD and DE settings.

Table 2. DS125DF111 VOD Levels

VODA/B Bit 2,

sel_vod[2] Bit 1,

sel_vod[1] Bit 0,

sel_vod[0] Output VOD (mVppd)

0 0 0 0 600

R0 0 1 700

0 1 0 800

0 1 1 900

F 1 0 0 1000

11 0 1 1100

1 1 0 1200

1 1 1 1300

Table 3. DS125DF111 DEM Levels

DEMA/B Reg 0x15

Bit [2] Reg 0x15

Bit [1] Reg 0x15

Bit [0] Reg 0x15

Bit [6] De-Emphasis (dB)

00 0 0 0 0.0

0 0 1 1 -0.9

0 0 1 0 -1.5

0 1 0 1 -2.0

0 1 1 1 -2.8

1 0 0 1 -3.3

Setup

www.ti.com

8SNLU158A–January 2014–Revised January 2016

Submit Documentation Feedback

DS125DF111EVM Evaluation Board

Table 3. DS125DF111 DEM Levels (continued)

DEMA/B Reg 0x15

Bit [2] Reg 0x15

Bit [1] Reg 0x15

Bit [0] Reg 0x15

Bit [6] De-Emphasis (dB)

0 1 0 0 -3.5

1 0 1 1 -3.9

1 1 0 1 -4.5

0 1 1 0 -5.0

1 1 1 1 -5.6

1 0 0 0 -6.0

1 0 1 0 -7.5

1 1 0 0 -9.0

1 1 1 0 -12.0

5.1.3 Equalization

There are no pin control settings for the input equalization. The DS125DF111 input equalization will

automatically adapt for divide ratios 1 and 2. For divide ratios 4 and 8, a pre-set equalization level is used.

5.1.4 Loopback

J6 and J61 control the DS125DF111EVM loopback function according to Table 4.

Table 4. DS125DF111 Loopback Control

Loopback Mode of Operation IN A IN B

0 Loopback Output B Output A

R Fanout Input A Output A Output A

F Fanout Input B Output B Output B

1 Normal Operation Output A Output B

5.1.5 LOS and LOCK

• LOS Function: The LOS function monitors the input of channel A for a valid signal. When there is a

valid signal on input A the LED will light up. Channel B does not have any effect on the LOS output

signal.

• LOCK Function: The LOCK function monitors both channel A and channel B for a valid lock condition.

If either channel has a valid lock the LED will light up.

DPS-DONGLE-EVM

SMBus Pin Headers

SCL | SDA | GND

DS1xxDF111EVM

SMBus Pin Headers

SCL

SDA

GND

DPS-DONGLE-EVM

DS1xxDF111EVM

PC running either DS110DF111 or

DS125DF111 profile in SigCon Architect

www.ti.com

Setup

SNLU158A–January 2014–Revised January 2016

DS125DF111EVM Evaluation Board

5.2 SMBus Slave Mode

The SMBus can also be used to control DS125DF111 devices. This method has the advantage of

independent channel control and finer signal conditioning granularity.

1. J17 – GND

2. J19 – VIN to VIH: 3.3 V supply operation (2.5 V internal regulator is enabled)

3. J15 – VIN = 3.3 V: Use internal regulator to convert 3.3 V supply to internal supply level of 2.5 V

NOTE: The 2.5V level may be observed on J18 (VDD) or the device VDD pins. While in 3.3 V mode,

J18 (VDD) is a regulated output voltage. Do not connect a 2.5 V supply to this pin.

4. Floating the AD[1:0] inputs will result in an SMBus address = 00 = 30’h

5. J3 – ENSMB = H: SMBus Slave Mode

6. Connect the board signals SDA, SCL, and GND on J20 to a DPS-DONGLE-EVM or an equivalent

USB2ANY device. A pull-up resistor is needed on the SMBus clock and data signals; place jumpers on

pins 1-2 of J4 and J5 to connect a 1 kΩpull-up resistor to SCL and SDA. The address line settings on

J16 (ADR0) and J10 (ADR1) are pin strap settings which get latched on power up and retain their

value until the DS125DF111 is power cycled.

7. The DS125DF111's control and signal integrity settings are programmable with SigCon Architect, a

GUI which supports full register access through SMBus communication. An example of a

DS1xxDF111EVM connected to a PC through a DPS-DONGLE-EVM is shown in Figure 3 and

Figure 4. The possible SMBus address settings are shown in Table 5. For more information about

SigCon Architect, reference the "SigCon Architect: Installation and Starter's Guide" (SNLU178).

Figure 3. DS1xxDF111EVM Slave Mode Full Setup Figure 4. DS1xxDF111EVM Slave Mode Close-Up

Setup

www.ti.com

10 SNLU158A–January 2014–Revised January 2016

Submit Documentation Feedback

DS125DF111EVM Evaluation Board

(1) A floating ADDR[1:0] pin at power-up will be interpreted as a logic 0.

Table 5. SMBus Write Address Assignment(1)

ADDR1 ADDR0 SMBus Write SMBus Read

0 0 0x30 0x31

0 1 0x32 0x33

1 0 0x34 0x35

1 1 0x36 0x37

5.2.1 Register Architecture and Bit Fields

There are two types of device registers in the DS125DF111. These are the Control/Share Registers and

the Channel Registers. The Control/Share Registers control or allow observation of settings which affect

the operation of all channels of the DS125DF111. They are also used to select which channel of the

device is to be the target channel for reads from and writes to the Channel Registers.

The Channel Registers are used to set all the configuration settings of the DS125DF111. They provide

independent control for each channel of the DS125DF111 for all the configurable device characteristics.

Any registers not described in the datasheet tables should be treated as Reserved. The user should not

try to write new values to these registers. The user-accessible registers described in the datasheet provide

a complete capability for customizing the operation of the DS125DF111 on a channel-by-channel basis.

Many of the registers in the DS125DF111 are divided into bit fields. This allows a single register to serve

multiple purposes, which may be unrelated. Often configuring the DS125DF111 requires writing a bit field

that makes up only part of a register value while leaving the remainder of the register value unchanged.

5.2.2 Using SigCon Architect

SigCon Architect can be used to program the DS125DF111EVM. In order to use SigCon Architect for

SMBus Slave Mode access control, a DPS-DONGLE-EVM (see SNLU184) or USB2ANY equivalent

adapter board must be used. This adapter board serves as an interface board to allow SMBus

communication between the PC and the DS125DF111 retimer. The SigCon Architect GUI features high

level control, low level register bit level control, and an Eye Monitor page to program the device. Examples

of these pages are shown in the following figures.

Figure 5. DS125DF111 High Level Page

Inhaltsverzeichnis

Andere Texas Instruments Hauptplatine Handbücher

Texas Instruments

Texas Instruments TAS5766MDCAEVM Bedienungsanleitung

Texas Instruments

Texas Instruments DRV8300-EVM Series Bedienungsanleitung

Texas Instruments

Texas Instruments BUF20800 Bedienungsanleitung

Texas Instruments

Texas Instruments TS3A227E Bedienungsanleitung

Texas Instruments

Texas Instruments DLP3021LEQ1EVM Bedienungsanleitung

Texas Instruments

Texas Instruments TPS61059EVM-141 Bedienungsanleitung

Texas Instruments

Texas Instruments DLP LightCrafter Dual DLPC900 Bedienungsanleitung

Texas Instruments

Texas Instruments LMH9235 Bedienungsanleitung

Texas Instruments

Texas Instruments Serial Programming Adapter MSP430 Bedienungsanleitung

Texas Instruments

Texas Instruments AM263 Series Bedienungsanleitung

Texas Instruments

Texas Instruments DS90C189-Q1EVM Bedienungsanleitung

Texas Instruments

Texas Instruments TPA3220 Bedienungsanleitung

Texas Instruments

Texas Instruments CSD87381PEVM-603 Bedienungsanleitung

Texas Instruments

Texas Instruments ADS42B4x EVM Bedienungsanleitung

Texas Instruments

Texas Instruments DAC3152EVM Bedienungsanleitung

Texas Instruments

Texas Instruments AN-1870 LM26420 Bedienungsanleitung

Texas Instruments

Texas Instruments Peripheral Explorer Kit Bedienungsanleitung

Texas Instruments

Texas Instruments LP8862-Q1EVM Bedienungsanleitung

Texas Instruments

Texas Instruments FDC1004QEVM Bedienungsanleitung

Texas Instruments

Texas Instruments CC112 Series Bedienungsanleitung

Texas Instruments

Texas Instruments TPSM8286 AA0 Series Bedienungsanleitung

Texas Instruments

Texas Instruments GC5325 Bedienungsanleitung

Texas Instruments

Texas Instruments TLV3607 Bedienungsanleitung

Texas Instruments

Texas Instruments MCF8316A Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
