Getting Started

The EVM ships with a Power On Self Test (POST)

flashed into I2C EEPROM. The POST automati-

cally executes when the board is powered ON.

POST performs memory test and internal EMAC

loopback test. At power ON, the user LEDs are

OFF by default. The LEDs blink and turn OFF to

indicate successful DSP booting.

After booting, User LED-1 turns ON to indicate

successful RAM test and User LED-2 turns ON to

indicate successful internal EMAC loop-back

test. These LEDs remain ON to indicate success

of both the tests.

Please refer to the EVM User Guide for software

installation and other details.

Important Notes when handling the

EVM

•Plug in all the cables before powering ON the

EVM to ensure proper grounding.

•Do not unnecessarily flex the boards, while

inserting cables. Excessive flexing can break

the PCB traces.

•Use proper ESD procedures when handling the

EVM.

•Warning: Some components on the EVM may

be too hot to touch with your bare hand when

power is on.

Online Documentation

•TMS320C6670 processor website

http://focus.ti.com/docs/prod/folders/print/tm

s320c6678.html

•MCSDK website for updates

http://focus.ti.com/docs/toolsw/folders/print/

bioslinuxmcsdk.html

•CCS v5

http://processors.wiki.ti.com/index.php/Categ

ory:Code_Composer _Stu dio_v5

C6670 EVM Information:

http://www.advantech.com/Support/TI-

EVM/default.aspx

This link contains

•Hardware & Software details

•User Guide

•Technical Reference Manual

•TMS320C6670 Datasheet

C6670 EVM Support:

Please write to

[email protected] for

technical queries related to this EVM.

Advantech Address:

Advantech Co., Ltd.

No. 1, Alley 20, Lane 26, Rueiguang Rd., Neihu

Dist., Taipei 114, Taiwan, R. O. C.

Toll Free: 0800-777-111

Phone:886-2-2792-7818

http://www.advantech.com/

TI Worldwide Technical Support

Internet

TI Semiconductor Product Information Center Home Page

support.ti.com

TI Semiconductor KnowledgeBase Home page

support.ti.com/sc/knowledgebase

Product Information Centers

Americas

Phone +1(972) 644-5580 Fax +1(972)927-6377

Internet/Email support.ti.com/sc/pic/americas.htm

Europe, Middle East and Africa

Phone

European Free Call 00800-ASK-TEXAS

(00800 275 83927)

International +49 (0) 8161 80 2121

Russian Support +7 495 981 0701

Note: The European Free Call (Toll Free) number is not active in

all countries. If you have technical difficulty calling the free call

number, please use the international number above.

Fax +(49) (0) 8161 80 2045

Internet support.ti.com/sc/pic/euro.htm

Japan

Fax

International +81-3-3344-5317

Domestic 0120-81-0036

Internet/Email

International support.ti.com/sc/pic/japan.htm

Domestic www.tij.co.jp/pic

Asia

Phone

International +91-80-413816651-

Domestic Toll-Free-Number

Australia 800-999-084

China 800-820-8682

Hong Kong 800-96-5941

India 1-800-425-7888

Indonesia 001-803-8861-1006

Korea 080-551-2804

Fax +886-2-2378-6808

Email [email protected]

[email protected]

Internet support.ti.com/sc/pic/asia.htm

Important Notice: The products and services of Texas

Instruments Incorporated and its subsidiaries described herein

are sold subject to TI's standard terms and conditions of sale.

Customers are advised to obtain the most current and complete

information about TI products and services before placing

orders. TI assumes no liability for applications assistance,

customer's applications or product designs, software

performance, or infringement of patents. The publication of

information regarding any other company's products or services

does not constitute TI's approval, warranty or endorsement

thereof.

The floating bar is a trademark of Texas Instruments.

All other trademarks are the property of their respective owners

Toll-Free-Number

Malaysia 1-800-80-3973

New Zealand 0800-446-934

Philippines 1-800-765-7404

Singapore 800-886-1028

Taiwan 0800-006800

Thailand 001-800-886-0010

Open the web browser, copy the

IP address 172.17.10.76) from step

4 to the web browser.

The TMDSEVM6670L (Evaluation Module) kit includes:

• TMS320C6670 Evaluation Module

• Power adapter and power cord

• USB cable for on-board JTAG emulation (XDS100v1)

• Ethernet cable

• RS-232 serial cable

• Software (DVD) and documentation

TMDSEVM6670L

TMS320C6670 Evaluation Module

DC 12V

DDR3 1333

512 MB

60-pin TI

DSP JTAG

On-Board RS-232

Serial Port

AMC

Type B+

C6670

(4 core DSP)

NAND Flash

64 MB

Hyperlink

Connector

Giga

Ethernet

80-pin

header

FPGA

USB

mini-B

Boot Mode /

Configuration

Setting

Note:

1. Additionally, this EVM has two boot modes settings, Power-On Self Test (POST) boot and Linux OOB Demo boot.

The settings of the EVM configuration switches (SW3, SW4, SW5 and SW6) for power-on self test boot is shown as

left figure and Linux OOB Demo boot is shown as right figure.

Press the RESET_FULL after changing switch settings and follow HyperTerminal and webpage settings in Step 4

and 5.

2. Follow the READ_ME_FIRST instructions for installing tools, MCSDK 2.0 and demos on your PC.

3. Refer to the Getting Started Guide under MCSDK for details on boot configurations.

4. Visit the following website for the latest MCDSK updates:

5. http://focus.ti.com/docs/toolsw/folders/print/bioslinuxmcsdk.html

Open HyperTerminal, select COM

port, configure settings.

Press the RESET_FULL button on the

EVM.

Allow 40 seconds for the BIOS

Out-Of-Box (OOB) Demo to

complete booting.

The demo acquires an IP address

from server and displays it on

console.

Copy the Network Added: Inf-1: IP

address from HyperTerminal

screen.

Insert the DVD and load the USB

COM driver by executing the

program \drivers\DPlnst32.exe.

Connect the USB mini-B cable to

USB1, Ethernet cable to Ethernet

port (LAN1) and 12V DC power

adapter to power jack.

Ensure EVM configuration switch

(SW3, SW4, SW5 and SW6) are set

as shown.

Power-On Self Test (POST) boot Linux OOB Demo boot

SW3 SW4 SW5 SW6
