Preface

Read This First

About This Manual

This User’s Guide describes the characteristics, operation, and use of the

TPS65011EVM-049 evaluation module (EVM), which helps you evaluate

and test the various operating modes of the TPS65011. The guide includes

setup instructions for the hardware and software, a schematic diagram, a

bill of materials (BOM), and PCB layout drawings for the evaluation

module.

How to Use This Manual

This document contains the following chapters:

❏Chapter 1 – Introduction

❏Chapter 2 – Setup

❏Chapter 3 – Board Layout

❏Chapter 4 – Schematic and Bill of Materials

Related Documentation From Texas Instruments

TPS65011 Data Sheet (SLVS501)

If You Need Assistance

Please contact your local TI sales representative.

FCC Warning

This equipment is intended for use in a laboratory test environment only. It

generates, uses, and can radiate radio frequency energy and has not been

tested for compliance with the limits of computing devices pursuant to

subpart J of part 15 of FCC rules, which are designed to provide

reasonable protection against radio frequency interference. Operation of

this equipment in other environments may cause interference with radio

communications, in which case the user at his own expense will be

required to take whatever measures may be required to correct this

interference.

vii

Contents

Read This First ................................................................................................................... v

About This Manual ....................................................................................................... v

How to Use This Manual .............................................................................................. v

Related Documentation From Texas Instruments........................................................ v

If You Need Assistance................................................................................................ v

FCC Warning ............................................................................................................... v

Contents ........................................................................................................................... vii

Figures .............................................................................................................................. vii

Tables................................................................................................................................ vii

Introduction ..................................................................................................................... 1-1

1.1 Requirements .................................................................................................... 1-2

Setup ................................................................................................................................ 2-1

2.1 Input/Output Connectors ................................................................................... 2-2

2.2 Setup ................................................................................................................. 2-3

Board Layout...................................................................................................................3-1

3.1 Layout................................................................................................................ 3-2

Schematic and Bill of Materials ..................................................................................... 4-1

4.1 Schematic.......................................................................................................... 4-2

4.2 Bill of Materials.................................................................................................. 4-2

Figures

Figure 3-1. Assembly Layer. .......................................................................................... 3-2

Figure 3-2. Top Layer Routing ....................................................................................... 3-3

Figure 3-3. Layer 2 Routing............................................................................................ 3-3

Figure 3-4. Layer 3 Routing............................................................................................ 3-4

Figure 3-5. Bottom Layer Routing ................................................................................. 3-4

Figure 4-1. TPS65011EVM-049 Schematic....................................................................4-2

Tables

Table 2-1. Input/Output Connectors..............................................................................2-2

Table 4-1. Bill of Materials.............................................................................................. 4-2

viii

1-1

Chapter 1

Introduction

The Texas Instruments TPS65011EVM-049 is an integrated power and

battery management integrated circuit for applications that are powered

with one Li-Ion or Li-Polymer cell and require multiple power rails. The

TPS65011 contains two highly efficient switching step-down converters,

two LDOs, a battery charger, and additional status and I/O pins. You

control the device via an I2C interface.

Topic Page

1.1 Requirements 1-2

Introduction

1-2

1.1 Requirements

To operate this EVM properly, you must connect and properly configure the

following components:

❏Personal computer

A computer with a USB port is required to operate this EVM. The

TPS65011 interface software runs on the PC and communicates with

the EVM via the PC USB port. You can send commands to the EVM

and read the contents of the TPS65011 internal registers through the

USB port.

❏Printed circuit board assembly

The TPS65011EVM-049 PCB contains the TPS65011 IC and its

required external components. This board contains several jumpers

and connectors that enable you to customize the board for specific

operating conditions.

❏USB to I2C interface board (EV2300)

The EV2300 is the link that allows the PC and the EVM to

communicate. One end of the EV2300 connects to the PC with the

supplied USB cable; the other end of the EV2300 connects to the EVM

with the supplied Molex cable.

QWhen you write a command to the EVM, the interface program run

from the PC sends the command to the PC USB port. The EV2300

receives the USB command, converts the signal to an I2C protocol,

and sends the I2C signal to the TPS65011 board.

QWhen you read a status register from the EVM, the PC sends a

command to read a register on the EVM. When the EVM receives

the command, it reports the status of the register via the I2C

interface. The EV2300 receives the information on the I2C

interface, converts it to a USB protocol, and sends it to the PC.

Software

Texas Instruments has provided software to assist you in evaluating

this EVM. When downloading software from TI’s website:

1) Download the master installation file (SLVC021.zip).

2) Unzip the files to a temporary directory.

3) Run the START.bat to start the installation menu.

4) Install the TPS65010EVM controller program first. Note that the

TPS65010EVM controller program is used for both the TPS65010

and TPS65011 EVMs.

5) Install the USB drivers next. (Be sure that the EV2300 board is not

connected to your computer).

Note: Additional manual installation instructions are in the

drivers\readme.txt file.

Inhaltsverzeichnis

Andere Texas Instruments Hauptplatine Handbücher

Texas Instruments

Texas Instruments TSW1405EVM Bedienungsanleitung

Texas Instruments

Texas Instruments INA232EVM Bedienungsanleitung

Texas Instruments

Texas Instruments DLP LightCrafter 4500 Betriebsanleitung

Texas Instruments

Texas Instruments LMX2615EVM-CVAL Bedienungsanleitung

Texas Instruments

Texas Instruments WL1837MODCOM8I Bedienungsanleitung

Texas Instruments

Texas Instruments TPA0253EVM Bedienungsanleitung

Texas Instruments

Texas Instruments ADS1158EVM Bedienungsanleitung

Texas Instruments

Texas Instruments ADS130E08 Bedienungsanleitung

Texas Instruments

Texas Instruments TPS2595EVM Bedienungsanleitung

Texas Instruments

Texas Instruments PCA9306 Bedienungsanleitung

Texas Instruments

Texas Instruments Tiva C Series Bedienungsanleitung

Texas Instruments

Texas Instruments LMK00101BEVAL/NOPB Bedienungsanleitung

Texas Instruments

Texas Instruments TPS60120EVM-174 Bedienungsanleitung

Texas Instruments

Texas Instruments AIC111EVM Bedienungsanleitung

Texas Instruments

Texas Instruments DAC8541EVM Bedienungsanleitung

Texas Instruments

Texas Instruments UCC5870QDWJEVM-026 Bedienungsanleitung

Texas Instruments

Texas Instruments TMS320DM6446 DVEVM v2.0 Bedienungsanleitung

Texas Instruments

Texas Instruments AFE8201EVM Bedienungsanleitung

Texas Instruments

Texas Instruments Stellaris LM3S6965 Bedienungsanleitung

Texas Instruments

Texas Instruments INA220 Bedienungsanleitung

Texas Instruments

Texas Instruments TS3A227E Bedienungsanleitung

Texas Instruments

Texas Instruments TPS56221EVM-579 Bedienungsanleitung

Texas Instruments

Texas Instruments TRF370 Series Bedienungsanleitung

Texas Instruments

Texas Instruments AM574 Series Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
