1 Introduction

1.1 Description

1.2 EVM Specifications

User's GuideSLOU230 – December 2008

TPA6132A2 EVM

Contents1 Introduction ................................................................................................................... 12 Operation ..................................................................................................................... 23 Reference ..................................................................................................................... 34 TPA6132A2EVM Bill of Materials .......................................................................................... 6

List of Figures

1 Top Layer ..................................................................................................................... 42 Bottom Layer ................................................................................................................. 5

List of Tables

1 Gain Setting .................................................................................................................. 22 TPA6132A2EVM Bill of Materials .......................................................................................... 6

This section provides an overview of the Texas Instruments (TI) TPA6132A2 DirectPath™ stereoheadphone amplifier evaluation module (EVM). It includes a brief description of the module and a list ofEVM specifications.

The TPA6132A2 is a DirectPath™ stereo headphone amplifier capable of delivering 25 mW/Ch into 16 Ωand requires no output DC blocking capacitors.

The TPA6132A2 EVM is a complete, stand-alone audio board. It contains the TPA6132A2 QFN (RTE)DirectPath™ stereo headphone amplifier. All components are Pb-free.

Supply voltage range, V

2.5 V to 5.5 VSupply current, I

0.5 A, maximumContinuous output power, P

, V

= 5 V, 16 Ω, THD+N = 1 % 25 mW

DirectPath is a trademark of Texas Instruments.

SLOU230 – December 2008 TPA6132A2 EVM 1Submit Documentation Feedback

2 Operation

2.1 Quick-Start List for Stand-Alone Operation

2.1.1 Power and Ground

2.1.2 Inputs and Outputs

2.1.2.1 Audio

2.1.2.2 Shutdown Controls

2.1.3 Gain Setting

2.1.4 Power Up

Operation

www.ti.com

This section describes how to operate the TPA6132A2EVM.

Use the following steps when operating the TPA6132A2EVM stand alone or when connecting the EVMinto an existing circuit.

1. Ensure that the external power sources are set to OFF.2. Set the power supply voltage between 2.5 V and 5.5 V. When connecting the power supply to theEVM, first connect the ground connection to the GND connector, and then connect the positive supplyto the V

connector. Verify that the connections are made to the correct banana jacks.

1. Ensure that the audio source is set to the minimum level.2. Connect the audio source to the inputs, INL and INR. Shunt JP1 and JP2 for single-ended input.3. Connect a headset or other load to the headphone jack.

1. Shutdown is controlled by pushbutton S1. Press and hold S1 to place the TPA6132A2 in shutdown.Release S1 to reactivate the TPA6132A2.

Set the gain of the TPA6132A2 at jumpers G0 and G1 according to the follow table:

Table 1. Gain Setting

G1 G0 GAIN (dB)

0 0 -60 1 01 0 31 1 6

1. Verify the correct connections as described in Sections 2.1.1 and 2.1.2.2. Verify the correct voltage setting of the power supply and turn ON the power supply. Proper operationof the EVM should begin.3. Adjust the audio signal source as needed.

TPA6132A2 EVM2 SLOU230 – December 2008Submit Documentation Feedback

3 Reference

3.1 TPA6132A2EVM Schematic

OUT

3.5mm

5 6 78

1516

TPA6132A2RTE

INL+

INR+

INR-

OUTR

HPVSS

CPN

PGND

CPP

HPVDD

INL-

OUTL

SGND

AVDD

0603

1.0ufd/10V

GND

100K

0603

1.0ufd/10V

0603

0.1ufd/16V

2mm

HPVDD

HPVSS

OUTL

OUTR

GND

0603

2.2ufd/10V

0603

1206

DNP

1206

GND

0.5in

GND

0.5in

GND

0.5in

GND

0.5in

GND

RCA (Red)

INR

0603

1.0ufd/10V

1.0ufd/10V 0603

JP1

GND

JP2 2

GND

INL

RCA (Black)

VDD

Vdd

GND

STANDOFFS

www.ti.com

Reference

This section includes the EVM schematic, board layout reference, and parts list.

SLOU230 – December 2008 TPA6132A2 EVM 3Submit Documentation Feedback

3.2 TPA6132A2EVM PCB Layers

Reference

www.ti.com

Figure 1. Top Layer

4TPA6132A2 EVM SLOU230 – December 2008Submit Documentation Feedback

www.ti.com

Reference

Figure 2. Bottom Layer

SLOU230 – December 2008 TPA6132A2 EVM 5Submit Documentation Feedback

4 TPA6132A2EVM Bill of Materials

TPA6132A2EVM Bill of Materials

www.ti.com

Table 2. TPA6132A2EVM Bill of Materials

Manufacturer/Qty. Reference Description SND Size

Part Number

C1, C2, C3, C4, Panasonic6 Capacitor, ceramic, 1 µF, 10 V, X5R 0603C5, C6 ECJ-1VB1A105K

Panasonic1 C7 Capacitor, ceramic, 0.1 µF, 16 V, X7R 0603

ECJ-1VB1C104K

muRata2 C8, C9 Capacitor, ceramic, 2.2 µF, 10 V, X7R 0603

GRM188R71A225KE15DEN, GND,

HPVDD, Keystone7 PC test point, whiteHPVSS, OUTL, 5002OUTR

Johnson Components2 GND,VDD Binding post, 15a, uninsulated

111-2223-001

Norcomp2 G0,G1 Header, 3 pin, PCB 2.0mm ROHS

26630301RP2G0, G1, JP1, Norcomp4 Shunt, black au flash 2 mmJP2 800-002-SP2-001HW1, HW2, Building Fasteners4 Hex nut, 4-40, zinc/steelHW3, HW4 HNZ440HW1, HW2, Keystone Electronics4 Standoff, 4-40 threaded M/F 0.50 in. ALUM-HEXHW3, HW4 8401

Switchcraft2 INL, INR Jack, RCA black, PCB-ra ROHS

PJRAN1X1U01XJP1, JP2, G1, Norcomp4 Header, 2 pin, PCB 2 mm ROHSG0 26630201RP2

Kycon, Inc., P/N1 OUT Jack, mini-stereo, PCB-ra, 3.5 mm ROHS

STX-3000

Panasonic1 R1 Resistor, 100 k Ω, 1/10 W, 5%, SMD, ROHS 0603

ERJ-3GEYJ104V

Panasonic1 S1 Momentary switch, SMT-short, black tab, 160g

EVQ-PPBA25

Texas Instruments1 U1 DirectPath headphone amplifier QFN 16 (RTE)

TPA6132A2RTE

TPA6132A2 EVM6 SLOU230 – December 2008Submit Documentation Feedback
