Thinkware BAB-95 Bedienungsanleitung

Quick Start Guide & Warranty

BAB-95

External Battery for Dash Cams

Ver. 1.0 (2022)

www.thinkware.com

Quick Start Guide

& Warranty

This product is an external power supply, which is used to provide

extended dash cam recording when the vehicle is parked,

without depleting or damaging the vehicle's battery.

This manual outlines the basic steps required

to install and use the external battery.

CONTENTS

English............................................................................................................................. 3

Français ........................................................................................................................... 19

Deutsch........................................................................................................................... 35

󴀩󴉅󸑣󶘮󱠅󱙆󳽳

Quick Start Guide

& Warranty

English

FCC

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired

operation.

FCC Compliance Statement

Note : This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur

in a particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment o and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

- This appliance and its antenna must not be co-located or operation in conjunction with any other antenna

or transmitter.

- A minimum separation distance of 20 cm must be maintained between the antenna and the person for

this appliance to satisfy the RF exposure requirements.

Caution : Any changes or modications to the equipment not expressly approved by the party responsi-

ble for compliance may void your permission to operate the equipment.

Note : This unit was tested with shielded cables on the peripheral devices.

Shielded cables must be used with the unit to insure compliance.

This Class A digital apparatus complies with Canadian ICES-003

English

Safety Information

Read and follow the safety information to safely use this product. If the instructions are not followed, the

product's performance may degrade, or it may overheat, ignite, or explode and result in injury or property

damage.

WARNING

Periodically inspect the product for proper operation. Incorrect wiring or aged and damaged cables

may cause a re.

yStop using the product immediately and contact the customer service center if you smell smoke or

strange odors coming from the product or the cables connected to the product.

yStop using the product immediately and replace the product or cables if you see the product or its

cables swelling or overheating.

yStore and use this product out of the reach of children or pets.

CAUTION

To avoid injury or damage to the product, follow these instructions when installing and using this

product.

yKeep the product away from moisture and direct sunlight, and do not expose the product to physical

impacts.

yDo not use this product for any purpose other than its intended use.

yDo not try to repair or modify the product. Unauthorized disassembly, repair, or modication of the

product will void the product’s warranty.

yDo not apply excessive pressure to the product or puncture the product with sharp objects.

yDo not place the product inside a microwave oven, or expose it to high pressure.

yUse only approved cables provided by the manufacturer when installing the product.

yEnsure that the product’s contacts do not come into contact with conductive materials, such as metal.

yDo not use the product in an environment where the product’s internal circuit may be aected by

static or electromagnetic waves.

Included items

Open the package and ensure that the following items are included.

External battery Charging cable Output cables Communication

extension cable

Fuse holder (3 types) Fuse (3 types) Velcro tape Quick start guide

Part names

Refer to the following gures for the location of connectors and indicators on the product.

Charging cable

connector

Operation/

Charging indicator

Extension battery

connector

Output cable

connector

USB connector

Power

switch

Place velcro

tape here.

Communication connector

ACC IN

Power connector

English

Operation modes depending on the power switch settings

Power switch setting Operation mode

LOW HIGH Normal-speed charge ON (6.5 A)

LOW HIGH Power OFF

LOW HIGH High-speed charge ON (8.5 A)

Caution - When setting the power switch

Set the power switch to HIGH (high-speed charge) when you use the charging cable for the fuse box. It

will take more time to fully charge if the power switch is set to LOW (normal-speed charge).

Product features

• With its 8.5 A high-speed charging, the external battery is capable of operating a dash cam

for up to 27 hours on approximately 50-minute charge (based on a power consumption rate

of 3.5 Wh).

• The charge pump and constant voltage/current circuits integrated into the product are

capable of fully charging and maintaining the external battery in optimal conditions

(maintains over 80% capacity after 1,500 cycles).

• The MCU-controlled battery management system in the external battery safely and precisely

controls the charge current and voltage, and the voltage balance between the battery cells.

• The thermal protection feature stops charging when the battery temperature reaches or

exceeds 176°F (80°C). If the input terminal is connected wrongly, such as by connecting the

continuous power (B+) and GND the other way, the device automatically stops battery output

to protect itself.

• The device automatically stops battery output when short circuits are detected between the

power terminals (B+, ACC) and the ground (GND). Charge the external battery to deactivate

the protective feature if the protection mode persists.

• The device automatically stops battery output when the battery voltage drops below or

reaches 11.5 V - 10.8 V.

• Supports parallel installation of two external batteries to expand battery capacity.

(Refer to“Wiring diagram”for details.)

Caution - Before installing the external battery

• The product warranty does not cover vehicle damage or product malfunctions caused by use of

third-party cables, or by inappropriate installation conditions where the vehicle’s alternator fails to

generate sucient charging voltage or current.

• In some vehicles, the vehicle’s alternator may be overloaded and damaged by the increased current

demand when you install two external batteries in parallel.

Installing the external battery

Refer to the following steps to correctly install and use the product.

1. With the product’s power switch in the OFF position,

connect the charging cable and output cable to the

product’s cable connectors. Output cable

Charging cable

2. Open your vehicle’s fuse box, check the fuse standard,

and select the correct fuse holder between the included

fuse holders.

Note

The fuse box location in the vehicle may vary depending

on the manufacturer and model of your vehicle. For more

information, refer to your vehicle’s manual.

3. In the fuse box, locate and remove the fuses for the

continuous power (B+) and the accessory power supply.

yThe continuous power (B+) supply cable contacts supply

power even when the engine is turned o. Select a

continuous power supply cable that is less than 10 A.

yThe accessory power (ACC) contacts supply power only

when the engine is turned on.
