Thinkware T700 Bedienungsanleitung

This product records videos while the vehicle is operating.

Read and follow the instructions in this guide to properly use and maintain the product.

User Guide

T700

Before using the product

About the product

This product records videos while the vehicle is operating. Use this product only for reference when

investigating incidents or road accidents. This product is not guaranteed to record or process cloud data

for all events. The device may not record accidents with impacts that are too minor to activate the impact

sensor or accidents with massive impacts that cause the vehicle’s battery voltage to deviate.

Video recording does not begin until the product is completely turned on (booted up). To ensure that all

vehicle events are recorded, wait until the product is completely booted up after turning it on, and then

begin operating the vehicle.

THINKWARE is not responsible for any loss caused by an accident, nor is it responsible for providing any

support regarding the outcome of an accident.

Depending on the vehicle’s configuration or operating conditions, such as the installation of remote door

lock devices, ECU settings, or TPMS settings, some product features may not be supported, and different

firmware versions may influence the product’s performance or features.

About the user guide

The information provided in the guide may change when the manufacturer updates its service policy.

This user guide is intended for THINKWARE T700 models only, and it may contain technical errors, editorial

errors, or missing information.

Copyrights

All rights for the content and maps in this guide are reserved by THINKWARE and are protected under

written consent from THINKWARE is prohibited and is eligible for criminal charges.

Registered trademarks

THINKWARE T700 is a registered trademark of THINKWARE.

Other product logos and service names in this guide are trademarks of the relevant companies.

AD160016211

211-161102

D 19 0055 201

201-190188

Contents

Safety information 4

1. Product overview 7

1.1 Included items 7

1.1.1 Standarditems 7

1.1.2 Accessories(soldseparately) 7

1.2 Part names 8

1.2.1 Frontcamera(mainunit)-frontview 8

1.2.2Frontcamera(mainunit)-rearview 9

1.2.3Rearcamera 9

1.3 Removing and inserting the memory card 10

1.4 Removing and inserting the nano SIM card 10

2. Installing the product 11

2.1 Installing the front camera (main unit) 11

2.1.1 Selectinganinstallationlocation 11

2.1.2Securingtheproduct 11

2.1.3Connectingthepowercable 13

2.2 Installing the rear camera 16

2.2.1Selectinganinstallationlocation 16

2.2.2Securingtherearcamera 17

2.2.3Connectingtherearcameracable 18

3. Using recording features 19

3.1 Turning the product on or off 19

3.2 Learning about the LED indicator status and

file storage locations 19

3.3 Using the continuous recording feature 20

3.4 Recording manually 20

3.5 Using parking mode 21

3.6 Using the SOS recording feature 22

3.7 Using the Super Night Vision 23

3.8 Using the road safety features 23

4. Using THINKWARE CONNECTED LTE 24

4.1 Connecting the product to THINKWARE

CONNECTED LTE 24

4.2 Viewing the THINKWARE CONNECTED LTE

screen layout 25

5. Using the mobile viewer 26

5.1 Connect the product to a smartphone 26

5.2 Viewing the mobile viewer screen layout 26

6. Using the PC viewer 27

6.1 System requirements 27

6.2 Learning about the PC viewer 27

6.2.1InstallingthePCviewer 27

6.2.2PCviewerscreenlayout(forWindows) 28

6.2.3 Playing recorded videos on the PC

viewer(forWindows) 29

6.2.4PCviewerscreenlayout(forMac) 30

6.2.5 Playing recorded videos on the PC

viewer(forMac) 31

7. Settings 32

7.1 Managing the memory card 32

7.2 Setting the Camera 32

7.3 Setting recording features 32

7.4 Setting road safety features 33

7.5 Configuring the system settings 34

7.6 Configuring network function settings 34

8. Accessing the product information 35

8.1 Viewing the product information 35

8.2 Accessing and configuring the GPS 35

9. Upgrading the firmware 36

10. Troubleshooting 37

11. Specifications 38

Safety information

Read the following safety information to properly use the product.

Safety symbols in this guide

"Warning" - Indicates a potential hazard which, if not avoided, may result in injury or death.

"Caution" - Indicates a potential hazard which, if not avoided, may result in minor injury or property damage.

"Note" - Provides useful information to help users better utilize the product’s features.

Safety information for proper use

Driving and product operation

• Do not operate the product while driving a vehicle. Distraction while driving may cause accidents and

result in injury or death.

• Install the product in places where the driver’s view is not obstructed. Obstruction of the driver’s vision

may cause accidents and result in injury or death. Check with your state and municipal laws before

mounting the product to the windshield.

Power supply

• Do not operate or handle the power cable with wet hands. Doing so may result in electrocution.

• Do not use damaged power cables. Doing so may result in electrical fire or electrocution.

• Keep the power cable away from all heat sources. Failure to do so may cause the power cord insulation to

melt, resulting in electrical fire or electrocution.

• Use the power cable with the correct connector and make sure the power cable is connected securely

and is firmly in place. Failure to do so may result in electrical fire or electrocution.

• Do not modify or cut the power cable. Also, do not place heavy objects on the power cable or pull, insert,

or bend the power cable using excessive force. Doing so may result in electrical fire or electrocution.

• Use only genuine accessories from THINKWARE or an authorized THINKWARE dealer. THINKWARE does

not guarantee compatibility and normal operation of third-party accessories.

• When connecting the power cable to the product, ensure that the connection between the cable plug

and the power cable connector on the product is secure. If the connection is loose, the power cable may

become disconnected due to vehicle vibration. Video recording is not available if the power connector is

disconnected.

Children and pets

Ensure that the product is out of the reach of children and pets. If the product breaks, it may result in fatal

damage.

Other information about the product

Product management and operation

• Do not expose the product to direct sunlight or intense light. The lens or internal circuitry may fail

otherwise.

• Use the product at a temperature between 14°F and 140°F (-10°C to 60°C) and store the product at a

temperature between -4°F and 158°F (-20°C to 70°C). The product may not function as designed and some

permanent physical damages may result if it is operated or stored out of the specified temperature ranges.

Such damages are not covered by the warranty.

• Frequently check the product for the proper installation position. Impact caused by extreme road

conditions may alter the installation position. Ensure that the product is positioned as instructed in this

guide.

• Do not apply excessive force when pressing the buttons. Doing so may damage the buttons.

• Do not use chemical cleaners or solvents to clean the product. Doing so may damage plastic components

of the product. Clean the product using a clean, soft, and dry fabric.

• Do not disassemble the product or subject the product to impact. Doing so may damage the product.

Unauthorized disassembly of the product voids the product warranty.

• Handle with care. If you drop, mishandle, or expose the product to external shocks, it may cause damage

and/or result in the malfunction of the product.

• Do not attempt to insert foreign objects into the device. Doing so may damage the product.

• Avoid excessive humidity and do not allow any water to enter the product. Electronic components inside

the product may fail if exposed to humidity or water.

• Depending on the make and model of your car, the power may be constantly supplied to the dash cam

even when the ignition is turned off. Installation of the device to a continuously powered 12V outlet could

result in vehicle battery drainage.

• This device is designed to record video while the vehicle is in operation. The quality of the video might be

affected by weather conditions and the road environment, such as whether it is day or night, presence of

street lighting, entering/exiting tunnels, and the surrounding temperature.

• THINKWARE is NOT responsible for the loss of any recorded video during operation.

• Although the device was designed to withstand high-impact car collisions, THINKWARE does not

guarantee the recording of accidents when the device is damaged as a result of the accident.

• Keep the windshield and camera lens clean for optimal video quality. Particles and substances on the

camera lens or windshield may reduce the quality of the recorded videos.

• This device is intended to be used inside the vehicle only.

1. Product overview

1.1 Included items

Ensure that all the items are included when you open the product box.

1.1.1 Standard items

ACC

BATTERY

GND

Front camera (main unit) Mount Hardwiring cable Adhesive cable holder

MicroSD memory card

with adapter

(consumable)

Quick start guide & Warranty

/ CS information / User guide

(stored in the microSD card)

Rear camera Rear camera cable

• The standard items may change without prior notice.

• You can use the services provided by the THINKWARE CONNECTED LTE application by installing a

designated nano SIM card (sold with the product) in the product. If a SIM other than an authorized nano

SIM for the THINKWARE CONNECTED LTE application is installed, the service may not operate normally and

THINKWARE will not be responsible for any loss.

1.1.2 Accessories (sold separately)

Car charger

If the product is connected to a vehicle using the car charger, the parking mode features supported on the

THINKWARE mobile applications cannot be used.

Product overview

1.2 Part names

1.2.1 Front camera (main unit) - front view

Speaker

Outputs the voice guide and buzzer sounds

to indicate the product’s status.

Power button

• Press and hold

to turn off the

product.

• Press to turn on

the product.

Wi-Fi button

Press to connect

the product to a

smartphone via

Wi-Fi network.

Voice recording button

Press to enable or

disable voice recording.

Manual recording button

• Press to start manual

recording.

• Press to respond to

the request for device

registration on the

THINKWARE CONNECTED

LTE application.

Wi-Fi LED

• Indicates the Wi-Fi

connection status.

• Indicates the SOS

feature status.

LTE LED

• Indicates the LTE

connection status.

• Indicates the SOS

feature status.

SOS button

Press to upload the recorded footage to the THINKWARE

CONNECTED LTE application when an accident occurs.

Microphone

Used for voice recording.

Reset button

Insert the tip of a sharp object to reset the product

when an error occurs.

• To reset the product, press and hold the voice recording ( ) and manual recording (REC) buttons

simultaneously until you hear beeps.

• When you press the SOS button during an accident, the Wi-Fi LED and the LTE LED turn on and flick

simultaneously.

• According to the data service policy, if you have used all of the SOS recording upload usage times,

pressing the SOS button will save the recorded video to the SD card, but may not upload it to the

THINKWARE CONNECTED LTE application.

Product overview

1.2.2 Front camera (main unit) - rear view

DC-IN power port

Used to connect

the power cable.

V-IN input port

Used to connect

the rear camera.

Nano SIM card slot

Insert a nano SIM

card to use LTE

connection.

Memory card slot

Insert a memory card to save recordings.

Front camera lens

Records the front view.

Mount connector

Used to connect

the mount.

1.2.3 Rear camera

Adhesive mount

Used to fix the rear camera in the vehicle.

Rear camera lens

Records the rear view.

Security LED

Indicates that the video is being recorded.

Connection port

Used to connect the rear

camera to the front camera

using a rear camera cable.

Product overview

1.3 Removing and inserting the memory card

Follow the instructions to remove the memory card from the product or to insert the memory card into the

product.

Before removing the memory card, ensure that the product

is turned off. Gently push the bottom of the memory card

with your fingernail to release it, and then remove it from the

product.

To insert the memory card into the memory card slot, ensure

that the metal contacts on the memory card are facing toward

the product’s buttons, and insert it into the slot until you hear

a click.

• Ensure that the product is turned off before removing the memory card. The recorded video files may be

corrupted or lost if you remove the memory card while the product is on.

• Ensure that the memory card is in the correct direction before inserting it into the product. The memory

card slot or the memory card may be damaged if it is inserted incorrectly.

• Use only authentic memory cards from THINKWARE. THINKWARE does not guarantee the compatibility and

normal operation of third-party memory cards.

To prevent loss of recorded video files, periodically back up the video files on a separate storage device.

1.4 Removing and inserting the nano SIM card

Follow the instructions to remove the nano SIM card from the product or to insert the nano SIM card into

the product.

Before inserting the nano SIM card into the nano SIM card

slot, ensure that the metal contacts on the nano SIM card are

facing toward the product’s mount connector and then insert

it into the slot until you hear a click.

To remove the nano SIM card, ensure that the product is

turned off and gently push the bottom of the nano SIM card

with your fingernail to release it, and then remove it from the

product.

Ensure that the nano SIM card is in the correct direction before inserting it into the product. The nano SIM

card slot or the nano SIM card may be damaged if it is inserted incorrectly.

You can use the services provided on the THINKWARE CONNECTED LTE application by installing a designated

nano SIM card (sold with the product) in the product. If a SIM other than the genuine nano SIM for the

THINKWARE CONNECTED LTE application is installed, the service may not operate normally and THINKWARE

is not responsible for any loss.

Inhaltsverzeichnis

Andere Thinkware Dashcam Handbücher

Thinkware

Thinkware X550 Bedienungsanleitung

Thinkware

Thinkware F750 Bedienungsanleitung

Thinkware

Thinkware Z3000Plus Bedienungsanleitung

Thinkware

Thinkware F800pro Bedienungsanleitung

Thinkware

Thinkware DASH CAM F200 PRO Bedienungsanleitung

Thinkware

Thinkware TW-Q800PRO32C Bedienungsanleitung

Thinkware

Thinkware H100 Bedienungsanleitung

Thinkware

Thinkware iNAVI BLACK Clair2 Bedienungsanleitung

Thinkware

Thinkware F50 Bedienungsanleitung

Thinkware

Thinkware FA700 Bedienungsanleitung

Thinkware

Thinkware X330 Bedienungsanleitung

Thinkware

Thinkware F70 PRO Bedienungsanleitung

Thinkware

Thinkware FW10 Bedienungsanleitung

Thinkware

Thinkware D1K32D Bedienungsanleitung

Thinkware

Thinkware DC-E1-FG Bedienungsanleitung

Thinkware

Thinkware Q800 PRO Bedienungsanleitung

Thinkware

Thinkware BAB-95 Bedienungsanleitung

Thinkware

Thinkware X350 Bedienungsanleitung

Thinkware

Thinkware D2K64D Bedienungsanleitung

Thinkware

Thinkware F100 Bedienungsanleitung

Thinkware

Thinkware U3000 Bedienungsanleitung

Thinkware

Thinkware F70 Bedienungsanleitung

Thinkware

Thinkware X700 Bedienungsanleitung

Thinkware

Thinkware F7008 Bedienungsanleitung

Beliebte Dashcam Handbücher anderer Marken

Cansonic

Cansonic UltraDuo Z2 Bedienungsanleitung

Gazer

Gazer F720 Bedienungsanleitung

HP f500g Bedienungsanleitung

Xblitz

Xblitz TANGO 4K Bedienungsanleitung

Rexing

Rexing M1 Bedienungsanleitung

Maka Technologies

Maka Technologies Marbella MXPro Bedienungsanleitung

NESA

NESA NRC-80DLM Montage- und Bedienungsanleitung

Kaiser Baas

Kaiser Baas R20 Bedienungsanleitung

Boyo

Boyo VTM43TC Bedienungsanleitung

Minolta

Minolta MNCD37 Bedienungsanleitung

Momento

Momento MD-5200 Bedienungsanleitung

BlackVue

BlackVue DR590X-1CH Bedienungsanleitung

HP F300 Bedienungsanleitung

CammSys

CammSys BlackSys BH-300 Bedienungsanleitung

Snooper

Snooper DVR-2HD Bedienungsanleitung

Lukas

Lukas Q900 Bedienungsanleitung

RVS

RVS 450C Bedienungsanleitung

BlackVue

BlackVue 750G PRO Referenzhandbuch
