www.thinuna.com Page 3 Version A
Features：
Network power amplifier
1. The network audio power amplifier is a constant voltage power amplifier with built-in 2
channels. It is also an audio terminal encoding and decoding device that can receive network
audio sources, collect local RCA, MIC mixing input, and achieve functions such as controlling the
output audio sources of different channels;
2. Comes with dual network ports, which can be accessed from any place with an Ethernet
interface. It can play network audio and can accept access and control from servers and other IP
network devices;
3. Network fault self-diagnosis, network and service status display;
4. Powerful network audio playback function, which can be used independently in the network,
and can directly play network audio signals from IP network servers and IP network acquisition
terminals;
5. Independent power supply, independent power design is adopted for the control board and
power amplifier board, even if one fails, the normal use of the other will not be affected;
6. Strong cut function, when the fire signal is activated, it will automatically output 24V electric
signal and three-wire strong cut signal to turn on the volume controller, no need for additional
equipment;
7. 2-channel 600/450/300/150W independent power amplifier;
8. Special power amplifier detection function, the network can monitor the power amplifier
status in real time;
9. With power amplifier backup function, the system can achieve switching Master/Slave
Amplifiers automatically when one become fail.
10. With two local RCA, local MIC mixing input function;
11. No signal automatically into standby state, energy saving and environmental protection;
12. Provide complete overheating and overcurrent protection of the whole machine;
13. Work signal indicator, local volume control, color display screen;
14. Network parameters can be configured locally;
Note: Only the power is different between different models, other functions are the same,
please see the function parameters for details.
Accessory:
The product contains a separate AC power cord for powering the product.
