Thomann 278617 Bedienungsanleitung

Mini Stage Par

4×8W QCL

RGBA/RGBW 25°/40°

LED PAR

user manual

Musikhaus Thomann e.K.

Treppendorf 30

96138 Burgebrach

Germany

Telephone: +49 (0) 9546 9223-0

E-mail: [email protected]

Internet: www.thomann.de

02.12.2014, ID: 278662_278617_303022 (V2)

Table of contents

1 General notes............................................................................................................................................... 5

1.1 Further information........................................................................................................................... 6

1.2 Notational conventions.................................................................................................................... 7

1.3 Symbols and signal words............................................................................................................... 7

2 Safety instructions.................................................................................................................................. 10

3 Features....................................................................................................................................................... 14

4 Installation.................................................................................................................................................. 15

5 Starting up.................................................................................................................................................. 19

6 Connections and controls................................................................................................................... 22

7 Operation.................................................................................................................................................... 25

7.1 Starting up the device.................................................................................................................... 25

7.2 Main menu.......................................................................................................................................... 25

7.3 Menu overview................................................................................................................................. 32

7.4 Functions in 4-channel DMX mode........................................................................................... 33

7.5 Functions in 6-channel DMX mode........................................................................................... 34

Table of contents

Mini Stage Par 4×8W QCL RGBA/RGBW 25°/40°

7.6 Functions in 8-channel DMX mode........................................................................................... 35

8 Technical data........................................................................................................................................... 38

9 Plug and connection assignments.................................................................................................. 41

10 Troubleshooting...................................................................................................................................... 42

11 Cleaning....................................................................................................................................................... 44

12 Protecting the environment.............................................................................................................. 45

Table of contents

LED PAR

1 General notes

This manual contains important instructions for the safe operation of the unit. Read and follow

the safety instructions and all other instructions. Keep the manual for future reference. Make

sure that it is available to all those using the device. If you sell the unit please make sure that

the buyer also receives this manual.

Our products are subject to a process of continuous development. Thus, they are subject to

change.

General notes

Mini Stage Par 4×8W QCL RGBA/RGBW 25°/40°

1.1 Further information

On our website (www.thomann.de) you will find lots of further information and details on the

following points:

Download This manual is also available as PDF file for you to download.

Keyword search Use the search function in the electronic version to find the topics of

interest for you quickly.

Online guides Our online guides provide detailed information on technical basics

and terms.

Personal consultation For personal consultation please contact our technical hotline.

Service If you have any problems with the device the

customer service will gladly assist you.

General notes

LED PAR

1.2 Notational conventions

This manual uses the following notational conventions:

The letterings for connectors and controls are marked by square brackets and italics.

Examples: [VOLUME] control, [Mono] button.

Texts and values displayed on the device are marked by quotation marks and italics.

Examples: ‘24ch’, ‘OFF’.

1.3 Symbols and signal words

In this section you will find an overview of the meaning of symbols and signal words that are

used in this manual.

Letterings

Displays

General notes

Mini Stage Par 4×8W QCL RGBA/RGBW 25°/40°

Signal word Meaning

DANGER! This combination of symbol and signal word indicates an

immediate dangerous situation that will result in death or

serious injury if it is not avoided.

WARNING! This combination of symbol and signal word indicates a pos‐

sible dangerous situation that can result in death or serious

injury if it is not avoided.

NOTICE! This combination of symbol and signal word indicates a pos‐

sible dangerous situation that can result in material and

environmental damage if it is not avoided.

Warning signs Type of danger

Warning – high-voltage.

Warning – suspended load.

General notes

LED PAR

Warning signs Type of danger

Warning – danger zone.

General notes

Mini Stage Par 4×8W QCL RGBA/RGBW 25°/40°

2 Safety instructions

This device is intended to be used as an electronic illumination effect using LED technics. Use

the device only as described in this user manual. Any other use or use under other operating

conditions is considered to be improper and may result in personal injury or property damage.

No liability will be assumed for damages resulting from improper use.

This device may be used only by persons with sufficient physical, sensorial, and intellectual

abilities and having corresponding knowledge and experience. Other persons may use this

device only if they are supervised or instructed by a person who is responsible for their safety.

DANGER!

Danger for children

Ensure that plastic bags, packaging, etc. are disposed of properly and are not

within reach of babies and young children. Choking hazard!

Ensure that children do not detach any small parts (e.g. knobs or the like) from

the unit. They could swallow the pieces and choke!

Never let children unattended use electrical devices.

Intended use

Safety

Safety instructions

LED PAR
