Timago TGR-R RA 882 Bedienungsanleitung

INSTRUCTIONS FOR USE

Aluminium 4-wheeled rollator

Product code: TGR-R RA 882

1. Characteristics

Folding 4-wheeled rollator is made of aluminium frame which is coated

with paint with metallic lustre. The rollator possesses wide upholstered

seat, soft backrest and removable basket. The product is equipped with

height adjustable handles with anatomic handgrips and brakes with

locking mechanism. The rollator is supplied with wheels with narrow

cross section 8’’ in diameter.

The set includes:

•Two handles with brakes

•Frame with seat

•Backrest

•Basket

•Locking knobs – 2 pcs

Elements of the rollator:

a. Push handle

b. Brake

c. Locking knob

d. Brake cables

e. Backrest

f. Locking pin

g. Side crossbar

h. Hinge of side crossbar

i. Strap for folding rollator

j. Basket

k. Upper adjustment of brake

l. Lower adjustment of brake

m. Cane holder

2. Application

The rollator is designed for patients with reduced mobility who need

stable support and help while walking. It is also recommended to the

elderly as an aid in keeping balance, improving walking comfort and

ensuring safety from falling. The use of the rollator affects positively on

the return to activity of the people with locomotion and tilting to erect

position problems. It guarantees better stabilization, support and

security while walking.

3. Assembly

Unfolding and folding the rollator

•To unfold the rollator, press the side crossbar, which is placed

under the seat, until the hinges are completely unfolded. Then, fix

the handles into the mounting openings and select appropriate

height by tightening the locking knobs. Brake cables should be

placed at the front. Lean the seat against unfolded frame.

•Fix the backrest into the mounting openings at the front of the

rollator until the pins are locked.

•The basket can be hanged on the frame or fixed under the seat.

•Remove plastic casing from wheels.

•To fold the rollator for transport, lower the seat and pull upwards

the strap which joins the side crossbar with frame until the frame

is completely folded.

NOTE! Be careful while folding or dismantling the rollator due to the

risk of smashing fingers in hinges.

Brakes

•To stop the rollator, pull the brake handle upwards and hold.

•While stop or using the seat, lock the brake with locking

mechanism by pushing down the brake handle.

•To release the brake, pull the brake handle upwards.

Height adjustment of handles

•To adjust the height of the handles, unscrew the locking knobs

which are located on the outer side of the frame, select

appropriate height and tighten the locking knobs.

Note! The handles must be set on the same level.

Adjustment of brakes

Adjustment of upper brake

Unscrew the nut of the cable, pull it up to the appropriate length and

lock it by tightening the locking screw.

Adjustment of lower brake

Loosen the mounting screw with the use of open-end wrench, pull the

black brake cable to adjust the tension of the cable, and then, tighten

the mounting screw.

4. Technical data

Overall width

60 cm

Overall depth

66 cm

Seat dimensions

35 cm x 32 cm

Seat height from the ground

53 cm

Handles height adjustment

77-88 cm

Weight

8.2 kg

Maximum capacity

110 kg

Maximum capacity of the basket

5 kg

Frame colours

red, blue, titanium

5. Notes

Timago International Group does not bear responsibility of improper

use of the rollator, failure to comply safety regulations and misuse.

6. Maintenance

Cleaning

•Clean the frame with damp cloth and dry thoroughly.

•Do not use strong polishing agents due to the damage of

protecting coatings.

•Clean the dirt from moving parts of the rollator regularly (hinges,

clamping screws, locks).

7. Storage and transport conditions

Device should not be exposed to direct sunlight, water or moisture.

8. Warranty information

All products distributed by our company are covered by a warranty, the

terms of which are described in the warranty card available on our

website. Please contact the retailer from whom you purchased the

product. Please, keep in mind that for warranty purposes, the proof of

purchase (receipt or invoice) should be retained

9. Labels

Reference

number

Manufacturer

LOT number

Manufacture date

Serial number

Medical device

Note

Please read the

instruction

The manufacturer checked for compliance with

essential medical devices requirements.

Our complete line of products is available from our distributors.

Learn more at: www.timago.com. Thank you for choosing Timago!

Timago International Group

Spółka z o.o. i Spółka – Spółka komandytowa

ul. Karpacka 24/12

43-316 Bielsko-Biała, Polska

T.: +48 33 499 50 00

F.: +48 33 499 50 11

E.: info@timago.com

Rev. II, date 20.05.2021
