USER MANUAL
900 // INDUCTION HOB - SLIDE
TIS90B
IMPORTANT // Please ensure that you read through this user manual prior to installation and use. This
manual contains important information to ensure optimal performance and keep you safe. Please retain your
proof of purchase, as this will be required in the event that you require warranty service. Remember to retain
this manual for future reference.
www.tisira.com
pg 2www.tisira.com | tisira
www
.tisira.com
CONGRATULATIONS ON THE SELECTION OF THIS TISIRA APPLIANCE. TISIRA
APPLIANCES HAVE BEEN SPECIFICALLY DESIGNED FOR AUSTRALIAN AND
NEW ZEALAND KITCHENS.
Please read through this user manual carefully as it contains information that
will ensure that your appliance is installed correctly, important operating &
care instructions and also some advice of what you need to do if this appliance
is not performing as intended.
HELLO
pg 3
tisira | www.tisira.com
www
.tisira.com
CONTENTS
HELLO 2
CONTENTS 3
WARNING & SAFETY INFORMATION 4-5
PRODUCT OVERVIEW 6
OPERATING INSTRUCTIONS 7-16
COOKING GUIDELINES 17-18
MAINTAINING YOUR COOKTOP 19
ELECTRICAL CONNECTION 20
INSTALLATION 21-22
TROUBLESHOOTING 23-24
PRODUCT SPECIFICATIONS 24
NOTES 25-26
WARRANTY 27
CONTACT DETAILS 28
pg 4www.tisira.com | tisira
www
.tisira.com
WARNING &
SAFETY
INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
No combustible material or products should
be placed on this appliance at any time.
Please make this information available to the
person responsible for installing the appliance
as it could reduce your installation costs.
In order to avoid a hazard, this appliance must
be installed according to these instructions
for installation.
This appliance is to be properly installed and
earthed only by a suitably qualified person.
This appliance should be connected to a circuit
which incorporates an isolating switch providing
full disconnection from the power supply.
Failure to install the appliance correctly could
invalidate any warranty or liability claims.
HEALTH HAZARD
This appliance complies with electro-
magnetic safety standards. However, persons
with cardiac pacemakers or other electrical
implants (such as insulin pumps) must
consult with their doctor or implant
manufacturer before using this appliance
to make sure that their implants will not be
affected by the electromagnetic field. Failure
to follow this advice may result in death.
HOT SURFACE HAZARD
During use, accessible parts of this appliance
will become hot enough to cause burns.
Do not let your body, clothing or any item
other than suitable cookware contact the
ceramic glass until the surface is cool.
Never leave metal objects (such as kitchen
utensils) or empty pans on the cooktop as
they can become hot very quickly.
BEWARE // magnetisable metal objects worn
on the body may become hot in the vicinity of
the cooktop. Gold or silver jewellery will not
be affected.
Keep children away.
Handles of saucepans may be hot to touch.
Check saucepan handles do not overhang
other cooking zones that are on. Keep
handles out of reach of children.
Failure to follow this advice could result in
burns and scalds.
CUT HAZARD
The razor-sharp blade of a cooktop scraper
is exposed when the safety cover is retracted.
Use with extreme care and always store
safely and out of reach of children.
Failure to use caution could result in injury
or cuts.
CAUTION // Your safety is important to us. Please read this information before using your cooktop.
pg 5
tisira | www.tisira.com
www
.tisira.com
WARNING &
SAFETY
INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
Never leave the appliance unattended when
in use. Boilover causes smoking and greasy
spillovers that may ignite.
Do not place or leave any magnetisable
objects (e.g. credit cards, memory cards)
or electronic devices (e.g. computers, MP3
players) near the appliance, as they may be
affected by its electromagnetic field.
Never use your appliance as a work or
storage surface.
Never use your appliance for warming or
heating the room.
After use, always turn off the cooking zones
and the cooktop as described in this manual
(i.e. by using the touch controls). Do not rely
on the pan detection feature to turn off the
cooking zones when you remove the pans.
Do not allow children to play with the
appliance or sit, stand, or climb on it.
Do not store items of interest to children in
cabinets above the appliance. Children climbing
on the cooktop could be seriously injured.
Do not leave children alone or unattended in
the area where the appliance is in use.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
Do not repair or replace any part of the
appliance unless specifically recommended
in the manual. All other servicing should be
done by a qualified technician.
Do not use a steam cleaner to clean your
cooktop.
Do not place or drop heavy objects on your
cooktop.
Do not stand on your cooktop.
Do not use scourers or any other harsh
abrasive cleaning agents to clean your
cooktop, as these can scratch the ceramic
glass.
Do not operate your cooktop by means of an
external timer or separate remote-control
system.
This appliance is intended to be used in
domestic households only.
pg 6www.tisira.com | tisira
www
.tisira.com
PRODUCT OVERVIEW
TOP VIEW
CONTROL PANEL
0 5 9 12 15
BOOST
BOOST
0 5 9 12 15
1. Max. 1800/3000 W zone
2. Max. 1800/3000 W zone
3. Max. 3000/4000 W zone
4. Max. 1400/2000 W zone
5. Flexible zone. 3000/4000 W
6. Glass plate
7. Control panel
2
2
5
5
1
1
1
6
6 7 8 9
3
3
4
7
4
1. Heating zone selection controls
2. Timer control
3. Boil-assist control
4. Keep warm control
5. Flexible zone control
6. Power/Timer slider touch control
7. Boost control
8. Keylock control
9. ON/OFF control
pg 7
tisira | www.tisira.com
www
.tisira.com
OPERATING
INSTRUCTIONS
WARNING
Do not cook on a broken or cracked cooktop.
If the cooktop surface should break or crack, switch the appliance off immediately at the mains power
supply (wall switch) and contact a qualified technician.
Take care, panel edges can be sharp. Failure to use caution could result in injury or cuts.
A WORD ON INDUCTION COOKING
Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by
electromagnetic vibrations generating heat directly in the pan, rather than indirectly heating through
the glass surface. With induction, the glass becomes hot only because the pan eventually warms it up.
BEFORE USING YOUR NEW INDUCTION HOB
Read this guide, taking special note of the ‘Safety Warnings’ section.
Remove any protective film that may still be on your Induction hob.
USING THE TOUCH CONTROLS
The controls respond to touch, so you don’t need to apply
any pressure.
Use the ball of your finger, not its tip.
You will hear a beep each time a touch is registered.
Make sure the controls are always clean, dry, and that there
is no object (e.g. a utensil or a cloth) covering them. Even a
thin film of water may make the controls difficult to operate.
Iron Pot
Magnetic curcit
Ceramic glass plate
Induction coil
Induced currents
pg 8www.tisira.com | tisira
www
.tisira.com
OPERATING
INSTRUCTIONS
CHOOSING THE RIGHT COOKWARE
CAUTION // Only use cookware with a base suitable for
induction cooking. Look for the induction symbol on the
packaging or on the bottom of the pan.
You can check whether your cookware is suitable by carrying
out a magnet test. Move a magnet towards the base of the
pan. If it is attracted, the pan is suitable for induction.
If you do not have a magnet:
1. Put some water in the pan you want to check.
2. If does not flash in the display and the water is heating,
the pan is suitable.
Cookware made from the following materials are not suitable:
pure stainless steel, aluminium or copper without a magnetic
base, glass, wood, porcelain, ceramic, and earthenware.
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the
glass, and is the same size as the cooking zone.
Always centre your pan on the cooking zone.
Always lift pans off the ceramic hob – do not slide, or they may
scratch the glass.
USING YOUR INDUCTION HOB
TO START COOKING
1. Touch the ON/OFF control.
After power on, the buzzer beeps once, all displays show “ – “ or “ – – “, indicating
that the induction hob has entered the state of standby mode.
2. Place a suitable pan on the cooking zone that you wish to use.
Make sure the bottom of the pan and the surface of the cooking zone are
clean and dry.
INSTRUCTIONS
INSTRUCTIONS
SUITABLE PAN DIMENSIONS
COOKING ZONE THE BASE DIAMETER OF INDUCTION COOKWARE
Minimum (mm) Maximum (mm)
1,2 140 220
3 180 300
4 120 160
Flexible Zone 200 220x400
pg 9
tisira | www.tisira.com
www
.tisira.com
OPERATING
INSTRUCTIONS
3. Touch the heating zone selection control,
and an indicator will flash.
4. Adjust the heat setting by sliding the
slider control.
NOTICE // If you don’t choose a heat setting
within 1 minute, the Induction hob will
automatically switch off. You will need to
start again at step 1. You can modify the heat
setting at any time during cooking.
IF THE DISPLAY FLASHES
This means that:
you have not placed a pan on the correct
cooking zone or,
the pan you’re using is not suitable for
induction cooking or,
the pan is too small or not properly
centred on the cooking zone.
No heating takes place unless there is a
suitable pan on the cooking zone. The display
will automatically turn off after 1 minutes if no
suitable pan is placed on it.
TO FINISH COOKING
1. Touch the heating zone selection control
that you wish to switch off.
2. Turn the cooking zone off by sliding
3. Turn the whole cooktop off by touching the
ON/OFF control.
BEWARE OF HOT SURFACES.
NOTICE // “H” will show which cooking zone is
hot to touch. It will disappear when the surface
has cooled down to a safe temperature.
pg 10 www.tisira.com | tisira
www
.tisira.com
OPERATING
INSTRUCTIONS
USING THE BOOST FUNCTION
ACTIVATING THE BOOST FUNCTION
1. Touch the heating zone selection control.
2. Touch the boost control , the zone
indicator will show “b” and the power
reaches Max.
CANCELLING THE BOOST FUNCTION
1. Touch the heating zone selection control
that you wish to cancel the boost function.
2. Touch the “Boost” control to cancel
the Boost function on the selected
zone. The cooking zone will revert to its
original setting.
NOTICE // The function can work in any
cooking zone. The cooking zone returns to its
original setting after 5 minutes. If the original
heat setting equals 0, it will return to 15 after
5 minutes.
NOTICE // The boost function can only
be activated in up to 2 zones at any one
time, you may select one zone from
the flexible area combined with one
other zone.
When zones are used at the same time
with two boost zones activated or with
their full power, the other zones will
have their power reduced to ensure
that the cooktop operates correctly.
Andere Handbücher für tIs90b
1
Inhaltsverzeichnis
Andere Tisira Kochfeld Handbücher
Tisira
Tisira TGWF31G Bedienungsanleitung
Tisira
Tisira TG60 Bedienungsanleitung
Tisira
Tisira TCK60 Bedienungsanleitung
Tisira
Tisira TCT61 Bedienungsanleitung
Tisira
Tisira TCK30 Bedienungsanleitung
Tisira
Tisira tIs90b Bedienungsanleitung
Tisira
Tisira TCT60 Bedienungsanleitung
Tisira
Tisira TCT91 Bedienungsanleitung
Tisira
Tisira TCT63E Bedienungsanleitung
Tisira
Tisira TGF63E Bedienungsanleitung
