TIVERTON AUDIO ELEMENT Elite Bedienungsanleitung

Dual-Coil PEMF System

Owner’s Manual

3 Dec 2017 V1

ELEMENT Elite

SOURCE AMPLIFIER PEMF COILS

WELCOME

…to the next advancement in PEMF devices.

Congratulations! You now own the dual-coil ELEMENT Elite

Elite by Tiverton Audio, the most powerful Pulsed ElectroMagnetic

Field (PEMF) device for home use on the market today.

Although complex in the variety of personal health benets

that can be obtained using this type of PEMF devise, the principle

of how it works is elegantly simple. A frequency, or set of

frequencies, is generated on the source devise (laptop, smart

phone, or tablet) and sent as an audio signal to the ELEMENT Elite

chassis.

The powerful amplier in the ELEMENT Elite chassis amplies

the audio signal and sends it out to the ELEMENT Elite coil

creating a magnetic eld with the frequency imbedded in it.

By putting your body in the magnetic eld, the frequency is

transferred to your body.

The concept is simple but your choices are broad. With the

ELEMENT Elite, you can choose from long, low intensity sessions

to short, deep penetrating high intensity sessions, or anything in

between.

The ELEMENT Elite also gives you the ability to run the full

range of rife frequencies, not just 50Hz or under like most

machines on the market.

WELCOME …to the next advancement in PEMF devices

Congratulations! You now own the ELEMENT, the most powerful

Pulsed ElectroMagnetic Force device on the market today.

With the ELEMENT, you can choose from long, low intensity

sessions to short, deep penetrating high intensity sessions, or any-

thing in between. The ELEMENT also gives you the ability to run

the full range of rife frequencies, not just 50Hz or under like most

machines on the market.

In the following pages, you will discover ways you can use the

ELEMENT to achieve the greatest PEMF experience.

It was our goal to create the best machine available at the most

affordable price. We believe we have done that with the ELEMENT.

CONTENTS

Introduction 2

Unpacking 3

Placement 3

System Setup 4

Guided Tour of the ELEMENT 5

Audio Sources and Software 6

System Review 8

Precautions 9

Begin a Session 9

End a Session 10

Additional Hints and Tips 10

PEMF Session Types 12

Sessions to kill pathogens 12

Sessions for cellular rebuilding 13

Precautions 14

Coil Placement 17

Troubleshooting and Service 18

Limited Warranty 18

Speciﬁcations 19

If you’re reading this

on-screen in Adobe

Acrobat / Reader, click

the Bookmarks icon at

the upper left of the

Acrobat screen.

A Table of Contents

will appear and you can

click headings to skip

directly to that section.

IF you are reading

this in Adobe®

Acrobat Reader or

Acrobat Pro, you can

simply click on a Table

of Contents entry at

left and you will be

teleported to that

page in the manual.

Contents

Unpacking.........................................4

Placement .........................................4

A Guided Tour Of the Element Elite

PEMF System ....................................5

Understanding the Element Elite

Chassis........................................... 5

Protection Mode LED Lights........ 5

Signal Type Led ............................. 6

Signal Input Connectors.............. 6

The Signal Output Connectors... 7

One-Coil & Two-Coil Operation .......7

Connection........................................8

Initial Set-Up ....................................9

The Carry Handle...........................11

Mobile Chassis ...............................11

Audio Sources and Software .........12

Choosing a Remote Device. ...........12

Review.............................................14

Precautions.....................................14

Fundamentals to Know Before

Running a Session..........................15

PEMF Session Types.................... 15

PEMF Sessions To Kill

Pathogens.................................... 15

PEMF Sessions For Cellular

Re-Building.................................. 17

PEMF Sessions For Metabolic

Disease......................................... 18

Coil Placement................................18

For Using Only One Coil ........... 18

For Using Two Coils .................... 19

Power And Duration................... 20

Begin a Session – Follow These Steps

.........................................................22

Ending A Session............................23

Additional Hints And Tips .............23

Troubleshooting and Service.........25

System Quickly Goes Into Overheat

Protect Mode (Right Led). .......... 25

Chassis Makes Loud Humming

Sound When Turned On. ........... 25

Service And Support ......................25

Limited Lifetime Warranty ............25

Specications..................................26

UNPACKING your ELEMENT PEMF System

After opening the carton, if possible keep the outer box,foam

and ﬁber packing, and plastic bag. It’s handy for moving or in the

unlikely event that your ELEMENT would need service or repair.

In the carton you will ﬁnd:

•ELEMENT Chassis. Though one of the most powerful units on

the market, the chassis is one of the smallest in size. This will

allow you to have the unit set up and ready to use at all times,

since it will comfortably fit on a nightstand or end table.

•ELEMENT Coils.Their advanced design is engineered to make

the most of the chassis’s power and abilities. Made slightly oval

to better fit over the head, and slightly curved to better comfort-

ably contour to the body, they will deliver the magnetic field

where you want it and at the levels you need it. The Coilscome

with removable, washable coversthat also helps provide

padding. The 140-inch connecting cable allows you to use Coils

up to ten feet or more from the ELEMENT chassis.

•12-foot audio cable for connecting your remote source device to

the input of the ELEMENT chassis. The ¹⁄8" stereo plugs are

compatible with the outputs of most source devices. You will

need an inexpensive, Apple Lightning®-to-¹⁄8" headphone

adaptor for newer iPhone®s.

•AC Power Cable.

PLACEMENT

of your ELEMENT PEMF System

• Use the front panel carry handle

to transport the ELEMENT chassis.

• The ELEMENT chassis should be

placed on a sturdy, well-supported

surface such as a table or night stand.

Be sure that the coil-to-chassis cord will reach to where you are

comfortable using the coil for extended periods of time.

• Make sure the back of the chassis is not closer than 1" from a

wall to avoid blocking the cooling fans' air ﬂow.

UNPACKING

your ELEMENT Elite PEMF System

After unpacking your ELEMENT Elite, if possible keep the outer

box, foam packing, and plastic bag. It’s handy for moving or in the

unlikely event that your ELEMENT Elite would need to be returned

to us for service or repair. In the carton you will nd:

■ELEMENT Elite Chassis. One of the most powerful units on the

market, the chassis is also one of the smallest in size. This allows

you to have the unit set up and ready to use at all times, since it

will comfortably t on a nightstand or end table.

■ELEMENT Elite Coils. Their advanced design is engineered to

make the most of the chassis’s power and abilities. They will

deliver the magnetic eld where you want it and at the levels you

need it. The Coils come with removable, washable covers that also

help provide padding. The twelve-foot coil lead wires allow you to

use coils up to ten feet or more from the ELEMENT Elite chassis.

■12-foot audio cable for connecting your remote source device to

the input of the ELEMENT Elite chassis. The ¹⁄8" (3.5mm) stereo

plugs are compatible with the outputs of most source devices.

You will need an inexpensive, Apple Lightning®, or USB C-to-¹⁄8"

headphone adapter for newer iPhone®s.

■AC Power Cable.

PLACEMENT

of your ELEMENT Elite PEMF System

■The ELEMENT Elite chassis should be placed on a sturdy, well-

supported surface such as a table or night stand. Be sure that the

coil lead wires will reach to where you are comfortable using the

coils for extended periods of time.

■Use the front panel carry handle

to transport the ELEMENT Elite chassis.

Coil Output connections (twist-lock).

“Signal Type” LED lights whenever there

is a magnetic eld present in coils.

Input from iPhone®, laptop or MP Player

(1/8" audio input socket).

Carry handle.

SYSTEM PROTECTION MODE LED LIGHTS:

The “amplier protect mode” (left) LED will come on for a few

seconds when you rst power up the machine. Otherwise, the red

“amplier protect mode” (left) and “system overheat protect mode”

(right) LEDs will not come on unless those issues occur.

If the amplier goes into protect mode and the LED comes on

during operation, it will reset back to normal operation within

about 30 seconds.

If the system goes into system overheat protect mode and

the right LED comes on, it will reset after cooling 15 degrees

Fahrenheit. If this should happen, the coil will most likely be

getting too hot as well. DO NOT TURN THE POWER OFF DURING

COOL DOWN. If you do, the system fans will turn off and it will

take much longer to cool.

A GUIDED TOUR of the ELEMENT Elite PEMF system

UNDERSTANDING THE ELEMENT Elite CHASSIS.

As with any sophisticated piece of equipment, it is best to rst go

over and understand all of the connections, buttons, and lights on

the front panel so you will know what the machine is doing and

how to use it properly for maximum benet. Besides…our manual

designer likes to draw arrows.

Ear Bud connection

(1/8" audio input socket).

“Protect mode” LED lights; see below for full explanation.

buds if you ever need to conﬁrm the source signal in getting to the

chassis (you will be able to hear the frequency being sent).

4As with any sophisticated piece of equipment, it is best to ﬁrst go

over and understand all of the connections, buttons, and lights on

the front panel so you will know what the machine is doing and

how to use it properly for maximum beneﬁt. Besides…our design-

er likes to draw arrows, as is evidenced below.

5Carefully read the Audio Sources and Software section beginning

on the next page for source software signal details.

Download and familiarize yourself with the software that you

have chosen. As noted above, you can test it by plugging a pair of

ear buds or headphones into the other ELEMENT audio socket.

A Guided Tour of Your ELEMENT PEMF System.

SYSTEM PROTECTION

MODE LED LIGHTS:

The two red LED

"ampliﬁer protect mode"

and "system overheat

protect" LEDs will not

come on unless these

issues occur.

Under normal con-

ditions, these lights

will never come on.

If the ampliﬁer goes

Power

LED

Ampliﬁer "protection

mode" LED lights red

when overdriving

caused ELEMENT's

ampliﬁer to go into

protection mode.

System Overheat

LED lights red when

overheating causes

ELEMENT to go into

protection mode.

System Power On LED

shines light blue when

system is on.

On top: Power Switch

Signal input / headphone

output monitor jacks.

Both sockets serve the

both purposes.

Coil Output Connection

(twist - lock)

Carry handle

CHANGE PIX

THE SIGNAL TYPE LED:

This is a current sensor so that you positively know that a signal

is going to one or both coils. When it’s lit, there is a magnetic

eld in the coils.

The SIGNAL TYPE light will come on with one of three color

options when the system senses minimum or greater current

going to the coils:

GREEN – Frequencies above 100Hz to 15kHz

GREEN/RED – Frequencies from 5Hz to 100Hz. We cut the

volume in half for this range. For these frequencies you never

need to run at full power to have maximum benet. Lowering

the volume greatly reduces the risk of over-heating the system.

RED – Frequencies that are out of range…below 5Hz or above

15 kHz (these frequencies will also be blocked so they do no

harm to the amplier)

No other PEMF machine has this valuable, common sense

feature. It actually directly senses current from the wire leading

to the coil and “reports” to the LED.

If this LED is not lit when you’re sure a signal is going to the

ELEMENT Elite (you can plug a set of earbuds into the other 1/8"

audio input socket to conrm), turn up your volume control. At

frequencies above 10,000 Hz, this LED might not light up when

the volume is too low. If there is very high frequency (above

10,000 Hz), material in the middle of a program, the light may go

out during that time, but you will still be getting a magnetic eld

in the coil.

THE SIGNAL INPUT CONNECTORS:

There are two 1/8" (3.5mm) audio sockets that can serve as either

inputs or outputs. Use one for the signal input and the other for

plugging in a set of ear buds when you want to check that the

signal is getting to the chassis (this will help in troubleshooting).

Both sockets are wired together, so it does not matter which

one you use for each function.

THE SIGNAL OUTPUT

CONNECTORS:

Each of the large coil sockets is a

bayonet-style, push-in-and-twist. It

must be twisted (clockwise) until it

clicks and latches to make good contact.

This is a heavy duty socket and it is OK

to plug or unplug it while a signal is on, if you need to, although

we recommend turning the input signal off before unplugging a

coil.

ELEMENT Elite CAN STAND UP (MOBILE OPTION ONLY):

The foot on the top rear of the chassis is for standing the unit

up and is adjustable so the unit will stand straight up. There is

no problem operating the unit standing up if you want to. When

placed on a table, the ELEMENT Elite telescoping handle adds only

about ½” to the overall height of the unit and hides completely

underneath when contracted. Important: DO NOT LIFT THE UNIT

WITH THE TELESCOPIC HANDLE. Instead, use the original handle

to lift it to and from the oor.

Be aware that if you operate it in this mode, it may kick up dust

or allergens from the oor.

ONE-COIL AND TWO-COIL OPERATION

You can use the ELEMENT Elite with one coil or both, depending

on your needs.

See the sections below on coil placement and on session type to

help you determine if using one or two coils is best for the type of

issue you wish to work on.

longer than needed.

Plug the coils into the sockets at the upper right of the ELEMENT

Elite chassis. They will only go in one way. After pushing them in

as far as they will go, twist them to the right (clockwise) until they

click and latch in place. The silver release tab should now be at

the top of the plug. To disconnect, slide the release tab away from

the chassis and twist a plug to the left (counter clockwise) until it

will pull out.

Plug one end of the 12-foot audio cable into your source device,

such as a smart phone, MP3 player, tablet or laptop. We strongly

recommend using a laptop.

Plug the other end of the audio cable into the ELEMENT Elite

chassis audio input socket. The other front panel audio socket is

for plugging in a set of ear buds if you ever need to conrm the

source signal is getting to the chassis (you will be able to hear the

frequency being sent…you will only hear it in one ear because it is a

monaural system.)

CONNECTION

of your ELEMENT Elite System

Plug the power cord into the back of the ELEMENT Elite chassis

and into a wall outlet. If an

outlet is not within reach of

the power cord make sure

any extension cord used is

rated for 15 amps and is not

Carefully read the Audio Sources and Software section beginning

on page 12 for source signal software details.

Download and familiarize yourself with the software that you

have chosen. As noted above, you can test it by plugging a pair

of ear buds or headphones into the other ELEMENT Elite audio

socket.

INITIAL SET-UP

(Only needs to be done once)

Plug in the power cord, audio cable from the laptop, and both coils

as explained in the previous steps. Push the coil plug into the jack

and turn clockwise until it latches (you should hear a click).

Open your signal generating software and set it up to play 5000 Hz

for around 2 minutes (that should be plenty of time to complete

the procedure).

Set the signal generating software to use a square wave.

Set the laptop volume all the way up.

Set the program volume all the way down.

Turn on the ELEMENT Elite. Make sure the POWER button light is

solid blue.

Start the signal generating program.



While watching the SIGNAL TYPE light, slowly increase the

volume until the light comes on green.

It may ash red for less than a second before turning green.

This is normal.

It is because the programming of the computer chip inside the

ELEMENT Elite samples at one second intervals, so depending on

the timing of that sampling there may be enough current to light

the LED but it has not yet been sampled to tell it to light green and

it defaults to red until sampled.

Save this volume setting as your “base line” volume. For most

metabolic issues, this setting should create a strong enough

magnetic eld.

You can increase the volume from there if you nd, through

experimentation, it provides improved benet.

How much higher the volume will need to be depends on the

issue you are working on.

For pathogens, you will need to increase the volume to nd the

MOR (Morbidity Osculation Rate) of the particular pathogen you

are targeting. We suggest doing so slowly over several sessions so

as to not cause a Herxheimer Reaction1that you cannot tolerate.

This initial set up only needs to be done once.

However, if you use multiple devices such as different

laptops, it should be repeated for each device.

Repeat initial set up steps any time you change devices.

1The Herxheimer Reaction is a short-term detoxification reaction in the body. As the body detoxifies, it is not uncommon to experience flu-like

symptoms including headache, joint and muscle pain, body aches, sore throat, general malaise, sweating, chills, nausea or other symptoms.

Inhaltsverzeichnis

Beliebte Netzwerk-Hardware Handbücher anderer Marken

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Bedienungsanleitung

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Bedienungsanleitung

Yudor

Yudor YDS-16 Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-320L Bedienungsanleitung

Samsung

Samsung ES1642dc Gebrauchsanweisung

Honeywell Home

Honeywell Home LTEM-PV Montageanleitung

evertz

evertz 7700 Series Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-343 Bedienungsanleitung

Asante

Asante AsanteBridge 1012 Bedienungsanleitung

FireBrick

FireBrick FB2700 Bedienungsanleitung

Audiovox Electronics

Audiovox Electronics ARWH2T Bedienungsanleitung

ADC

ADC DSX-1 Handbuch

NetComm

NetComm NF2 Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 5620 Bedienungsanleitung

Dell EMC

Dell EMC XC6420 Series Bedienungsanleitung

Lanner

Lanner NCA-1020A Bedienungsanleitung

Allied Telesis

Allied Telesis AT-TN121-A Bedienungsanleitung

Arista

Arista CCA-ETM-Q12 Bedienungsanleitung
