Tommee Tippee GroClock Bedienungsanleitung

the amazing sleep trainer

for young children

Instructions for use

The Groclock explained...

Stay in bed – When you activate your

Groclock, stars and hearts appear around

a sleeping Ollie. To show the passing of

time, the stars disappear at even times during

the sleep or nap time.

Time to get up – When the clock reaches the

wake up time that you set, the stars disappear,

and Ollie wakes up, meaning your child can get up.

After Ollie wakes up, it will remain displayed for two hours, before changing to the

energy saving mode where the digital clock is displayed until re-activated.

The Groclock has two options – night-time sleep mode and day-time nap mode.

You only need to pre-set the wake up times you want once (Step 3),

but you need to activate the clock (Step 4), each time you use it.

Daily activation of the clock soon becomes part of the bedtime routine, and

needs to be done in order to set your Groclock.

Use your bedtime story book to help explain the Groclock to your child.

What the buttons do

Enter

Settings menu

Set time

Set night–time sleep mode

Set day–time nap mode

Set audible alarm

Set LED brightness

Scroll Down

Scroll Up

To set your Groclock

Step 1 – Plug in the Groclock - the screen showing the digital clock display will appear.

Step 2 – Set the current time

1. Press the scroll down button three times until its shows the settings menu - 5 small

ﬂashing icons will appear on your screen

2. Press the enter and the clock icon will ﬂash

3. Press the enter again to select

4. Set the current time using the up and down buttons - select the hour, press enter ,

select the minutes, press enter , select am or pm, press enter

5. The word ‘On’ will appear. Scroll up or down between ‘On’ or ‘OFF’ depending on if

you want the digital clock to be visible while the count down process is happening.

Press enter .

The settings menu screen will return.

Step 3 – Set the wake-up times

You do not set a go to sleep time just the wake up time you want Ollie to wake up.

(If you are not

intending to use this product for day-time naps, set both night-time and day-time modes to the

same ‘wake up’ time).

Night-time sleep mode

1. Whilst on the settings menu screen with

the 5 icons ﬂashing, press enter button

and the clock icon will ﬂash

2. Press scroll down so the star image

is ﬂashing, press enter to select

3. Select the time that you want the

Groclock to ‘wake up’

(the time for your

child to get up e.g. 7:00 am)

Set the time using the up and down

buttons - select the hour, press enter ,,

select the minutes, press enter , select

am or pm, press enter

(ensure this is

set as AM for a morning ‘wake up’).

Day-time nap mode

1. Whilst on the settings menu screen with

the 5 icons ﬂashing, press enter button

and the clock icon will ﬂash

2. Press scroll down so the sun image

is ﬂashing, press enter to select

3. Select the time that you want the

Groclock to ‘wake up’

(the time for your

child to get up from their nap e.g. 3:00 pm)

Set the time using the up and down

buttons - select the hour, press enter ,,

select the minutes, press enter , select

am or pm, press enter .

Key lock feature

Key lock deactivates once wake up time has been reached

To switch on key lock -

When the Groclock is activated in night-time sleep or day-time nap mode, press

and hold the scroll down button until a cross appears in the big star’s cheek.

The buttons will now be locked.

To turn o key lock -

Press and hold the scroll down button until you hear a beep.

TIP: Try not to let your child see you set the key lock.

Additional features

Adjusting the brightness

The brightness level of the screen can be adjusted.

1. From the digital clock display return to the settings menu screen by pressing scroll down

three times

2. Press the enter and the clock icon will ﬂash

3. Press scroll down four times until the lightbulb ﬂashes, press enter to select

4. Scroll up and down to desired setting (0 = least bright, 10 = most bright), press enter

. For the blue light to remain o in sleep mode set this brightness setting to 0. This means

there is no visible blue light in a dark room

5. Press scroll down to display the digital clock

Setting the audible alarm

The Groclock has an audible alarm which can be set to go o at any time in any mode.

1. From the digital clock display return to the settings menu screen by pressing scroll down

three times

2. Press the enter and the clock icon will ﬂash

3. Press scroll down three times until the alarm bell ﬂashes, press enter to select

4. Select the time you wish the alarm to sound. Set the time using the up and down

buttons - select the hour, press enter , select the minutes, press enter , select am or pm,

press enter

5. The bell symbol will start to ﬂash, scroll up or down to desired setting ( = o or

= on), press enter

6. Press scroll down to display the digital clock

To turn o the audible alarm follow steps 1-4 (above) but on step 5 ensure you select the bell

symbol with the cross over it , and press enter , this will turn the audible alarm o.

To return to the screen showing the digital clock display, press scroll down .

This is the energy saving mode displayed during the day.

Step 4 – Activate your sleep trainer

when putting your child to sleep

To activate the night-time sleep mode

1. From the digital clock screen, press scroll

down , the screen will change to an

awake Ollie with a small ﬂashing star icon

(night time sleep) on the left cheek,

press enter

2. The screen will change from awake Ollie

to asleep Ollie with small stars around the

outer edge, this will now count down to

the ‘wake up’ time previously set when

the sun will come out.

To activate the day-time nap mode

1. From the digital clock screen, press scroll

down twice, the screen will change

to an awake Ollie with a small sun icon

(day time nap) on the left cheek, press

enter

2. The screen will change from awake Ollie

to asleep Ollie with small stars around the

outer edge, this will now count down to

the ‘wake up’ time previously set when

the sun will come out.

To return to the menu when the sleep trainer is activated

Press enter , Press scroll down twice, and the settings menu screen will appear. Press scroll

down to return to the digital clock.

Frequently asked questions

Q. If the power is turned o, does the clock remember the correct time?

A. When the power goes o, the clock ‘freezes’ all the settings, including

the main time, the wake up times and brightness settings. Therefore if the

power goes o for a few seconds and then back on, the time will have been

paused for a few seconds. However if the power was o say for 3 hours,

then the time will be out by 3 hours and will therefore need re–setting.

Q. If I need to keep the power on should I worry about electricity

consumption?

A. Your Groclock uses LEDs so it’s naturally energy ecient. It also has a

built–in energy saving mode.

Q. What is the dierence between the night–time and day–time nap mode?

A. The Groclock works the same way in both modes. The two modes

enable two dierent ‘wake up’ times to be stored, this does not need to be

day-time it could be an alternate night-time.

Q. Is there a demo mode so I can show my child how Ollie changes when

he wakes up?

A. Yes! To set the demo mode press and hold the scroll up button for

three seconds. To turn o the demo mode, press and hold the scroll up

button for three seconds.

Q. My screen has frozen and is not responding to the controls.

A. Switch the Groclock o at the mains, wait a few seconds and switch

back on.

For further information visit tommeetippee.com

Mayborn ANZ Pty Ltd. (ABN 66 154 703 134), PO Box 475 Mt Waverley VIC 3149, AUSTRALIA

Newborn Brands (NZ) Ltd. PO Box 47-677, Ponsonby, Auckland, 1144, NEW ZEALAND.

Mayborn (UK) Limited retains all intellectual property rights to this product.

Patent pending UK, USA and worldwide PCT patents and Design rights applied for.

Product Ref No: 291345 14171219_1

Safety

IMPORTANT WARNINGS! Keep this instruction sheet for future

reference. These instructions can also be found at www.tommeetippee.com

WARNING. LONG CABLE. STRANGULATION HAZARD.

Your

Groclock

is a safe low voltage device, powered from a small mains operated power unit.

For your continued safety and the reliability of your Groclock, please observe the

normal electrical safety precautions:

• This product is not a toy. Please ensure that it is kept out of reach of children and never allow your

child to play with either the power unit or the connecting lead

• Keep the product away from water and moisture. It’s intended for indoor use only

• Repairs should be carried out only by a competent engineer. There are no customer adjustments or

fuses inside the Groclock case

• The Groclock has been designed to be robust, but it may be broken if dropped

• The connecting lead is low voltage only, but for reliability reasons it should be treated

with care

• To completely disconnect the power unit, the AC/DC adapter must be unplugged from the mains

• Access to power to supply the AC/DC adapter should not be obstructed whilst in use

• Electro–static discharge may aect the working of your Groclock. If this occurs, simply switch the

unit o for several seconds and the unit will re–set

• The Groclock and AC/DC adaptor shall not be exposed to dripping or splashing and no objects ﬁlled

with liquids, such as vases, shall be placed on the Groclock and AC/DC adaptor

• For use only with the power cable supplied with the Groclock

Technical Information

Height: 13.9 cm

Weight: 285g

When the time comes to dispose of this equipment, please help protect our environment by means of proper disposal. Your local

authorities will have special return and disposal facilities available for you.

Information on the disposal for Waste Electrical & Electronic Equipment (WEEE)

This symbol on the products and accompanying documents means that used electrical and electronic products should not be mixed with

general household waste. For proper disposal for treatment, recovery and recycling, please take these products to designated collection

points where they will be accepted on a free of charge basis. In some countries you may be able to return your products to your local retailer

upon the purchase of a new product.

Disposing of this product correctly will help you save valuable resources and prevent any possible eects on human health and the

environment, which could otherwise arise from inappropriate waste handling. Please contact your local authority for further details of your

nearest collection point for WEEE.

Penalties may be applicable for the incorrect disposal of this product in accordance with national legislation.

Mains Supply Voltage: 230V, 50Hz.

Power Unit: 6V at 200mA.

Andere Handbücher für GroClock

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Tommee Tippee Babyaccessoires Handbücher

Tommee Tippee

Tommee Tippee closer to nature Bedienungsanleitung

Tommee Tippee

Tommee Tippee 423242 Bedienungsanleitung

Tommee Tippee

Tommee Tippee microwave steam sterilizer Bedienungsanleitung

Tommee Tippee

Tommee Tippee Day&Night Bedienungsanleitung

Tommee Tippee

Tommee Tippee Perfect Prep Day & Night Bedienungsanleitung

Tommee Tippee

Tommee Tippee Sleepee Moses Basket Bedienungsanleitung

Tommee Tippee

Tommee Tippee Express and Go Bedienungsanleitung

Tommee Tippee

Tommee Tippee Perfect Prep Day & Night Bedienungsanleitung

Tommee Tippee

Tommee Tippee twist & click Bedienungsanleitung

Tommee Tippee

Tommee Tippee ELECTRIC STEAM STERILISER Bedienungsanleitung

Tommee Tippee

Tommee Tippee colicsoothe Bedienungsanleitung

Tommee Tippee

Tommee Tippee Perfect Prep Bedienungsanleitung

Tommee Tippee

Tommee Tippee Advanced Anti-Colic Bedienungsanleitung

Tommee Tippee

Tommee Tippee Grofriend Bedienungsanleitung

Tommee Tippee

Tommee Tippee twist & click Bedienungsanleitung

Tommee Tippee

Tommee Tippee Express and GO Bedienungsanleitung

Tommee Tippee

Tommee Tippee 360 sealer Bedienungsanleitung

Tommee Tippee

Tommee Tippee Pump and Go Bedienungsanleitung

Tommee Tippee

Tommee Tippee soft sippee Bedienungsanleitung

Tommee Tippee

Tommee Tippee dreammaker Bedienungsanleitung

Tommee Tippee

Tommee Tippee 1156 Bedienungsanleitung

Tommee Tippee

Tommee Tippee Sangenic Stücklistenhandbuch

Tommee Tippee

Tommee Tippee Simplee Bedienungsanleitung

Tommee Tippee

Tommee Tippee advanced anti-colic Bedienungsanleitung

Beliebte Babyaccessoires Handbücher anderer Marken

Britax

Britax JETTA Bedienungsanleitung

Affinity

Affinity ROOKIE Bedienungsanleitung

BEBE CONFORT

BEBE CONFORT BabyFix Bedienungsanleitung

Childcare

Childcare Galaxy Bedienungsanleitung

Fisher-Price

Fisher-Price H8096 Bedienungsanleitung

Beaba

Beaba SterilExpress Bedienungsanleitung

Baninni

Baninni BABYWALKER PIO BNBW009 Bedienungsanleitung

MONTESSORI ROOM

MONTESSORI ROOM Waldorf Rocker Bedienungsanleitung

osann

osann Marty Klimax Bedienungsanleitung

Swereco

Swereco 144971 Handbuch

Leander

Leander Cradle Bedienungsanleitung

nuVita

nuVita 7530 Bedienungsanleitung

Fisher-Price

Fisher-Price R4743 Bedienungsanleitung

Fisher-Price

Fisher-Price G8684 Bedienungsanleitung

bbluv

bbluv Glüv Bedienungsanleitung

bbluv

bbluv Glüv Bedienungsanleitung

bbluv

bbluv Glüv Bedienungsanleitung

bbluv

bbluv Näj Bedienungsanleitung
