Toro 02917 Bedienungsanleitung

FormNo.3412-264RevA

RoadLightswithBrakeLightsKit

Groundsmaster®3400TractionUnit

ModelNo.02917—SerialNo.400000000andUp

InstallationInstructions

Thiskitisdesignedtoprovideafullsetofroadlightswithmountingbracketsandoperationswitches.

Installation

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescriptionQty.Use

1Nopartsrequired–Preparethemachine.

Left,rearlightbracket1

Right,rearlightbracket1

Bolt(M16x110mm)2

Nut(M16)2

Fuse(15A)2

Installtherearlights.

Dowtyseal(1/4inch)1

Pressureswitchadapter1

Pressureswitch1

3Pressureswitchcable1

Installthepressureswitch.

Numberplatebracket1

2-waytabhousingconnector1

Flasherrelay1

4Standardshorterrelay1

Installthenumberplatebracket.

Centerheadlightmount1

Rightheadlightmount1

Leftheadlightmount1

Bolt(M6x20mm)8

Locknut(M6)8

Bolt(M10x25mm)4

Locknut(M10)4

Washer(3/8inch)8

Mountingbracket2

4-waytabhousingconnector2

Installthefrontlights.

Instrumentpanelconnectorlead1

Hazardwarningswitch1

Lightsswitch1

Indicatorswitch1

Hornbutton1

Horndecal1

Cabletie24

Installthecontrolpanelswitches.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.T oro.com.OriginalInstructions(EN)

PrintedintheUK

AllRightsReserved*3412-264*A

ProcedureDescriptionQty.Use

7Reector2Installthereectors.

8Seriallabel1Installtheseriallabel.

MediaandAdditionalParts

DescriptionQty.Use

InstallationInstructions1Readbeforeinstallingandoperatingkit

PartsCatalog1Usetoreferencepartnumbers

PreparingtheMachine

NoPartsRequired

Procedure

1.Parkthemachineonalevelsurface,lowerthecutting

unit,engagetheparkingbrake,shutofftheengine,and

removethekeyfromtheignitionswitch.

2.Disconnectthenegative(–)batterycablefromthe

battery.

WARNING

Gasesthatemitfromthebatteryareexplosive.

Keepopenamesandelectricalsparkaway

fromthebattery.Whenworkingwiththe

battery,wearsafetygogglesandrubbergloves.

Donotsmoke.

InstallingtheRearLights

Partsneededforthisprocedure:

1Left,rearlightbracket

1Right,rearlightbracket

2Bolt(M16x110mm)

2Nut(M16)

2Fuse(15A)

Procedure

Note:Ifyouarettingtherearlightstoamachinewith

aserialnumberof316999999andlower,therearlight

mountingbracketsneedtobereplacedwiththebracketsthat

aresuppliedaslooseparts.

Therearlightsattachtotheoutsideoftherollbarpostson

theleftandrightsidesofthemachine.Thelightswillbe

insertedintotheexistingboltholesintherollbar.

1.Opentheenginecover.

2.Lifttheoperatorplatform.

3.Removethebulkheadbehindtheoperator’sseatby

unscrewingthe4bolts(Figure1).

Note:Removingthebulkheadenablesaccesstothe

mainwiringloom.

g018276

Figure1

1.Bulkhead2.Bolt(4)

4.Ensurethattherollbarpivotboltsandclampboltsare

inplaceandaretight,andorthesecuringpinsarein

placetoretainthetophoop.

5.Removetherollbarpivotboltontheleftsideofthe

machine.

6.Aligntheindicatedholeintheleftrearlightbracket

withtheholeintherollbarandinsertthenewbolt

(M16x110mm),usingtheexistingwashers(Figure

2orFigure3).

g197780

Figure2

Machinewithserialnumbers316999999andlower

1.Bolt(M16x110mm)4.Leftrearlightbracket

2.Existingwashers5.Rollbar

3.Orangeindicatorsideup6.Nut(M16)

g196536

Figure3

Machinewithserialnumbers400000000to999999999

1.Bolt(M16x110mm)4.Rollbar

2.Orangeindicatorsideup5.Existingwasher

3.Leftrearlightbracket6.Nut(M16)

7.Installthenewnut(M16)ontotheboltandtorqueit

to15N∙m(11ft-lb).

Note:Donotovertightenitasthiswillmaketheroll

bardifculttofold.

8.Removetherollbarpivotboltontherightsideofthe

mower.

9.Aligntheindicatedholeintherightrearlightbracket

withtheholeintherollbarandinsertthenewbolt

(M16x110mm),usingtheexistingwashers(Figure

4orFigure5).

g197781

Figure4

Machinewithserialnumbers316999999andlower

1.Nut(M16)4.Rightrearlightbracket

2.Existingwashers5.Orangeindicatorsideup

3.Rollbar6.Bolt(M16x110mm)

g196537

Figure5

Machinewithserialnumbers400000000to999999999

1.Nut(M16)4.Bolt(M16x110mm)

2.Existingwasher5.Rightrearlightbracket

3.Rollbar6.Orangeindicatorsideup

10.Installthenewnut(M16)ontotheboltandtorqueit

to15N∙m(11ft-lb).

Note:Donotovertightenthenut,asthismakesthe

rollbardifculttofold.

Note:Ifthereisalreadyabeaconkitttedtotheright

orleftside,usetheexistingboltandthenewnylocnuts

(M16)providedwiththiskit.

11.Feedallelectricalcablesdownthefrontoftherollbar

frameandontotheelectricalmountpanel.

12.Connectthecablestothemainwiringharnessofthe

machinewhichislocatedontheelectricalbulkhead

(Figure6),asfollows:

A.Connectthe4-pin,left,rear,light-assembly,wiring

connectortothecorresponding4-pinelectrical

connectorontheleftsideofthemainwiring

harness.

B.Connectthe4-pin,right,rear,light-assembly,

wiringconnectortothecorresponding4-pin

electricalconnectorontherightsideofthemain

wiringharness.

Note:The2-pinelectricalconnectorsontheleft

andrightrear-lightassemblyisrequiredforthe

number-platelight.Only1ofthe2-pinelectrical

connectorsisused.

g018243

Figure6

1.4-pin,left,rear,

light-assemblyconnector

onthemainwiringharness

3.4-pin,left,rear,

light-assemblyconnector

onthemainwiringharness

2.3-pin,

electrical-pressure-switch,

cableconnectoronthe

mainwiringharness

13.Install2fuses(15A)intothefuseblock.Usetherst

andthirdreceptaclesfromtheleftendofthefuse

block(Figure7).

g018244

Figure7

1.Fuse—15amp(2)

InstallingthePressureSwitch

Partsneededforthisprocedure:

1Dowtyseal(1/4inch)

1Pressureswitchadapter

1Pressureswitch

1Pressureswitchcable

Procedure

Thepressureswitchcontrolsthebrakelights.Theswitchis

screwedintothemaintransmissionline.

1.Locatethe3hoseconnectionsontherightsideofthe

transmissionpump.Thelowerfrontconnectiontothe

pumphasateettingwithablankingcap.

2.Removethisblankingcapfromtheteetting.

3.Screwthepressureswitchadapterintotheteetting

usingadowtyseal(1/4inch)asshowninFigure8.

g018247

123

g018247

Figure8

1.Dowtyseal(1/4inch)3.Pressureswitch

2.Pressure-switchadapter

4.Screwthepressureswitchintothisadapter(Figure8).

Torquetheswitchto34N∙m(25ft-lb).

5.Workingontheelectricalbulkhead,plugthe3-pin

connectoroftheelectricalpressureswitchcabletothe

correspondingconnectorlocatedonthemainwiring

harnessofthemachine(Figure6andFigure9).

g028149

Figure9

Connectorsasviewedfromthecableentryside

1.Green/Yellow5.Blue

2.Yellow6.Pressureswitchconnector

(mainwiringharness)

3.Black7.Pressureswitchcable

connector

4.Brown

6.Runtheelectricalpressureswitchcablefromthe

electricalbulkhead,downtherightrollbarpost,and

forwardalongthechassisrailtothepressureswitch.

7.Plugtheconnectorintothepressureswitchandsecure

it.

InstallingtheNumberPlate

Bracket

Partsneededforthisprocedure:

1Numberplatebracket

12-waytabhousingconnector

1Flasherrelay

1Standardshorterrelay

Procedure

Thenumberplatewithlightattachestothebulkhead.

1.Inthecenteroftheplasticbulkheadcover,

approximately40mm(1-1/2inches)fromthefront,

drillan8mmdiameterhole(Figure10).

g018245

Figure10

1.Drillahole(8mm)here.2.Numberplatebracket

WARNING

Usingadrillwithoutpropereyeprotection

mayallowdebristoentertheeye,causing

injury.

Whendrillingorcarryingoutotheroperation,

alwaysweareyeprotection.

2.Feedthenumberplatecablethroughthehole(8mm)

intheplasticbulkheadcover.Installthenumberplate

bracketandthebulkheadwiththebulkheadfasteners

previouslyremoved.

3.Pushthe2-waytabhousingconnectorontothe

terminalsofthenumberplatecable(Figure11).

g028150

Figure11

1.Redwire3.2-waytabhousing

connector

2.Blackwire

4.Connectthenumber-plate-lightwiringtoeitherthe

leftorrightrear-light-assembly-wiring,2-pinelectrical

connector.

5.Plugtheasherrelayintotheleftvacant-relaysocket

andthestandardshorterrelayintotherightvacant-relay

socket(Figure12).

g018246

Figure12

1.Flasherrelay2.Standardshorterrelay

InstallingtheFrontLights

Partsneededforthisprocedure:

1Centerheadlightmount

1Rightheadlightmount

1Leftheadlightmount

8Bolt(M6x20mm)

8Locknut(M6)

4Bolt(M10x25mm)

4Locknut(M10)

8Washer(3/8inch)

2Mountingbracket

24-waytabhousingconnector

Procedure

Thefrontlightassembliesattachtothecenterheadlight

mount,whichattachestothemachineusingtwomounting

brackets(Figure13):

1.Installthe2mountingbracketstothefrontofthe

machineusing2bolts(M10x25mm),4washers(3/8

inch),and2locknuts(M10)asshowninFigure13.

2.Installthecenterheadlightmounttothemounting

bracketsusing2bolts(M10x25mm),4washers(3/8

inch),and2locknuts(M10)asshowninFigure13.

3.Applyanti-seizegreasetofullycoattheinsidewallof

thetubeendsandallthesurfacesofthespringsand

tube-endproles(Figure13).

4.Whileholdingtherightheadlightmount,threadthe

wiringcabledownthroughtheendtubesandoutfrom

theheadlightmountcutout(Figure13).

5.Securetherightheadlightmounttothecenterheadlight

mountusingthe4bolts(M6x20mm)and4locknuts

(M6)asshowninFigure13.

g018249

Figure13

1.Centerheadlightmount7.Nylocnut(M10)

2.Rightheadlightmount8.Washer(3/8inch)

3.Leftheadlightmount9.Mountingbracket

4.Screw(M6x20mm)10.Applyanti-seizehere

5.Nylocnut(M6)11.Headlightmountcutout

6.Screw(M10x25mm)

6.Installthe4waytab-housingconnectorontothe

wiringcablebypushingthepinsintothebackof

theconnector.(Figure14).Identifyandmarkthis

connectoras“R”tohelpwithcableidenticationwhen

makingtheconnectionstothemachinemainwiring

harness.

g028151

Figure14

Connectorasviewedfromthecableentryside

1.Blue4.Black

2.Green5.4-waytabhousing

connector

3.Red/White

7.Repeatsteps4through6,markingtheconnectorwith

an“L”instep6.

8.Passthecablesdownthroughthecutoutforthetowing

pointandthoughtheholesinthefrontchassistothe

cuttingunitmanifoldlocatedundertheoperator’s

platform.

9.Locatethetwo4-pinconnectorsonthemainwiring

harnesslocatedneartothecuttermanifold.

10.Connecttheconnectoronthemachinewiringharness

withthegreen/whitewiretotheidentiedleftlight

assemblyconnector.(Figure15).

g028152

Figure15

1.Blue4.Black

2.Green/white5.Green

3.Red/white6.4-waytab-housing

connector

11.Connecttheconnectoronthemachinewiringharness

withthegreen/redwiretotheidentiedrightlight

assemblyconnector(Figure16).

g028152

Figure16

1.Blue4.Black

2.Green/red5.Green

3.Red/white6.4-waytab-housing

connector

InstallingtheControlPanel

Switches

Partsneededforthisprocedure:

1Instrumentpanelconnectorlead

1Hazardwarningswitch

1Lightsswitch

1Indicatorswitch

1Hornbutton

1Horndecal

24Cabletie

Procedure

1.Removethe6screwssecuringthecontrolpaneltothe

controlpod.

2.Carefullyliftoffthepanel.

Note:Ensurethattheconnectorstotheexisting

switchesarenotdisturbed.

3.Installtheinstrumentpanelconnectorleadintothe

controlarm.

4.Feedtheconnectorleadinstrumentpanelupthrough

theopeninginthebottomofthecontrolpodsothat

theendwiththe3connectorsareinsidethecontrol

pod,andtheendwiththesinglelargeconnectorisfed

downthecontrolarm.

5.RemovetheswitchblankpanelsFigure17.

Note:Thepanelsarelocatedjustabovethekeyswitch

ontherearfaceofthecontrolpod.

g018292

Figure17

1.Switchblank—lightswitch2.Switchblank—hazard

switch

6.Passthehazardandlightswitchconnectorsthrough

theswitchhole.

Note:Thehazardandlightconnectorsareonthe

shorterleads;thehazardconnectorisredandthelight

connectorisblack.Theindicatorconnectorisblack

andonthelongerlead.

7.Connectthelightandhazardswitchestothecorrect

connectorandpushtheswitchintothehole(Figure

18).

g018253

Figure18

1.Lightswitch2.Hazardswitch

8.Onthecontrolpanel,removetheroundplug(horn

button)andtherectangularplug(indicatorswitch)

showninFigure19.

G018336

g018336

Figure19

1.Roundplug—hornbutton2.Rectangular

plug—indicatorswitch

9.Installthehorndecal;lineitupwiththeedgesofthe

roundandrectangularholes(Figure20).

G018335

g018335

Figure20

1.Hornbutton3.Directionindicatorswitch

2.Horndecal

10.Installthehornbuttonandthedirectionindicator

switchontothecontrolpanel(Figure20).Installthe

directionindicatorswitchwiththegreen/redwires

totheleftandthegreen/whitewirestotheright,as

showninFigure21.

G018338

g018338

Figure21

1.Green/Red2.Green/White

11.Connectthedirectionindicatorswitchtotheconnector

leadinstrumentpanel.

Note:Theindicatorconnectorisblackandonthe

longerlead.

12.Connectthepinkwireandtheblack/purplewireto

thehornbutton.

Note:Thepinkwireandtheblack/purplewireare

locatedinthecontrolpanel.

13.Workingundertheoperatorplatform,connectthe

connectorleadinstrumentpaneltothemulti-pin

connectoronthemachine’smainelectrical-wiring

harness.

Note:Themulti-pinconnectorislocatedinthe

chassisrailtotherightofthetransmissionpump.

14.Attachcabletiestoallcablesforthefrontlights,rear

lights,andthepressureswitch.

Important:Ensurethatthecabletiesproperly

securethecables.Thetieswillpreventthecables

frombecomingtrappedorchafed.

15.Connectthenegativebatterycable.

16.Testtheswitchesonthecontrolpaneltoensurethat

theyareoperatingcorrectly.

17.Retthecontrolpaneltoensurethatnoconnectors

havebecomedetachedandthatnocablesarenipped.

18.Lowerandlatchtheenginecoverandoperator’s

platform.

Andere Handbücher für 02917

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Toro Rasenmäherzubehör Handbücher

Toro

Toro 02904 Bedienungsanleitung

Toro

Toro 30421 Bedienungsanleitung

Toro

Toro 04135 Bedienungsanleitung

Toro

Toro 106-2245 Bedienungsanleitung

Toro

Toro 07320 Bedienungsanleitung

Toro

Toro 78479 Bedienungsanleitung

Toro

Toro Z Master 100 Series Bedienungsanleitung

Toro

Toro Kevlar 02878 Bedienungsanleitung

Toro

Toro 140-3508 Bedienungsanleitung

Toro

Toro 04495 Bedienungsanleitung

Toro

Toro Groundsmaster e3200 Bedienungsanleitung

Toro

Toro 127-6879 Bedienungsanleitung

Toro

Toro 31212 Bedienungsanleitung

Toro

Toro 140-9324 Bedienungsanleitung

Toro

Toro Groundsmaster 4500-D Bedienungsanleitung

Toro

Toro 132-4162 Bedienungsanleitung

Toro

Toro 138-0798 Bedienungsanleitung

Toro

Toro TITAN ZX Series Bedienungsanleitung

Toro

Toro 86001 Bedienungsanleitung

Toro

Toro 04480 Bedienungsanleitung

Toro

Toro Grandstand 139-1529 Bedienungsanleitung

Toro

Toro 25465 Bedienungsanleitung

Toro

Toro Greensmaster eFlex 1018 Bedienungsanleitung

Toro

Toro 139-6040 Bedienungsanleitung

Beliebte Rasenmäherzubehör Handbücher anderer Marken

Ariens

Ariens 891008 Bedienungsanleitung

Rover

Rover 108 - 109 Bedienungsanleitung

Snapper

Snapper 1690047 Bedienungsanleitung

Scag Power Equipment

Scag Power Equipment GC-F4 Bedienungsanleitung

RHINO

RHINO 800 Bedienungsanleitung

Exmark

Exmark Quest 126-7506 Bedienungsanleitung

Snapper

Snapper 1685167 Bedienungsanleitung

Cub Cadet

Cub Cadet 19B70029100 Bedienungsanleitung

Stihl

Stihl AMK 043.1 Bedienungsanleitung

MTD

MTD 753-0873 Handbuch

Bush Hog

Bush Hog RG60 Bedienungsanleitung

Land Pride

Land Pride RCF2760 Bedienungsanleitung

Simplicity

Simplicity 211 Bedienungsanleitung

Exmark

Exmark ULTRAVAC QUICK DUMP SYSTEM Bedienungsanleitung

Excel

Excel Two Bag Catcher Bedienungsanleitung

Textron

Textron Jacobsen Pro12 DFS Bedienungsanleitung

Ryobi

Ryobi AC018130 Bedienungsanleitung

Snapper

Snapper 4544 Einrichtungshandbuch
