Toro 04063 Bedienungsanleitung

FormNo.3415-336RevA

LEDLightKit

SerialNumber400000000andAfterGreensmaster®800,1000,

1600,Flex™1820/2120,andeFlex®1820/2120SeriesMower

ModelNo.04063

ModelNo.04064

InstallationInstructions

WARNING

CALIFORNIA

Proposition65Warning

Thisproductcontainsachemical

orchemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orreproductiveharm.

Usetheappropriatemodelforyourmachineas

follows:

•ModelNo.04063—Greensmaster®800,1000,

and1600seriesmachines

•ModelNo.04064—Greensmaster®Flex

1820/2120oreFlex1820/2120seriesmachines

Note:Determinetheleft,right,front,andbacksides

ofthemachinefromthenormaloperatingposition.

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescriptionQty.Use

1Nopartsrequired–Preparethemachine.

2Nopartsrequired–Removethecontrol-panelcover(1820

or2120seriesmachines).

LEDlightassembly2

Lightmount2

Flange-headbolt(3/8inch)4

3Flangenut(3/8inch)2

Assemblethelightmountstothe800,

1000,and1600seriesmachine.

LEDlightassembly2

Lightmount2

Mountplate1

Flange-headbolt(3/8inch)1

Flange-headbolt(5/16x1inch)1

Flange-headbolt(5/16x1-1/2inches)4

Flangelocknut(5/16inch)4

Flangenut(3/8inch)1

Flangenut(5/16inch)1

Washer4

Assemblethelightmountstothe1820

or2120seriesmachine.

5Wireharness2Assemblethewireharnessestothe

machine.

62-positionrockerswitch1Installthelightswitch.

7Cabletie10Installthecableties.

8Nopartsrequired–Finishthelightkitinstallation.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.T oro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3415-336*A

PreparingtheMachine

NoPartsRequired

DisconnectingtheSpark-Plug

Wire

800,1000,and1600SeriesMachines

1.Ensurethatthereel-driveleverisinthe

DISENGAGEposition;refertotheOperator’s

Manual.

2.Movethemachinetoalevelsurfaceandset

thetraction-drivelevertotheNEUTRALposition;

refertotheOperator’sManual.

3.SetthethrottlecontroltotheSLOWpositionand

pushtheOn-OffswitchtotheOFFposition;refer

totheOperator’sManual.

4.Engagetheservicebrakeandholdinplacewith

theparking-brakeknob;refertotheOperator’s

Manual.

5.Removethespark-plugwirefromtheterminalof

thesparkplug(Figure1).

g032966

Figure1

1.Spark-plugwire

DisconnectingtheSpark-Plug

Wire

Flex1820and2120SeriesMachines

1.Ensurethetractionandreeldriveengagement

leverisintheDISENGAGEposition;refertothe

Operator’sManual.

2.Movethemachinetoalevelsurfaceandset

thetractionandreeldriveengagementleverto

theNEUTRALposition;refertotheOperator’s

Manual.

3.SetthethrottlecontroltotheSLOWpositionand

pushtheOn-OffswitchtotheOFFposition;refer

totheOperator’sManual.

4.Pulltheservicebrakeleverbackandholdin

placewiththeparking-brakelatch;refertothe

Operator’sManual.

5.Removethespark-plugwirefromtheterminalof

thesparkplug(Figure1).

DisconnectingtheBattery

eFlex1820and2120SeriesMachines

1.Ensurethetractionandreeldriveengagement

leverisintheDISENGAGEposition;refertothe

Operator’sManual.

2.Movethemachinetoalevelsurfaceandset

thetractionandreeldriveengagementleverto

theNEUTRALposition;refertotheOperator’s

Manual.

3.RotatethekeyswitchtotheOFFposition;refer

totheOperator’sManual.

4.Pulltheservicebrakeleverbackandholdin

placewiththeparkingbrakelatch;refertothe

Operator’sManual

5.Wait10to15minutesforthemotorcapacitors

todischarge.

6.DisconnecttheT-handleconnectorofthebattery

adapterwireharnessfromtheP04connectorof

thebatterywireharness(Figure2).

g210482

Figure2

1.P04T-handleconnector

(batteryadapterwire

harness)

2.P04connector(battery

wireharness)

Removingthe

Control-PanelCover

1820or2120SeriesMachines

NoPartsRequired

Procedure

1.Removethe4ange-headscrews(1/4x1/2

inch)thatsecurethecontrol-panelcovertothe

supportbracketofthehandlebar(Figure3).

g032757

Figure3

1.Control-panelcover3.Supportbracket(handle

bar)

2.Flange-headscrew(1/4x

1/2inch)

2.Movethecontrolpanelcoverupandforward

fromthecontrolpanel,andremovethecover

fromthemachine(Figure3).

Note:Retaintheange-headscrewsand

control-panelcoverforassemblyinInstallingthe

Control-PanelCover(page14).

AssemblingtheLight

Mountstothe800,1000,

and1600SeriesMachine

Partsneededforthisprocedure:

2LEDlightassembly

2Lightmount

4Flange-headbolt(3/8inch)

2Flangenut(3/8inch)

Procedure

1.Removeanddiscardtheboltfromtheupper

frameofbothsideplatesasshowninFigure4.

g210479

Figure4

1.Bolt

2.Loosentheboltsontherightreeldrivecover,

thenraisethecover(Figure5).

Important:Loosen,butdonotremovethe

bolts.

Note:Raisingthecoverwillallowyoutousea

wrenchtotightentheboltthatisclosesttothe

cover.

g207878

Figure5

1.Bolt—loosen

3.Use4ange-headbolts(3/8inch)and2ange

nuts(3/8inch)tosecurethelightmountstoboth

sideplates(Figure6).

Note:Ensuethatthethrottlecableisrouted

behindthelightmount.

g206126

Figure6

1.Flange-headbolt(3/8

inch)

3.Flangenut(3/8inch)

2.Lightmount

4.RemovethenutandthewasherfromeachLED

lightassembly,thenusethenutandthewasher

tosecuretheLEDlightstoeachlightmount

(Figure7).

g200656

Figure7

1.LEDlight3.Washer

2.Lightmount4.Nut

AssemblingtheLight

Mountstothe1820or2120

SeriesMachine

Partsneededforthisprocedure:

2LEDlightassembly

2Lightmount

1Mountplate

1Flange-headbolt(3/8inch)

1Flange-headbolt(5/16x1inch)

4Flange-headbolt(5/16x1-1/2inches)

4Flangelocknut(5/16inch)

1Flangenut(3/8inch)

1Flangenut(5/16inch)

4Washer

Procedure

1.Use2ange-headbolts(5/16x1-1/2inches),2

washers,and2angenuts(5/16inch)tosecure

themountplatetotheleftsideplate(Figure8

orFigure9).

•Flex/eFlex1820machines:positionthe

mountplatetotheoutsideoftheleftside

plate(Figure8).

•Flex/eFlex2120machines:positionthe

mountplatetotheinsideoftheleftside

plate(Figure9).

g210476

Figure8

Flex/eFlex1820MachineShown

1.Flangelocknut(5/16inch)4.Flange-headbolt(5/16x

1-1/2inches)

2.Mountplate5.Leftsideplate

3.Washer

g200371

Figure9

Flex/eFlex2120MachineShown

1.Flangelocknut(5/16inch)4.Flange-headbolt(5/16x

1-1/2inches)

2.Mountplate5.Leftsideplate

3.Washer

2.Use1ange-headbolt(3/8inch),1ange-head

bolt(5/16x1inch),1angenut(3/8inch),and

1angenut(5/16inch)tosecurealightmount

tothemountplate(Figure10).

g206120

Figure10

Flex/eFlex2120MachineShown

1.Lightmount4.Flangenut(5/16inch)

2.Flange-headbolt(5/16x

1inch)

5.Flangenut(3/8inch)

3.Flange-headbolt(3/8

inch)

3.Use2ange-headbolts(5/16x1-1/2inches),2

washers,and2angenuts(5/16inch)tosecure

alightmounttotherightdrivehousing(Figure

11).

g206121

Figure11

1.Flange-headbolt(5/16x

1-1/2inch)

4.Lightmount

2.Washer5.Flangelocknut(5/16inch)

3.Drivehousing

4.RemovethenutandthewasherfromeachLED

lightassembly,thenusethenutandthewasher

tosecuretheLEDlightstoeachlightmount

(Figure12).

g200370

Figure12

1.LEDlight3.Washer

2.Lightmount4.Nut

AssemblingtheWire

HarnessestotheMachine

Partsneededforthisprocedure:

2Wireharness

AttachingtheWireHarnessesto

theLEDLights

1.Connectthe2-pinconnectoroftheLEDlightinto

the2-socketconnectoroftheLEDlightharness

(Figure13).

Ensurethattheconnectorsarefullyseated

andthelatchoftheconnectorssnaptogether

securely.

g200657

Figure13

1.2-socketconnector(wire

harness)

2.2-pinconnector(LEDlight)

2.Repeatstep1fortheotherwireharnessand

LEDlight.

RoutingtheWireHarness

Routethewireharnessesdowneachlightmountand

upeachhandleasshowninFigure14.

Note:Ensurethatthewireharnessesarerouted

belowthedifferentialaxleshaft(Figure15).

g210745

Figure14

800,1000,and1600SeriesMachineshown

1.Wireharness

g210746

Figure15

800,1000,and1600SeriesMachineshown

1.Wireharness2.Differentialaxleshaft

ConnectingtheLEDLightWire

HarnessestotheMachineWire

Harness

800,1000,and1600SeriesMachines

Note:PerformthefollowingstepsfortheLEDlight

wireharnessesonbothsidesofthemachine.

1.Atthebackoftheconsole,removetheplug

fromthe2-socketconnectorofthemachinewire

harness(Figure16).

g206149

Figure16

Leftsideofthemachineshown

1.2-socketconnector(wire

harness—machine)

3.2-pinconnector(wire

harness—LEDlightkit)

2.Plug4.Console

2.Connectthe2-pinconnectoroftheLEDlight

wireharnesstothe2-socketconnectorofthe

machinewireharness(Figure16).

Ensurethattheconnectorsarefullyseated

andthelatchoftheconnectorssnaptogether

securely.

3.Performthepreviousstepsforthewireharness

ontheothersideofthemachine(Figure17).

g210747

Figure17

1.Wireharness—LEDlight

kit

3.Installed2-pinconnector

and2-socketconnector

2.Wireharness—machine

ConnectingtheLEDLightWire

HarnessestotheMachineWire

Harness

Flex1820and2120SeriesMachines

Note:PerformthefollowingstepsfortheLEDlight

wireharnessesonbothsidesofthemachine.

1.Atthefrontoftheconsole,removetheplug

fromthe2-socketconnectorofthemachinewire

harness(Figure18).

g210534

Figure18

Leftsideofthemachineshown

1.2-pinconnector(wire

harness—LEDlightkit)

3.2-socketconnector(wire

harness—machine)

2.Plug

2.Connectthe2-pinconnectoroftheLEDlight

wireharnesstothe2-socketconnectorofthe

machinewireharness(Figure18).

Ensurethattheconnectorsarefullyseated

andthelatchoftheconnectorssnaptogether

securely.

3.Performthepreviousstepsforthewireharness

ontheothersideofthemachine(Figure19).

g210792

Figure19

1.Installed2-pinconnector(wireharness—LEDlightkit)

ConnectingtheLEDLightWire

HarnessestotheMachineWire

Harness

eFlex1820and2120SeriesMachines

Note:PerformthefollowingstepsfortheLEDlight

wireharnessesonbothsidesofthemachine.

1.Atthefrontoftheconsole,removetheplug

fromthe2-socketconnectorofthemachinewire

harness(Figure20).

g210537

Figure20

Leftsideofthemachineshown

1.2-pinconnector(wire

harness—LEDlightkit)

3.2-socketconnector(wire

harness—machine)

2.Plug

2.Connectthe2-pinconnectoroftheLEDlight

wireharnesstothe2-socketconnectorofthe

machinewireharness(Figure20).

Ensurethattheconnectorsarefullyseated

andthelatchoftheconnectorssnaptogether

securely.

3.Performthepreviousstepsforthewireharness

ontheothersideofthemachine(Figure21).

g210792

Figure21

1.Installed2-pinconnector(wireharness—LEDlightkit)

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Toro Rasenmäherzubehör Handbücher

Toro

Toro 132-7169 Bedienungsanleitung

Toro

Toro Groundsmaster 4700-D Bedienungsanleitung

Toro

Toro 31211 Bedienungsanleitung

Toro

Toro 79348 Bedienungsanleitung

Toro

Toro Groundsmaster 300 Series Bedienungsanleitung

Toro

Toro 120-3290 Bedienungsanleitung

Toro

Toro Sand Pro 5040 Bedienungsanleitung

Toro

Toro 31529 Bedienungsanleitung

Toro

Toro HoverPro 450 Bedienungsanleitung

Toro

Toro 78534 Bedienungsanleitung

Toro

Toro 04482-60001 Bedienungsanleitung

Toro

Toro 22441 Bedienungsanleitung

Toro

Toro Groundsmaster 200 Series Bedienungsanleitung

Toro

Toro 110-6506 Bedienungsanleitung

Toro

Toro Grandstand 139-1529 Bedienungsanleitung

Toro

Toro 13-32G Wheel Horse Bedienungsanleitung

Toro

Toro Z-Master Bedienungsanleitung

Toro

Toro Wheel Horse 78305 Bedienungsanleitung

Toro

Toro 78514 Bedienungsanleitung

Toro

Toro 132-4162 Bedienungsanleitung

Toro

Toro E-Z Vac 79346 Bedienungsanleitung

Toro

Toro 79120 Bedienungsanleitung

Toro

Toro 126-8379 Bedienungsanleitung

Toro

Toro Recycler Kit 131-4184 Bedienungsanleitung

Beliebte Rasenmäherzubehör Handbücher anderer Marken

Ariens

Ariens 891008 Bedienungsanleitung

Rover

Rover 108 - 109 Bedienungsanleitung

Snapper

Snapper 1690047 Bedienungsanleitung

Scag Power Equipment

Scag Power Equipment GC-F4 Bedienungsanleitung

RHINO

RHINO 800 Bedienungsanleitung

Exmark

Exmark Quest 126-7506 Bedienungsanleitung

Snapper

Snapper 1685167 Bedienungsanleitung

Cub Cadet

Cub Cadet 19B70029100 Bedienungsanleitung

Stihl

Stihl AMK 043.1 Bedienungsanleitung

MTD

MTD 753-0873 Handbuch

Bush Hog

Bush Hog RG60 Bedienungsanleitung

Land Pride

Land Pride RCF2760 Bedienungsanleitung

Simplicity

Simplicity 211 Bedienungsanleitung

Exmark

Exmark ULTRAVAC QUICK DUMP SYSTEM Bedienungsanleitung

Excel

Excel Two Bag Catcher Bedienungsanleitung

Textron

Textron Jacobsen Pro12 DFS Bedienungsanleitung

Ryobi

Ryobi AC018130 Bedienungsanleitung

Snapper

Snapper 4544 Einrichtungshandbuch
