Totevision LCD-1700VRQ Bedienungsanleitung
17” Quad display LCD monitor ______________________
1
CHAPTER 1
INTRODUCTION
BEFORE INSTALLING YOUR MONITOR
READ THIS MANUAL COVER TO COVER.
PAY ATTENTION to all WARNING and CAUTIONS
DO NOT use computer components not recommend by the
manufacture
Do not attempt to service the monitor your self. If a problem
occurs, contact the manufacture's authorized service center
ABOUT YOUR MONITOR
This monitor is a microprocessor-controlled, color monitor
which uses a TFT LCD panel. The monitor conforms to EPA
Energy Star and VESA DPMS ( Display Power Management
Signaling) power management standards. Our monitor also
provide one option to accept the video input (like NTSC or PAL
signal), you can switch these input signal through OSD and the
video OSD setting please refer to the Chapter 4.
RGB MODE
This monitor is equipped with a microprocessor that
identifies your computer’s video mode and allows user to adjust
the setting.
________________________17” Quad display LCD monitor
2
FACTORY-PRESET MODES
Table 1 shows standard video mode setting that have been
pre-adjusted at the factory for accurate video display. These
setting are stored in the monitor's memory
Table 1. Factory-Preset Modes
Mode Resolution H-Freq.(KHz) V-Freq(Hz)
NEC 640x400 24.83 56.4
VGA 640x350
720x400
640x480
640x480
640x480
31.47
31.47
31.47
37.86
37.5
70
70
60
72
75
SVGA 800x600
800x600
800x600
800x600
35.16
37.88
48.08
46.87
56.3
60.3
72.2
75
XGA
1024x768
1024x768
1024x768
48.36
56.47
60
60
70
75
SXGA 1280x1024
1280x1024 63.98
80 60
75
Macintosh 640x480
832x624
1024x768
1024x768
35
49.7
48.78
60.241
66.7
74.55
60
74.927
17” Quad display LCD monitor ______________________
3
SPECIFICATIONS
lLCD-1700VRQ 17” LCD Monitor
Overall Dimension (HxWxD): 483 x 354 x 50.3 mm
Shipping Weight (G/W): 9 Kg
Effective Display area (H/V):337.92 x 270.34 mm
Display colors: 16.7M colors
Scan Frequencies:
Horizontal 31.47K to 80KHz
Vertical 60Hz to 75Hz
Number of Pixels: 1280x1024 pixels
Pixel pitch: 0.264x0.264 mm
Picture Tube: 17" TFT LCD panel
Power:
Input 110-240VAC(auto-sensing)
Frequency: 48-62Hz
Consumption 45Watts maximum (on)
RGB Connector: 15pin Mini D-sub (Standard)
BNC connector 6 x BNC connector
4 x camera input
1 x playback
1 x recorder
RGB Signals:
Video Analog RGB 0.7Vp-p/75Ω
Sync Separate
Display Data Channel:
Compatibility VESA DDC 1/2B
________________________17” Quad display LCD monitor
4
Compatibility: IBM and compatible, Apple
Macintosh, NEC
Environmental Limits:
Operating Temp 32°to 104°F ( 0°to 40°C )
Storage Temp. -4°to 140°F ( -20°to 60°C )
Operating Humidity 10 to 85% without condensation
Storage Humidity 10 to 95% without Condensation
Agency Approval
EMI FCC-A and CE
Safety UL
17” Quad display LCD monitor ______________________
5
Chapter 2
PRODUCT PACKAGE
Open the shipping carton and check the contents. If any
items are missing or damaged, contact your dealer
immediately.
The package should include the following items
l8U 17” Color TFT LCD Monitor
lAccessory Box:
1. VGA cable x 1
2. AC to DC adapter x 1
3. Power Cord x 1
4. User’s manual x 1
INSTALLING THE MONITOR
The monitor is equipped with an auto sensing power supply
for voltage ranges from 110~240VAC, 60/50Hz. Confirm the
line voltage designation on the rear panel of the monitor.
________________________17” Quad display LCD monitor
6
FOLLOW THESE STEPS TO INSTALL THE
MONITOR
1. Before you connect the cables, make sure that the
monitor and the system unit power switches are OFF
2. Plug one end of the 15pin signal cable to the monitor and
the other end to the video signal connector at the rear of
the system. Tighten the two screws on the cable
connector on both ends, otherwise the screen will be
abnormal and LED light is yellow color, not the normal
green color.
3. Connect 4 cameras through BNC cable
4. Connect out BNC to recorder to record the screen
5. Connect the power to the monitor through the AC/DC
adapter
17” Quad display LCD monitor ______________________
7
CONTROL FUNCTIONS
The OSD control functions of 17” Quad display LCD monitor are
located on the lower side. They are shown in the figure below
and described in the following paragraphs.
Menu ∇∆-+
AV/PC Menu ?/CH1 ?/CH2 -/CH3 +/CH4 =/AUTOX
The first line is used for RGB OSD adjustment
The second line is used for security OSD adjustment
AV/PC: Switch the Screen between RGB and security
screen.
The RGB control key description:
1. : Power Switch
2. ﹣/+: Decrement/Increment or Volume control
3. ∇/∆: Cursor Up/Down or Brightness control
4. MENU: Activate the on screen display function
As the security control key definition, please see the chapter 4.
________________________17” Quad display LCD monitor
8
Chapter 3
ADJUSTING THE PC MONITOR
The LCD monitor is designed to work with a range of
compatible video adapters on the market. Due to the possible
deviations between these video adapters, you may make
some adjustment to fit the monitor for adapter used.
ADJUSTMENT PROCEDURE
1. First, you must activate the OSD screen through pressing
the MENU key, the screen will show in the center of
screen as below:
Note: In the last paragraph, we will assume that you had
already done this procedure and only explain how to
change the setting.
2. Use the ∇& ∆key to select the requiredadjustment item
up or down.
3. Use the ﹣&+key to change the control value for
optimum viewing.
4. Each change that you had made will be automatically
saved into memory, If the screen display garbage and you
don't know how to restore to correct setting, please move
arrow to "Load Value" item then pressing "-" key to load
factory default.
