Totevision LCD-840V Bedienungsanleitung

KEY DEFINE:

ŒUP: PRESS THIS BUTTON TO INCREASE OR DECREASE THE VALUE OF

THE ADJUSTMENT FUNCTIONS.

•DOWN: PRESS THIS BUTTON TO INCREASE OR DECREASE THE VALUE OF

THE ADJUSTMENT FUNCTIONS.

ŽENTER: PRESS THIS BUTTON FOR MENU ADJUSTING, SELECTING THE MENU

YOU WANT WITH “UP”OR “DOWN”, THEN PRESS THIS BUTTON AGAIN

TO ENTER THE SELECTED MENU.

•POWER: PRESS THIS BUTTON TO TURN ON THE POWER.

PRESS AND HOLD FOR MORE THAN 2 SECONDS TO TURN THE

POWER OFF.

UNDER POWER ON CONDITION, THIS BUTTON ACTS AS INPUT

MODE SELECTOR (VGA/ S-VIDEO/ VIDEO).

•VGA IN

‘S-VIDEO IN

’VIDEO IN

“DC 12V

ON SCREEN DISPLAY FOR VIDEO INPUT

VIDEO MAIN OSD MENU FIGURE

---PRESS “ENTER” BUTTON TO ACTIVATE THE OSD MAIN AS

SHOWN ON SCREEN

---PRESS “UP” OR “DOWN” BUTTON AGAIN TO SELECT THE

OSD MENU

1. BRIGHTNESS

---PRESS “ENTER” BUTTON TO ENTER THIS MODE

---PRESS “UP” OR “DOWN” BUTTON TO SELECT THE DESIRED

ADJUSTMENT ITEM

* BRIGHTNESS: TO ADJUST THE BRIGHTNESS OF THE PANEL

*CONTRAST: TO ADJUST THE WHITE COLOR LEVEL OF THE

IMAGE.

* BACK LIGHT: TO ADJUST THE BACK LEVEL OF THE PANEL

*RECALL: WHEN YOU RUN THE FUNCTION, THE MONITOR

WILL BE SETTING TO LAST STATUS OF THE SAVING VALUE

*EXIT: RETURN TO LAST MENU

2. VIDEO QUALITY

---PRESS “ENTER” BUTTON TO ENTER THIS MODE

---PRESS “UP” OR “DOWN” BUTTON TO SELECT THE DESIRED

ADJUSTMENT ITEM

* BRIGHTNESS: TO ADJUST THE BRIGHTNESS OF THE PANEL

*CONTRAST: TO ADJUST THE WHITE COLOR LEVEL OF THE


*SATURATION: TO ADJUST THE COLOR SATURATION OF THE


* HUE: TO ADJUST THE COLOR HUE OF THE IMAGE

* SHARPNESS: TO ADJUST THE IMAGE FROM WEAK TO

SHARP

* RECALL: WHEN YOU RUN THE FUNCTION, THE MONITOR

WILL BE SETTING TO LAST

* EXIT: RETURN TO LAST MENU

Brightness

Contrast

Back Light

Recall

Exit

Video Quality

Brightness

Contrast

Saturat

Hue

Sharpness

Recall

Exit

3. OSD FUNCTION

---PRESS “ENTER”BUTTON TO ENTER THIS MODE

---PRESS “UP”OR “DOWN”BUTTON TO SELECT THE DESIRED

ADJUSTMENT ITEM

* H POSITION: TO ADJUST THE HORIZONTAL POSITION OF

THE OSD MENU

*V POSITION: TO ADJUST THE VERTICAL POSITION OF THE

OSD MENU

*LANGUAGE: N/A

*OFF TIMER: THE METHOD OF OSD DISPLAY

*RECALL: WHEN YOU RUN THE FUNCTION, THE MONITOR

WILL BE SETTING TO LAST

*EXIT: RETURN TO LAST MENU

4. IMAGE

---PRESS “ENTER” BUTTON TO ENTER THIS MODE

---PRESS “UP” OR “DOWN” BUTTON TO SELECT THE DESIRED

ADJUSTMENT ITEM

*VIDEO SYSTEM: NTSC /PAL /SECAM /NTSC 4.43 /AUTO

*DITHERING: N/A

*SELECT INPUT: PRESS TO SELECT INPUTS VGA/S-VIDEO/

VIDEO

*EXIT: RETURN TO LAST MENU

5. RECALL

---PRESS “ENTER” BUTTON TO ENTER THIS MODE

---PRESS “UP” OR “DOWN” BUTTON TO SELECT THE DESIRED

ADJUSTMENT ITEM

*RECALL ALL: WHEN YOU RUN THE FUNCTION, THE MONITOR

WILL BE SETTING TO LAST

*EXIT: RETURN TO LAST MENU

6. EXIT MENU

OSD Function

H Position

V Position

Language

Off Timer

Recall

Exit


Video System

Dithering

Select Input

Exit

Recall

Recall All

Exit

Exit Menu

ON SCREEN DISPLAY FOR VGA INPUT

VGA MAIN OSD MENU FIGURE

---PRESS “ENTER” BUTTON TO ACTIVATE THE OSDMAIN MENU

AS SHOWN ON SCREEN

---PRESS “UP” OR “DOWN” BUTTON AGAIN TO SELECT THE

OSD MENU

1. AUTO CONFIG

---PRESS “ENTER” BUTTON TO ENTER THIS MODE

---PRESS “UP” OR “DOWN” BUTTON TO SELECT THE DESIRED

ADJUSTMENT ITEM

*AUTO CONFIG: SELECT “YES” TO MAKE THE MONITOR HAVE

THE BEST EFFICIENCY

*EXIT: RETURN TO LAST MENU

2. POSITION

---PRESS “ENTER” BUTTON TO ENTER THIS MODE

---PRESS “UP” OR “DOWN” BUTTON TO SELECT THE DESIRED

ADJUSTMENT ITEM

*H POSITION: TO ADJUST THE HORIZONTAL POSITION OF THE


*V POSITION: TO ADJUST THE VERTICAL POSITION OF THE


*AUTO POSITION: SELECT “YES” TO AUTO ADJUST THE

VERTICAL AND HORIZONTAL POSITION

* EXIT: RETURN TO LAST MENU

3. BRIGHTNESS

---PRESS “ENTER” BUTTON TO ENTER THIS MODE

---PRESS “UP” OR “DOWN” BUTTON TO SELECT THE DESIRED

ADJUSTMENT ITEM

*BRIGHTNESS: TO ADJUST THE BRIGHTNESS OF THE PANEL

*CONTRAST: TO ADJUST THE WHITE COLOR LEVEL OF THE


*BACK LIGHT: TO ADJUST THE BACK LIGHT BULE INTENSITY

*RECALL: WHEN YOU RUN THE FUNCTION, THE MONITOR

WILL BE SETTING TO LAST STATUS OF THE SAVING VALUE

*EXIT: RETURN TO LAST MENU

Auto Config

Exit

Position

H Position

V Position

Auto Position

Exit

Brightness

Contrast

Back Light

Recall

Exit

4. CLOCK

---PRESS “ENTER” BUTTON TO ENTER THIS MODE

---PRESS “UP” OR “DOWN” BUTTON TO SELECT THE DESIRED

ADJUSTMENT ITEM

*CLOCK: TO ADJUST VIDEO SAMPLING CLOCK

*PHASE: TO ADJUST THE NOISE OF THE IMAGE

*RECALL: WHEN YOU RUN THE FUNCTION, THE MONITOR

WILL BE SETTING TO LAST STATUS OF THE SAVING VALUE

*EXIT: RETURN TO LAST MENU

5. COLOR

---PRESS “ENTER” BUTTON TO ENTER THIS MODE

---PRESS “UP” OR “DOWN” BUTTON TO SELECT THE DESIRED

ADJUSTMENT ITEM

*COLOR 9300°K:TO SET THE COLOR TEMPERATURE OF

THE IMAGE TO 9300 K

*COLOR 5500°K:TO SET THE COLOR TEMPERATURE OF

THE IMAGE TO 5500 K

*BALANCE COLOR: TO ADJUST THE COLOR BALANCE

*USER COLOR: TO SET THE RGB COLOR OF THE IMAGE BY

ONESELF DEFINE

*AUTO BALANCE: AUTOMATIC ADJUSTMENT OF THE BALANCE

*AUJUST COLOR: PRESS “ENTER” BUTTON TO ENTER COLOR

ADJUSTMENT. PRESS “UP” OR “DOWN” BUTTON TO ADJUST

R/G/B COLOR LEVEL AND OFF SET

6. OSD FUNCTION

---PRESS “ENTER” BUTTON TO ENTER THIS MODE

---PRESS “UP” OR “DOWN” BUTTON TO SELECT THE DESIRED

ADJUSTMENT ITEM

*H POSITION: TO ADJUST THE HORIZONTAL POSITION OF THE

OSD MENU

*V POSITION: TO ADJUST THE VERTICAL POSITION OF THE

OSD MENU

*LANGUAGE: N/A

*OFF TIMER: THE METHOD OF OSD DISPLAY

*RECALL: WHEN YOU RUN THE FUNCTION, THE MONITOR

WILL BE SETTTING TO LAST

Clock

Phase

Recall

Exit

Color

Color 9300°K

Color 5500°K

Balance Color

User Color

Auto Balance

Adjust Color

OSD Function

H Position

V Position

Language

Off Timer

Recall

Exit

*EXIT: RETURN TO LAST MENU

7. IMAGE

---PRESS “ENTER” BUTTON TO ENTER THIS MODE

---PRESS “UP” OR “DOWN” BUTTON TO SELECT THE DESIRED

ADJUSTMENT ITEM

*MODE SELECT: CHANGE DOS MODE RESOLUTION

640 x 400 OR 720 x 350 OR 720 x 400

*DITHERING: N/A

*SELECT INPUT: PRESS TO SELECT INPUTS VGA / S-VIDEO /

VIDEO

*EXIT: RETURN TO LAST MENU

8.INFORMATION

VGA CONDITION

RESOLUTION AND FREQUENCY

9. RECALL

---PRESS “ENTER” BUTTON TO ENTER THIS MODE

---PRESS “UP” OR “DOWN” TO SELECT THE DESIRED

ADJUSTMENT ITEM

*RECALL ALL: TO SET DEFAULT VALUE TO THE ORIGINAL

SETTING

*EXIT: RETURN TO LAST MENU

10. EXIT MENU

Exit Menu

Information

Recall

Recall All

Exit


Mode Select

Dithering

Select Input

Exit

SPECIFICATIONS

MODEL NO.: LCD-840V

SCREEN SIZE:8.4”(DIAGONAL)

DISPLAY RESOLUTION: 800 (H) x 600 (V)

PIXEL PITCH (mm): 0.213 (H) x 0.213 (V)

ACTIVE AREA (mm):170.4 (H) x 127.8 (V)

LCD PROFILE RATIO: 4:3

COLOR CONFIGURATION: R.G. B.VERTICAL STRIPE

BRIGHTNESS RATING: 250 NIT TYP

INPUT SIGNAL: NTSC / PAL (DUAL.CAPABLITY) / SECAM /

NTSC4.43

NUMBER OF PIXELS: 262,144 DOTS

VIEWING ANGLE: LEFT & RIGHT 40 DEGREE

DOWN 10 DEGREE

TOP 30 DEGREE

PIXEL CONFIGURATION: STRIPE

VIDEO INPUT SIGNAL LEVEL: 1V P-P(POSITIVE) / 75 ohm

OPERATING TEMPERATURE: 0℃~+60℃

STORAGE TEMPEATURE: -20℃~+70℃

DC POWER SUPPLY: DC 12V IN (FROM POWER SUPPLY)

POWER CONSUMPTION: <10 W

CONNECTORS: DC-IN, RCA VIDEO, S-VIDEO, D-SUB

RESPONSE: 20ms/RISING TIME, 30ms/FALLING TIME

DIMENTIONS: 291.0 (H) X 214.0 (W) x 37.9 (D) mm
