Toyota RAV4 (RHD) - MMC Bedienungsanleitung
Last Modified: 03-12-2013 6.4 D Doc ID: RM1000000004ZPI
Model Year: 2013 Model: RAV4 Prod Date Range: [12/2012 - ]
Title: AUDIO / VIDEO: AUDIO AND VISUAL SYSTEM(f r Radi and Display Type): DTC CHECK / CLEAR;
2013 MY RAV4 [12/2012 - ]
DTC CHECK / CLEAR
1. CHECK DTC (CHECK USING TECHSTREAM)
(a) C nnect the Techstream t the DLC3.
(b) Engine start.
(c) Turn the Techstream n.
(d) Enter the f ll wing menus: B dy Electrical / Navigati n System / Tr uble C des.
(e) Check f r DTCs, and then write them d wn.
Body Electrical > Navigation System > Tro ble Codes
(f) Check the details f the DTC(s).
Click here
2. CLEAR DTC (CLEAR USING TECHSTREAM)
(a) C nnect the Techstream t the DLC3.
(b) Engine start.
(c) Turn the Techstream n.
(d) Enter the f ll wing menus: B dy Electrical / Navigati n System / Clear DTCs.
(e) Clear the DTCs.
Body Electrical > Navigation System > Clear DTCs
3. START DIAGNOSTIC MODE
HINT:
Illustrati ns may differ fr m the actual vehicle screen depending n the device settings and
pti ns. Theref re, s me detailed areas may n t be sh wn exactly the same as n the actual
vehicle screen.
•
Start diagn stic m de 15 sec nds after engine started. Otherwise, s me items cann t be checked.•
(a) While pressing and h lding the "Media" r "Audi " switch, perate the light c ntr l switch: Off →
Tail →Off →Tail →Off →Tail →Off.
Page
1
of
8
AUDIO / VIDEO: AUDIO AND VISUAL SYSTEM(for Radio and Dis lay Ty e): DTC
...
8/
28/
2013
mhtml:file://C:\Users\SB185219\Downloads\RM1000000004ZPI
-
DTC CHECK_CLEAR
...
*a Example
(b) Diagn stic m de starts and the "Service Menu" screen will be displayed. Service inspecti n starts
aut matically and the result will be displayed.
4. FAILURE DIAGNOSIS
(a) Press the "Failure Diagn sis" switch n the "Service Menu" screen.
(b) The "Failure Diagn sis" will be displayed.
5. SYSTEM CHECK
(a) Press the "System Check" switch n the "Failure Diagn sis" screen.
Page
2
of
8
AUDIO / VIDEO: AUDIO AND VISUAL SYSTEM(for Radio and Dis lay Ty e): DTC
...
8/
28/
2013
mhtml:file://C:\Users\SB185219\Downloads\RM1000000004ZPI
-
DTC CHECK_CLEAR
...
*a Example
(b) The "System Check M de" screen will be displayed.
6. CHECK DTC (CHECK USING SYSTEM CHECK MODE SCREEN)
(a) System check m de screen descripti n
Screen Description
DISPLAY CONTENT
*a: Device Name List
N . 1
Device Name List N . 1 displays s me f the devices that make up the
audi and visual system
•
The names f the c mp nents fr m Device Name List N . 1 are sh wn
in the f ll wing table
•
*b: Check Result Result c des f r all devices are displayed
*c: Mem ry Clear
Present and hist ry DTCs and registered c nnected device names are
cleared
•
Press the "Mem ry CLR" switch f r 3 sec nds•
*d: Recheck A system check will be perf rmed again after the mem ry is cleared•
Page
3
of
8
AUDIO / VIDEO: AUDIO AND VISUAL SYSTEM(for Radio and Dis lay Ty e): DTC
...
8/
28/
2013
mhtml:file://C:\Users\SB185219\Downloads\RM1000000004ZPI
-
DTC CHECK_CLEAR
...
DISPLAY CONTENT
The "Recheck" switch will dim during a system check•
*e: Device Name List
N . 2
Device Name List N . 2 displays s me f the devices that make up the
audi and visual system
•
The names f the c mp nents fr m Device Name List N . 2 are sh wn
in the f ll wing table
•
*a: Device Name List No. 1 Description
NAME COMPONENT CONNECTION METHOD
DA Radi and display receiver assembly -
XM*1 Satellite radi antenna assembly -
DSP-AMP*2 Stere c mp nent amplifier assembly C mmunicati n line f r AVC-LAN
*1: w/ SDARS System
*2: f r 11 Speakers
*b: Check Res lt Description
RESULT MEANING ACTION
OK The device d es n t resp nd with a DTC -
DETAIL The device resp nds with a DTC L k up the DTC in "Unit Check
M de"
NCON*1,
*2
The device was previ usly present, but d es n t
resp nd in diagn stic m de
Check p wer supply wire harness
f the device
NRES*1,
*2
The device resp nds in diagn stic m de, but gives n
DTC inf rmati n
Check p wer supply wire harness
f the device
*1: w/ SDARS System
*2: f r 11 Speakers
*e: Device Name List No. 2 Description
NAME COMPONENT CONNECTION METHOD
AUX N . 1 stere jack adapter assembly Vehicle wire harness
Page
4
of
8
AUDIO / VIDEO: AUDIO AND VISUAL SYSTEM(for Radio and Dis lay Ty e): DTC
...
8/
28/
2013
mhtml:file://C:\Users\SB185219\Downloads\RM1000000004ZPI
-
DTC CHECK_CLEAR
...
*f Example
(b) Unit check m de screen descripti n
*f Example
Screen Description
DISPLAY CONTENT
*a: Device name Target device
*b: Hist ry DTC Diagn stic mem ry results and st red DTCs are displayed.
*c: Current DTC DTCs utput in the service check are displayed.
*d: DTC DTC (Diagn stic Tr uble C de)
*e: Diagn sis
clear switch
Pushing this switch f r 3 sec nds clears the diagn stic mem ry data f the target
device (B th resp nse t diagn stic system check result and the displayed data are
cleared.).
HINT:
This screen is updated nce per sec nd. •
A maximum f 6 DTCs can be displayed f r hist ry and present DTCs.•
Page
5
of
8
AUDIO / VIDEO: AUDIO AND VISUAL SYSTEM(for Radio and Dis lay Ty e): DTC
...
8/
28/
2013
mhtml:file://C:\Users\SB185219\Downloads\RM1000000004ZPI
-
DTC CHECK_CLEAR
...
*a Example
(c) Read the system check result.
(1) If the check result is "DETAIL" touch the displayed check result to view the results on the "Unit
Check Mode" screen and record them.
NOTICE:
A maximum of 6 DTCs can be displayed for history and present DTCs on the "Unit check mode"
screen. Therefore when 6 DTCs are displayed troubleshoot those DTCs first and then check the
"Unit check mode" screen again to see if any other DTCs are displayed.
HINT:
When all results are "OK" this means that no DTCs are stored. •
When proceeding to view the results of another device press the "Back" switch to return to the
"System Check Mode" screen. Repeat the step above to view the results of other devices.
•
(2) Check the details of the DTC(s).
Click here
7. DTC CLEAR/RECHECK (CLEAR USING SYSTEM CHECK MODE SCREEN)
Page
6
of
8
AUDIO / VIDEO: AUDIO AND VISUAL SYSTEM(for Radio and Dis lay Ty e): DTC
...
8/
28/
2013
mhtml:file://C:\Users\SB185219\Downloads\RM1000000004ZPI
-
DTC CHECK_CLEAR
...
*a Example
(a) Clear DTCs
(1) Press the "Memory CLR" switch for 3 seconds.
(2) Confirm that the check results are cleared.
HINT:
To clear the DTCs for a specific device clear the DTCs using the "Unit Check Mode" screen. •
When clearing the DTCs using the "Unit Check Mode" screen press the "Code CLR" switch for 3
seconds.
•
*a Example
(b) Recheck
(1) Press the "Recheck" switch.
(2) Confirm that all diagnostic codes are "OK" when the check results are displayed. If a code other
than "OK" is displayed troubleshoot again.
Page
7
of
8
AUDIO / VIDEO: AUDIO AND VISUAL SYSTEM(for Radio and Dis lay Ty e): DTC
...
8/
28/
2013
mhtml:file://C:\Users\SB185219\Downloads\RM1000000004ZPI
-
DTC CHECK_CLEAR
...
*a Example
HINT:
When DTCs are cleared using the "Unit Check Mode" screen press the "Back" switch to return to
the "System Check Mode" screen and perform this operation.
8. FINISH DIAGNOSTIC MODE
(a) Turn the ignition switch off.
Page
8
of
8
AUDIO / VIDEO: AUDIO AND VISUAL SYSTEM(for Radio and Dis lay Ty e): DTC
...
8/
28/
2013
mhtml:file://C:\Users\SB185219\Downloads\RM1000000004ZPI
-
DTC CHECK_CLEAR
...
