Инструкция для
ENG (Установка)
TP-Link TL-WN781ND
Перейти в карточку товара
8 800 775 98 98
1
1. Power down your computer and unplug its power cord;
2. Open the case and locate an available PCI-E slot on the motherboard;
3. Insert the PCI Express Adapter into the PCI-E slot. Make sure that all of its pins
are touching the slot's contacts. You may have to apply a bit of pressure to slide
the adapter all the way in. After the adapter is firmly in place, secure its
fastening tab to your computer's chassis with a mounting screw;
4. Close the case and insert the power cable into the computer, then turn on the
computer.
2
Installing Adapter Driver
Choose Install Driver&Utility
If you are running Windows 2000, please install the device by referring to
the “Installation Guide” part of the User Guide on the included Resource
CD.
Note
You may see the Found New
Hardware Wizard when the
computer boots up. This is the
default setup wizard of Windows
XP. For a smoother installation,
please click “Cancel” and insert
the provided TP-LINK Resource
CD.
Click Cancel
A
fter inserting the provided Resource
CD into your CD-ROM drive, the
Setup Wizard will automatically pop
up on your computer’s screen.
3
Click Next
Choose Install
Driver Onl
y
Click Next
Follow the step-by-step instructions
to finish the driver installation.
If prompted to ‘The software has not
passed Windows Logo testing to
verify its compatibility with Windows
XP’, click Continue Anyway to
continue.
Click Finish
4
Select your network by
the network name
Connecting to the Wireless Router/Access Point
After you have successfully installed the driver software, the icon will appear on
the bottom right-hand corner of your desktop.
If the Wirless Router/Access Point supports Wi-Fi Protected Setup (WPS)
function, you are recommanded to use the QSS (Quick Secure Setup) to
quickly connect to your wireless network. Please refer to the
A
ppendix
Connecting to the Wireless Router by QSS.
Note
Click
Click Connect
Click Connect
Input the Network key of
y
our wireless network
If you don’t know the wireless network key, please consult the network
administrator or log on to the setup page of your Wireless Router/Access
Point with an Ethernet cable to check the wireless security settings. Please
refer to the manual of your Wireless Router/Access Point or contact the
manufactory’s technical support for more details.
Note
Click Refresh network list
5
1
Installing Adapter Driver
You have now successfully connected
to your wireless network.
If your network is an unsecured network, you will not be prompted to input the
Network key. It will connect to your network automatically.
Note
You may see the Found New
Hardware Wizard when the
computer boots up. This is the
default setup wizard of Windows
Vista. For a smoother installation,
please click “Cancel” and insert
the provided TP-LINK Resource
CD.
Click Cancel
6
Click Next
Click Finish
Choose Install Driver&Utility
Follow the step-by-step instructions
to finish the driver installation.
If prompted to ‘Windows can’t verify
the publisher of this driver software’,
click Install the driver software
Anyway to continue.
A
fter inserting the provided Resource
CD into your CD-ROM drive, the
Setup Wizard will automatically pop
up on your computer’s screen.
7
Input the Network key of
y
our wireless network
Connecting to the Wireless Router/Access Point
If the Wirless Router/Access Point supports Wi-Fi Protected Setup (WPS)
function, you are recommanded to use QSS (Quick Secure Setup) to quickly
connect to your wireless network. Please refer to the Appendix Connecting to
the Wireless Router by QSS.
Note
Click this icon at the bottom
right of the desktop and then
click Connect to a network
Select your network by
the network name
Click Connect
Click this button to refresh
the network list
Click Connect
8
Click Close
Save this network for
automaticall
y
connectin
g
You have now successfully
connected to your wireless
network.
If your network is an unsecured network, you will not be prompted to input the
Network key. It will connect to your network automatically.
Note
If you don’t know the wireless network key, please consult the network
administrator or log on to the setup page of your Wireless Router/Access
Point with an Ethernet cable to check the wireless security settings. Please
refer to the manual of your Wireless Router/Access Point or consult the
manufactory’s technical support for more details.
Note
9
Click Install QSS
Installing the QSS Driver
Follow the step-by-step instructions
to finish the QSS installation.
Click Finish
