TP-Link TL-WN910N - Bedienungsanleitung

TL-WN910N

Wireless N CardBus Adapter

2.4GHz 11n/g/b

Rev: 1.0.2

1910010240

Specifications are subject to change without notice. is a registered trademark

of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or

registered trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any means or used to make

any derivative such as translation, transformation, or adaptation without permission from

http://www.tp-link.com

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not in-stalled and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/ TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received, including interference that may cause

undesired operation.

Any changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

FCC RF Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. End users must follow the specific operating instructions for satisfying RF

exposure compliance. This transmitter must not be co-located or operating in conjunction with

any other antenna or transmitter. This equipment has been SAR-evaluated for use in hand.

SAR measurements are based on a 4mm spacing from the body and that compliance is

achieved at that distance.

CE Mark Warning

This is a class B product. In a domestic environment, this product may cause radio interference,

in which case the user may be required to take adequate measures.

National Restrictions

2400.0-2483.5 MHz

Country Restriction Reason/remark

Bulgaria General authorization required for outdoor

use and public service

France

Outdoor use limited to

10 mW e.i.r.p. within

the band 2454-2483.5

MHz

Military Radiolocation use. Refarming of the 2.4

GHz band has been ongoing in recent years to

allow current relaxed regulation. Full

implementation planned 2012

Italy If used outside of own premises, general

authorization is required

Luxembourg None General authorization required for network and

service supply(not for spectrum)

Norway Implemented

This subsection does not apply for the geographical

area within a radius of 20 km from the centre of

Ny-Ålesund

Russian

Federation Only for indoor applications

Note: Please don’t use the product outdoors in France.

TP-LINK TECHNOLOGIES CO., LTD

TP-LINK TECHNOLOGIES CO., LTD.

South Building, No.5 Keyuan Road, Central Zone, Science & Technology Park, Nanshan,

Shenzhen, P. R. China

DECLARATION OF CONFORMITY

For the following equipment:

Product Description: Wireless N CardBus Adapter

Model No.: TL-WN910N

Trademark: TP-LINK

We declare under our own responsibility that the above products satisfy all the technical

regulations applicable to the product within the scope of Council Directives:

Directives 1999/5/EC

The above product is in conformity with the following standards or other normative documents:

ETSI EN 300 328 V1.7.1: 2006

ETSI EN 301 489-1 V1.8.1:2008 & ETSI EN 301 489-17 V1.3.2:2008

EN60950-1:2006

EN62311:2008

Recommendation 1999/519/EC

Person is responsible for marking this declaration:

Yang Hongliang

Product Manager of International Business

CONTENTS

Chapter 1 Introduction ........................................................................................ 2

1.1 Overview of the Product ...................................................................................... 2

1.2 Features .............................................................................................................. 2

1.3 LED Status .......................................................................................................... 3

Chapter 2 Installation Guide ............................................................................... 4

2.1 Hardware Installation........................................................................................... 4

2.2 Software Installation ............................................................................................ 4

2.2.1 Overview................................................................................................. 4

2.2.2 Software Installation for Windows XP ..................................................... 4

Chapter 3 Configuration....................................................................................11

3.1 Current Status.................................................................................................... 11

3.2 Profile Management........................................................................................... 13

3.2.1 Add or Modify a Configuration Profile.................................................... 13

3.2.2 Remove a profile................................................................................... 18

3.2.3 Switch another Profile........................................................................... 18

3.2.4 Export a Profile...................................................................................... 19

3.2.5 Import a Profile...................................................................................... 19

3.2.6 Scan Available Networks ...................................................................... 20

3.2.7 Auto Profile Selection Management...................................................... 20

3.3 Diagnostics........................................................................................................ 21

3.3.1 Check Driver Information ...................................................................... 22

3.3.2 Check Receive and Transmit Statistical Information............................. 22

3.4 Configuration for Windows Vista........................................................................ 23

Appendix A: Specifications................................................................................... 26

Appendix B: Glossary............................................................................................27

Package Contents

The following items should be found in your package:

¾One TL-WN910N Wireless N CardBus Adapter

¾Quick Installation Guide

¾One resource CD for TL-WN910N, including:

•TP-LINK Wireless N Client Utility (11NWCU) and Drivers

•User Guide

•Other Helpful Information

)Note:

Make sure that the package contains the above items. If any of the listed items are damaged or

missing, please contact with your distributor.

Conventions:

The ‘Adapter’ mentioned in this User Guide stands for TL-WN910N Wireless N CardBus

Adapter without any explanations.

TL-WN910N Wireless N CardBus Adapter

Chapter 1 Introduction

Thank you for choosing the TL-WN910N Wireless N CardBus Adapter!

1.1 Overview of the Product

The adapter is a 802.11n client device; it is designed to provide a high-speed and unrivaled

wireless performance for your notebook. With a faster wireless connection, you can get a better

Internet experience, such as downloading, gaming, video streaming and so on.

With the 802.11n technology, higher throughput improvements using MIMO (multiple input,

multiple output antennas), the TL-WN910N’s auto-sensing capability allows high packet transfer

rate of up to 300Mbps for maximum throughput. It has good capability on anti-jamming, and it can

also interoperate with other wireless (802.11b) products. The adapter supports WEP, WPA and

WPA2 encryption to prevent outside intrusion and protect your personal information from being

exposed.

The adapter is easy to install and manage. The Quick Setup Wizard guides you step-by-step

through the installation process; the TP-LINK Wireless N Client Utility helps you create a wireless

connection immediately.

With unmatched wireless performance, reception, and security protection, the TL-WN910N is the

best choice for easily adding or upgrading wireless connectivity to your notebook computer.

1.2 Features

¾Complies with IEEE802.11n, IEEE802.11g, IEEE802.11b standards

¾Supports WPA/WPA2 data security, IEEE802.1x authentication, TKIP/AES encryption,

64/128/152-bit WEP encryption

¾Supports high rate of up to 300Mbps for maximum throughput, supports automatically

adjust to lower speeds due to distance or other operating limitations

¾Provides 32-bit CardBus interface

¾Supports Ad-Hoc and Infrastructure modes

¾Good capability on anti-jamming

¾Supports roaming between access points when configured in Infrastructure mode

¾Ease to configure and provides monitoring information

¾Supports Windows 2000, XP, Vista

¾Built-in three internal antennas which are listed in a format of 2x3 for three receivers and

two transmitters.

TL-WN910N Wireless N CardBus Adapter

1.3 LED Status

LED Indications Status Working Status

Status Blue Flashing

Alternately

Activity Blue Flashing

Alternately

The adapter is trying to scan a networking

connection.

Status Blue Intermittently

Activity Blue Intermittently

The adapter is already connected but is not

transmitting or receiving data.

Status Blue Flashing

Activity Blue Flashing The adapter is transmitting or receiving data.

TL-WN910N Wireless N CardBus Adapter

Chapter 2 Installation Guide

2.1 Hardware Installation

To install the adapter, follow these steps listed as below:

1. Locate an available CardBus slot on your laptop.

2. With the connector pin end facing the CardBus slot and the label facing up, slide the

Adapter into the CardBus slot until it locks in place.

)Note:

Once the Adapter is firmly in place, the Found New Hardware Wizard screen will pop up.

2.2 Software Installation

2.2.1 Overview

The Adapter’s Setup Wizard will guide you through the Installation procedure for Windows 2000,

XP and Vista. The Setup Wizard will install the TP-LINK Wireless N Client Utility (11NWCU) and

drivers.

When you install the hardware prior to before installing the software, the system will prompt

“Found New Hardware Wizard”, click Cancel, and run the Setup Wizard program on the

CD-ROM.

The Setup steps for Windows 2000, XP and Vista are very similar. The following setup steps

are for Windows XP.

2.2.2 Software Installation for Windows XP

1. Insert the Resource CD into your CD-ROM drive, and open the folder with the same name

as your product. Then double-click Setup.exe in the proper folder according to your

operating system to start the installation. After that, Figure 2-1 will appear. You can click

Cancel to end the installation in the screen above.
