TP-Link Archer T2E Bedienungsanleitung

User Guide

AC600 Wireless Dual Band PCI Express Adapter

Archer T2E

Contents

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01

Chapter 1. Get to Know About Your Adapter . . . . . . . . . . . . . . . . . . . 02

1. 1. Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .03

1. 2. LED Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .04

Chapter 2. Connect to a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 05

Chapter 3. Use Your Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08

3. 1. Install Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .09

3. 2. Join a Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

3. 3. Uninstall Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Appendix: Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

About This Guide

This guide is a complement to Quick Installation Guide. The Quick Installation

Guide instructs you on quick installation, and this guide provides the product

overview and more detailed instructions for each steps.

When using this guide, please notice that features available of the adapter may

vary by model and software version. It may also vary by region or ISP. All images,

steps, and descriptions in this guide are only examples and may not reflect your

actual experience.

Conventions

In this guide, the following conventions are used:

Convention Description

Underlined Underlined words or phrases are hyperlinks. You can click to redirect to a

website or a specific section.

Teal Contents to be emphasized and texts on the web page are in teal, including

the menus, items, buttons, etc.

Note: Ignoring this type of note might result in a malfunction or damage to the

device.

Tips: Indicates important information that helps you make better use of your

device.

*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications.

Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1)

environmental factors, including building materials, physical objects, and obstacles, 2) network conditions,

including local interference, volume and density of traffic, product location, network complexity, and

network overhead, and 3) AP limitations, including rated performance, location, connection quality, and AP

condition.

‡Use of MU-MIMO and WPA3 requires both the AP and system to support the corresponding features.

More Info

• The latest driver can be found at Download Center at

https://www.tp-link.com/support.

• The Quick Installation Guide (QIG) can be found where you find this guide or

inside the package of the product.

• Specifications can be found on the product page at https://www.tp-link.com.

• A TP-Link Community is provided for you to discuss our products at

https://community.tp-link.com.

Chapter 1

Get to Know About Your

Adapter

This chapter introduces the detail of the adapter.

Chapter 1 Get to Know about Your Adapter

1. 1. Product Overview

The Archer T2E receives Wi-Fi signals on two separate bands for all your online

needs. Choose the 2.4 GHz band for browsing, email and social media, or switch

to 5 GHz band for gaming and streaming. The Archer T2E can work with MU-

MIMO routers, which provide simultaneous data streams, boosting throughput

and efficiency.

• Standards: IEEE 802.11b/g/n 2.4GHz, IEEE 802.11a/n/ac 5GHz

• Interface: PCI Express

• Antenna: 1 Detachable External Antenna

• LED: Status

• Security: WEP, WPA/WPA2/WPA3, WPA-PSK/WPA2-PSK/WPA3-SAE

• Dimensions: 4.76 × 3.09 × 0.85 in (120.8 × 78.5 × 21.5 mm)

Chapter 1 Get to Know about Your Adapter

1. 2. LED Status

You can check the adapter’s working status by following the LED Explanation

table.

Status Indication

On The adapter has been installed.

Off The adapter is not installed or not detected.

Tips:

If the LED is off, try these troubleshooting tips:

1. Remove and reinstall the adapter.

2. Refer to Troubleshooting-T2 to check if the adapter is recognized and enabled. Reinstall the adapter

software, if necessary.

Chapter 2

Connect to a Computer

This chapter introduces how to connect the adapter to your computer.

Please note that images are for demonstration only.

Chapter 2 Connect to a Computer

Follow the steps below to insert the adapter into your computer:

1. Turn off the computer, unplug the power cable and remove the case panel.

2. Locate an available PCI-E slot and carefully insert the adapter.

Chapter 2 Connect to a Computer

3. Connect the antennas to the adapter.

4. Replace the case panel, plug in the power cable and turn on your computer.

Note:

If the bracket is not suitable for your computer, detach it from the adapter’s board and replace it with the

low-profile bracket provided.

Chapter 3

Use Your Adapter

This chapter introduces how to install or uninstall your adapter’s Wi-Fi driver,

connect to a wireless network on a Windows system.

This chapter includes the following sections:

• Install Driver

• Join a Wireless Network

• Uninstall Driver
