User Guide

4G LTE Mobile Wi-Fi

M7000/M7010

Contents

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Chapter 1. Get to Know About Your Mobile Wi-Fi. . . . . . . . . . . . . . . . . . . . . .3

1. 1. Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1. 2. Physical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1. 2. 1.The Exterior. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1. 2. 2.The Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Chapter 2. Set Up Internet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

2. 1. Install the Mobile Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2. 2. Connect to the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Chapter 3. Log In. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3. 1. Via tpMiFi App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3. 2. Via PC Login Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3. 3. Via Phone Login Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Chapter 4. Manage Your Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4. 1. Track Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4. 1. 1.Check Data Usage on the tpMiFi App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4. 1. 2.Check Data Usage via SMS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

4. 1. 3.Revise Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4. 2. Limit Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4. 2. 1.Limit Data Package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4. 2. 2.Limit Monthly Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

4. 3. Set Usage Limit for Specific Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4. 4. Set Rate Limit for Specific Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4. 5. Set Up Free Data Period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4. 6. Enable Mobile Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4. 7. Enable Data Roaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Chapter 5. Secure Your Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

5. 1. Secure Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

5. 2. Block Unwelcome Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

5. 3. Lock SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Chapter 6. Customize Your Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

6. 1. Specify Network Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

6. 2. Configure APN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

6. 2. 1.Configure APN Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

6. 2. 2.Configure Network Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

6. 3. Configure DHCP Server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Chapter 7. Manage Your Mobile Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

7. 1. Save the Mobile Wi-Fi’s Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

7. 2. Change Login Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

7. 3. Set Up System Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

7. 4. Restore Configuration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

7. 5. Update the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

7. 6. Update ISP Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

7. 7. System Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

About This Guide

This guide is a complement of Quick Installation Guide. The Quick Installation

Guide provides instructions for quick internet setup, while this guide contains

details of each function and demonstrates how to configure them.

Features available in the Mobile Wi-Fi may vary by model and software version.

Mobile Wi-Fi availability may also vary by region or ISP. All images, steps, and

descriptions in this guide are only examples and may not reflect your actual

Mobile Wi-Fi experience.

Conventions

In this guide the following conventions are used:

Convention Description

Underlined Underlined words or phrases are hyperlinks. You can click to redirect to a website or a

specific section.

Teal Contents to be emphasized and texts on the web page are in teal, including the menus,

items, buttons and so on.

The menu structures to show the path to load the corresponding page. For example,

Advanced > Wireless > Black List means the Black List page is under the Wireless menu

that is located in the Advanced tab.

Note: Ignoring this type of note might result in a malfunction or damage to the device.

Tips: Indicates important information that helps you make better use of your device.

*Maximum wireless signal rates are the physical rates derived from IEEE

Standard 802.11 specifications. Actual wireless data throughput and wireless

coverage are not guaranteed and will vary as a result of 1) environmental

factors, including building materials, physical objects, and obstacles, 2) network

conditions, including local interference, volume and density of traffic, product

location, network complexity, and network overhead, and 3) client limitations,

including rated performance, location, connection, quality, and client condition.

*Battery life estimates obtained through testing in a laboratory setting.

More Info

The latest software, management app and utility are available at the Download

Center at https://www.tp-link.com/support.

The Quick Installation Guide can be found in the same place you found this guide

or inside the package of the Mobile Wi-Fi.

Specifications can be found on the product page at https://www.tp-link.com.

TP-Link Community is provided for you to discuss our products and share

knowledge at https://community.tp-link.com.

Our Technical Support contact information can be found at Contact Technical

Support page at https://www.tp-link.com/support.

Chapter 1

Get to Know About Your

Mobile Wi-Fi

This chapter introduces what the Mobile Wi-Fi can do and its appearance.

It includes the following sections:

• Product Overview

• Physical Description

Chapter 1 Get to Know About Your Mobile Wi-Fi

1. 1. Product Overview

The Faster Connections, The More You Can Do

Just insert a SIM card to create your reliable personal Wi-Fi hotspot and share

instant 4G/3G connectivity with friends. The Mobile Wi-Fi, supporting the latest

generation 4G LTE network, can reach a faster download speed so that users

can enjoy HD movies without interruption, download files in seconds, and hold a

video chat without dropouts.

Artful Little Gadget and Built-in Battery for Life on the Go

The TP-Link Mobile Wi-Fi features a compact, elegant design and rechargeable

powerful battery very suitable for travel, business trips and outdoor activities.

With added flexibility, the device can be charged via a micro USB cable connected

to an adapter, laptop or portable charger for endless hours of 4G sharing.

Easy Management with the tpMiFi App

With the tpMiFi App, you can conveniently access and manage the Mobile Wi-Fi

right on your iOS/Android devices. The tpMiFi app allows you to set data limits,

control Wi-Fi access and send messages.

Chapter 1 Get to Know About Your Mobile Wi-Fi

1. 2. Physical Description

1. 2. 1. The Exterior

LEDs

Power Butt

Micro USB Port

LED Explanation

LED Status Indication

(Wi-Fi)

On Wi-Fi is enabled.

Off Wi-Fi is disabled.

(Internet)

On Internet service is available.

Off Internet service is unavailable.

(Battery)

On Power is on.

Off Power is off.

Blinking Red The battery level is lower than 10%.

Blinking Green The Mobile Wi-Fi is charging.

Note:

The LEDs will turn off automatically after idling for 30 seconds. To check the LED status, press the Power

button to turn them on again.

Item Explanation

Item Description

Power Button • Press and hold to power on/off the Mobile Wi-Fi.

• Press to turn on LEDs if they are off after idling.

Micro USB Port Plug in the USB cable to this port to charge your Mobile Wi-Fi.

Chapter 1 Get to Know About Your Mobile Wi-Fi

1. 2. 2. The Interior

SSID:

TP-Link_XXXX

Wireless Password:

XXXXXXXX

Reset Button

SIM Card Slo

Item Explanation

Item Description

SIM Card Slot Insert a SIM card into the slot. A micro or nano SIM card must be converted

using a SIM card adapter.

Reset Button With the Mobile Wi-Fi powered on, use a pin to press and hold this button until

all LEDs turn on momentarily to reset the Mobile Wi-Fi.

Note:

1. The label is under the battery pack.

2. Resetting the device to its factory defaults will clear all previous configuration.

Chapter 2

Set Up Internet

Connection

This chapter introduces how to install the Mobile Wi-Fi and connect your wireless

or smart devices to the internet.

It includes the following sections:

• Install the Mobile Wi-Fi

• Connect to the Internet
