Before cable connection, keep your hands dry. If you currently use a

modem, disconnect it now - the Modem Router will replace your current

modem.

Connect your computer to the Port

labeled “1~4” on the Router with

an Ethernet cable.

Connect the splitter to the wall jack

using a telephone line, then use

the other telephone line to connect

to the ADSL port on the Router

and the MODEM port of the

splitter, also have the PHONE port

of the splitter connected to a

telephone.

If no telephone is needed, please connect the ADSL port of the Router to

the wall jack using the telephone line directly.

Note Please use only wired network connections to configure the Router.

Installation

Note

The product model shown in this QIG is TD-W8951ND, as an example.

Note

Plug the provided Power Adapter

into the Power jack on the back of

the Router and the other end to a

standard electrical wall socket.

Power on all your network devices and then check to see if the LEDs of the

Router display normally as the diagram below describes.

If the LEDs display abnormally, please check to see if all the cable

connectors (power adapter, phone line and Ethernet cable) are well

connected to your device. With the phone line well connected, if the ADSL

LED turns off after flashing, please contact your ISP to ensure that you

internet connection is active.

Note

Power: Solid light

ADSL: Solid light or flashing

WLAN: Solid light or flashing

LAN: Solid light if the corresponding

port is connected

Insert the provided Resource

CD into your CD-ROM drive.

The Setup Wizard will

automatically pop up on

your computer’s screen.

To configure the device, you can either run the setup CD (method one), or run

the Web-based Quick Setup Wizard (method two). TP-LINK strongly

recommends that you run the setup CD.

Note

Please select your product

model and click Start Setup

The configuration has now been completed. Please skip to Step 3 “Testing the

Internet Connection”.

The basic settings for your Router are completed. Please open the web browser

and try to log on to some popular website to test your Internet connection, for

example:

http://www.tp-link.com

http://www.google.com

If the above websites can be accessed, it indicates that your Router has been

configured successfully and you can start to enjoy the Internet. If the websites

cannot be accessed, please refer to “T4. What can I do if I cannot access the

Internet?” in the Troubleshooting guide.

For the advanced configurations, please refer to the User Guide on the

CD provided.

Note

Note The above configurations only need to be set once. If you want other

computers in your LAN to access the Internet, please connect the desired

computer to the ADSL Router directly. If the additional computer can not

access the Internet, please set that computer referring to “T3. What can I

do if I cannot access the web-based configuration page?” in the

Troubleshooting guide.

Then a flash video will pop up and

show you how to connect you

devices. After that, the Easy Setup

Assistant will start.

Click NEXT, and then follow

the step-by-step instructions

until you complete the

confi

uration

Note

T1. How do I restore my Router’s configuration to its factory default settings?

T2. What can I do if I don’t know or forget my password?

1) Restore the Router’s configuration to its factory default settings. If you don’t

know how to do that, please refer to section T1.

2) Use the default user name and password: admin, admin.

3) Try to configure your Router once again by following the instructions in the

previous steps of the QIG.

T3. What can I do if I cannot access the web-based configuration page?

1) Configure your computer’s IP Address.

For Windows 7 OS

Once the Router is reset, the current configuration settings will be lost and

you will need to re-configure the Router.

With the Router powered on, press

and hold the RESET button on the

rear panel for 8 to 10 seconds

before releasing it.

Press it for 8 to 10 seconds

Troubleshooting

Go to Start > Settings > Control

Panel, and then you will see the

following page.

Click View network

status and tasks

Right-click Local Area

Connection

Click Properties

Click Change adapter settings

Double-click Internet Protocol

ersion 4 (TCP/IPv4)

For Windows Vista OS

Go to Start > Settings

>Control Panel, and then

you will see the following

page.

Click View status

Click View network

status and tasks

Select Obtain an IP

address automatically

Select Obtain DNS server

address automatically

Click OK

Click Properties

Double-click Internet Protocol

ersion 4 (TCP/IPv4)

For Windows XP OS

Select Obtain an IP address

automatically

Select Obtain DNS server

address automatically

Click OK

Go to Start > Control Panel, you

will then see the following page.

Click Network and Internet

Connections

Click Network Connections

Right-click Local Area

Connection

Click Properties

Double-click Internet

Protocol (TCP/IP)
