TP-Link TL-MR3020 Bedienungsanleitung
Quick Installation Guide
3G/4G Wireless N Router
7106506987 REV2.0.0
www.tp-link.com
Specificaons are subject to change without noce. is a registered trademark of TP-Link Technologies Co., Ltd. Other
brands and product names are trademarks or registered trademarks of their respecve holders.
No part of the specificaons may be reproduced in any form or by any means or used to make any derivave such as
translaon, transformaon, or adaptaon without permission from TP-Link Technologies Co., Ltd.
Copyright © 2016 TP-Link Technologies Co., Ltd. All rights reserved.
01 / English
07 / Български
13 / Čeština
19 / Eesti
25 / Қазақша
31 / Latviešu
37 / Lietuvių
43 / Magyar
49 / Polski
55 / Русский язык
61 / Română
67 / Slovenčina
73 / Srpski jezik/Српски језик
CONTENTS
1
English
Determine Operation Mode
Refer to the following table to determine an appropriate operation mode as
needed.
Mode
Switch
Operation
Mode Scenario
3G/4G 3G/4G
Router I want to share the 3G/4G network with my local devices.
WISP WISP Client
Router
I want to have internet access from a Wireless Internet Service
Provider (WISP), and share internet with local devices.
AP Access
Point
I want to access internet wirelessly, but only a wired network is
available.
Connect the Hardware
1. Switch the operation mode to the determined one.
Note: By setting the router to AP Mode, you can also access the other four modes:
Repeater, Bridge, Client and Multi-SSID. For details, please refer to the User Guide at
2
English
www.tp-link.com.
2. Connect the hardware according to the diagram below.
■3G/4G Router
A
B
C
3G/4G USB Modem
3
English
■WISP Client Router
A B
■Access Point
B
CD
A
Wired Router
Internet
4
English
Congure the Router
1. Connect your device to the router wirelessly. The SSID (wireless network
name) and password are printed on the router’s label.
2. Launch a web browser and type http://tplinkwifi.net in the address bar.
Enter admin for both username and password to log in.
3. Go to Quick Setup and click Next to start.
4. Follow the step-by-step instructions to complete the initial
configuration.
Enjoy internet!
Note: If you have changed the default SSID and password, you have to reconnect your
wireless devices to the new Wi-Fi network.
FAQ (Frequently Asked Questions)
Q1. What can I do if I forgot my web management password?
• Refer to FAQ > Q3 to reset the router, and then use the default admin (all
5
English
lowercase) for both username and password to log in.
Q2. What can I do if I cannot log in to the web management page?
• If the computer is set to a static or xed IP address, change the setting to obtain
an IP address automatically.
• Verify that http://tplinkwi.net is correctly entered in the web browser. Alternatively,
check spacing and enter http://192.168.0.254 in the web browser.
• Use another web browser and try again.
• Reset your router to its factory default settings ( FAQ > Q3) and try again.
• Disable and then enable the network adapter in use.
Q3. How do I restore the router to its factory default settings?
• With the router powered on, press and hold the WPS/Reset button for 8 to 10
seconds and then release the button.
Q4. What can I do if I cannot access internet with an identied 3G/4G
USB modem?
• Insert a suited SIM/UIM card into the 3G/4G USB modem correctly.
• Plug your 3G/4G USB modem directly into your PC and disable the PIN verication
via the modem utility.
• Verify that the 3G/4G USB modem works well on your PC.
• Consult your ISP for the latest dial number and APN (Access Point Name), and
6
English
correct the preset information manually.
Q5. What can I do if the "Unknown Modem" message displays?
• Launch a web browser, enter www.tp-link.com in the address bar and go to
Support > Compatibility List. And check whether your 3G/4G USB modem is on
the 3G/4G Compatibility List. If the latest rmware or bin le doesn't support your
modem, please contact our technical support.
Q6. How to update the rmware of the router?
1. Go to the router's product page at www.tp-link.com, and download the latest
rmware.
2. Connect your computer to the router via an Ethernet cable (recommended) or
wirelessly.
3. Log in to the web management page and go to System Tools > Firmware Upgrade
to update the router.
7
Български
Определяне на режима на работа
Разгледайте следната таблица, за да определите подходящия режим
на работа според нуждите.
Превключвател
на режима
Режим на
работа Сценарий
3G/4G 3G/4G
рутер
Искам да споделям 3G/4G мрежата с моите локални
устройства
WISP
WISP
клиент
рутер
Искам да получавам достъп до интернет от
доставчик на безжични интернет услуги (Wireless
Internet Service Provider (WISP)), и да споделям
интернета с локални устройства.
AP Точка за
достъп
Искам безжичен достъп до интернет, но има само
кабелна мрежа
Свързване на хардуера
1. Превключете режима на работа на този, който сте определили.
Забележка: Като поставите рутера в режим "Точка за достъп", вие също така
8
Български
имате достъп и до останалите четири режима: Повторител, Мост, Клиент и
Мулти-SSID. За подробности, вижте Ръководството за потребителя на
www.tp-link.com.
2. Свържете хардуера съгласно схемата по-долу.
■ 3G/4G рутер
A
B
C
3G/4G USB модем
