TP-Link TL-WR841N Bedienungsanleitung

7106504693 REV1.0.0

Specifications are subject to change without notice. TP-LINK is a registered

trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product

names are trademarks or registered trademarks of their respective

holders.

No part of the specifications may be reproduced in any form or by any

means or used to make any derivative such as translation, transformation,

or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.

www.tp-link.com

300M Wireless N Router

Model No.TL-WR841N

Quick Installation Guide

TP-LINK TECHNOLOGIES CO., LTD.

English

Français

CONTENTS

English...................................................................... 1

Français.................................................................. 13

English Français

Quick Installation Guide

Note Please select your preferred conguration method:

Method 1 >> Conguration via CD Setup Wizard

For Windows users only

Method 2 >> Conguration via Web-based Quick

Setup Wizard

For Mac OS/Linux users or Windows

users who cannot run mini CD

Package Contents

TL-WR841N Power Adapter

Ethernet Cable Resource CD

QIG

English

Français

Hardware Connection

Power off your modem.

Connect the WAN port on your Router to the modem’s LAN

port with an Ethernet cable.

Connect your computer to one of the LAN ports labeled 1~4

on the Router with an Ethernet cable.

Power on the modem and wait for one minute.

Plug the provided POWER Adapter into the POWER jack

on the back of the Router and the other end to a standard

electrical wall socket.

Press the ON/OFF button to power on the Router.

Note Please conrm that the WLAN light is ON so that client

devices can connect to the router wirelessly. Press the

WIFI button for more than 2 seconds to turn on or turn

off the wireless function.

WIFI

ON/OFF

WPS/

RESET

Wall Socket

Cable/DSL Modem

Internet

Wireless N Router

To WAN port

To the modem’s LAN port

Line

Cable Cable

To LAN port

Wall Socket

English Français

Method One:

Conguration via CD Setup Wizard

Note This method is only for Windows users who can run the

mini CD.

1. Insert the TP-LINK Resource CD into the CD-ROM drive.

2. Select TL-WR841N and click Easy Setup Assistant.

English

Français

3. Select your language from the drop-down menu. Click START

and the Easy Setup Assistant will guide you step by step to

set up the Router.

4. Follow the instructions until you see the screen below. Click

FINISH to complete the setup.

Note You can click WEB management interface for more

advanced settings.

English Français

Method Two:

Conguration via Web-based Quick Setup Wizard

Note This method is for Mac OS/Linux users or Windows

users who cannot run the mini CD.

1. Open your browser and type http://tplinklogin.net in the

address eld, then use the user name admin and password

admin to log in.

2. Click Next in the pop up Quick Setup page.

Note If the login window fails to pop up or you cannot access

the management page after the login window, please

refer to Troubleshooting-2.

Note The Router will automatically detect the Internet

connection. If the Internet is available, the Router will

direct you to Step 5; otherwise, you need to continue

with Step 3.

English

Français

3. Select Auto-Detect to detect the Internet connection type and

click Next. (The Dynamic IP is the suitable connection type for

most cases, so we take it as an example in the following.)

4. If Dynamic IP is detected, there will appear the MAC Clone

page. In most cases, there is no need to clone the MAC

address. You can select “No, I do NOT need to clone MAC

address” and then click Next to continue.

English Français

5. You can rename your wireless network and create your own

password on this page. The default wireless network name

is TP-LINK_XXXXXX; and the default wireless password, the

same as the PIN code, is printed on the bottom label. Click

Next to continue.

6. Click Finish to make your settings take effect.

English

Français

Appendix: Additional Features

You can set up additional features by referring to the Technical

Support page on the TP-LINK website or the User Guide on the

resource CD.

Scan the QR code to access the

Technical Support page.

Or access the website:http://

www.tp-link.com/en/support/faq/

Open ports for Game Console FAQ ID: 72

Set up Bandwidth Control FAQ ID: 194

Set up Parental Control FAQ ID: 350

Set up Access Control FAQ ID: 359

Set up WDS Bridging FAQ ID: 440

Set up/Change the wireless security settings FAQ ID: 256

Upgrade the rmware FAQ ID: 296

Restore the factory default settings FAQ ID: 426
