User Guide

TL-SF1016

TL-SF1016DS

TL-SF1024

TL-SF1024D

TL-SF1048

16/24/48-port 10/100Mbps Fast Ethernet Switch

Rev: 2.0.1

7106503501

Specifications are subject to change without notice. is a

registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and

product names are trademarks or registered trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any means or

used to make any derivative such as translation, transformation, or adaptation

http://www.tp-link.com

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at

his own expense.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received, including interference that

may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

CE Mark Warning

This is a class A product. In a domestic environment, this product may cause radio

interference, in which case the user may be required to take adequate measures.

Note:

As for TL-SF1016DS, TL-SF1016, TL-SF1024D and TL-SF1024, a fuse resistor is

used in the “F1” position on the PCB of the power module. The fuse resistor

should be used with the following type: 10ohm 2W@25℃.

CONTENTS

Package Contents ................................................................................................ 1

Chapter 1 Product Introduction....................................................................... 2

1.1 Product Overview .............................................................................................2

1.2 Features ...........................................................................................................2

Chapter 2 Identifying External Components .................................................. 3

2.1 Front Panel .......................................................................................................3

2.2 Rear Panel........................................................................................................3

Chapter 3 Installation ....................................................................................... 5

3.1 Precautions.......................................................................................................5

3.2 Installation ........................................................................................................6

3.2.1 Desktop Installation.................................................................................6

3.2.2 Rack Installation......................................................................................6

3.3 Connect to Ground ...........................................................................................8

3.4 Power on ..........................................................................................................9

Appendix A: Specifications ............................................................................... 10

Appendix B: Troubleshooting ............................................................................11

Package Contents

The following contents should be found in your box:

¾One TL-SF1016/TL-SF1016DS/TL-SF1024/TL-SF1024D/TL-SF1048 Switch

¾One power cord

¾This User Guide

¾Mounting screws and two “L” planks

Note:

Make sure that the package contains the above items. If any of the listed items are

damaged or missing, please contact with your distributor. TL-SF1016DS and TL-

SF1024D do not include mounting screws and two “L” planks.

Chapter 1 Product Introduction

This chapter describes the features of the model of TL-SF1016/TL-SF1016DS/TL-

SF1024/TL-SF1024D/TL-SF1048 16/24/48-port 10/100Mbps Fast Ethernet Switch.

TL-SF1016, TL-SF1024 and TL-SF1048 just differ in the size, the number of LED

indicators and ports, and all figures in this guide are of TL-SF1016.

1.1 Product Overview

TL-SF1016/TL-SF1016DS/TL-SF1024/TL-SF1024D/TL-SF1048 16/24/48-port Switch

provides 16/24/48 10/100Mbps Auto-Negotiation RJ45 ports. Each port of the

TL-SF1016 / TL-SF1016DS / TL-SF1024 / TL-SF1024D / TL-SF1048 supports

auto MDI/MDI-X function, eliminating the need for crossover cables or Uplink ports.

The Switch is Plug- and-Play and any port can be simply plugged into a server, a

hub or a switch, using straight cable or crossover cable.

The TL-SF1016/TL-SF1016DS/TL-SF1024/TL-SF1024D/TL-SF1048 16/24/48-port

10/100Mbps Fast Ethernet Switch provides you with a low-cost, easy-to-use, high-

performance, seamless and standard upgrade to improve your old network to a

100Mbps network. It will boost your network performance up to full duplex data

transfer.

1.2 Features

¾Complies with IEEE802.3, IEEE802.3u standards

¾16/24/48 10/100Mbps Auto-Negotiation RJ45 ports supporting Auto-

MDI/MDIX

¾Supports IEEE802.3X flow control for full-duplex mode and backpressure for

half-duplex mode

¾LED indicators for monitoring power, link, activity, speed

¾Rack-mountable steel case

¾Internal power supply

Chapter 2 Identifying External Components

This Chapter describes the front panel, rear panel and LED indicators of the

Switch.

2.1 Front Panel

The front panel of TL-SF1016 consists of switch model, switch LED indicators, and

16 10/100Mbps RJ-45 ports.

Figure 2-1 TL-SF1016 Switch Front Panel sketch

The LED indicators include Power, Link/Act LED indicators, which are used for

monitoring and pre-troubleshooting of the Switch. The following section shows the

LED indicators of the Switch along with an explanation of each indicator.

¾Power LED: This indicator will light solid red when the Switch powers up. If

the LED is not lit, please check the power supply and connection.

¾Link/Act LED: The LED indicates Link/Active status. The corresponding LED

indicator will light solid green when connected to a network device. It flashes

green when data is being transmitted or received on the working connection.

¾100Mbps: The corresponding port LED indicator will light solid green when

it's working on 100Mbps speed. Not lit indicates working on

10Mbps speed.

Note:

Because of the difference among the mode of switch, some switches don’t include

the 100Mbps indicator, such as TL-SF1048, TL-SF1016DS, TL-SF1024D and a

few of TL-SF1016 switch.

2.2 Rear Panel

The rear panel of TL-SF1016 features a power socket and a Grounding Terminal

(marked with ).

Figure 2-2 TL-SF1016 Switch Rear Panel sketch

¾Grounding Terminal: TL-SF1016 already comes with Lightning Protection

Mechanism. You can also ground the Switch through the PE (Protecting Earth)

cable of AC cord or with Ground Cable. For detail information, please refer to

section 3.3 Connect to Ground.

¾AC Power Socket: Connect the female connector of the power cord here, and

the male connector to the AC power outlet. Please make sure the voltage of

the power supply meets the requirement of the input voltage.

Note:

Because of the difference among the mode of switch, some switches don’t include

the Grounding Terminal, such as TL-SF1048 and a few of TL-SF1016 and TL-

SF1024 switches.

Chapter 3 Installation

3.1 Precautions

To ensure a long-term and stable performance of the Switch, please pay attention

to the following before the installation.

1) Safety Requirements

•Before cleaning the Switch, cut off the power supply. Do not clean it by the

waterish cloth, and never use any other liquid cleaning method.

•Take waterproof measures during storage, transportation and operation of

the equipment.

•Use only the power cord provided with the Switch.

•Make sure the voltage of the power supply meets the requirement of the

input voltage of the Switch.

•Do not push any objects into the openings of the Switch.

•Ensure the vent hole is well ventilated and unblocked.

•Do not open or remove the cover of the Switch.

2) Location Requirements

When you choose a location for the Switch, please follow these guidelines:

•Install the Switch on a flat and stable surface that can support the entire

weight of the Switch with all fittings.

•Locate the Switch far from strong electromagnetic field generators (such as

motors), vibration, dust, and direct exposure to sunlight.

•To ensure adequate air flow around the Switch. At least 10 cm (4 inches) of

space at the front and rear of the Switch is needed for ventilation.

•Make sure that the Switch will be accessible and that the cables can be

easily connected.

•Position the Switch away from water and moisture sources, be sure to

provide an acceptable temperature and humidity operating environment.

3.2 Installation

This Switch can be either installed on the standard 19-inch mountable rack or

located on the desktop.

Caution:

Please unplug the power cord before installing or removing the Switch.

3.2.1 Desktop Installation

To install the Switch on the desktop, please follow the steps:

1) Set the Switch on a flat surface strong enough to support the entire weight of

the Switch with all fittings.

2) Remove the adhesive backing papers from the rubber feet.

3) Turnover the Switch and attach the supplied rubber feet to the recessed areas

on the bottom at each corner of the Switch.

Figure 3-1 Attaching Rubber Feet

4) Upturn the Switch and connect it to the network devices while keep enough

ventilation space around.

5) Connect the Switch to power source with the provided power cord.

Caution:

Please avoid any heavy thing placed on the Switch.

3.2.2 Rack Installation

To install the Switch in an EIA standard-sized, 19-inch rack, follow the instructions

described below:
