TEW-424UB

Quick Installation Guide

Table of Contents

Version 04.28.2006

English .....................................................................................................

Troubleshooting ........................................................................................

1. Before You Start

2. ....................................................................................

................................................................................

How to Install

3. Wireless Configuration ......................................................................

System Requirements

Application

USB port: 1.1 or 2.0

CD-ROM Drive

CPU: Intel Pentium 300MHz or above

Memory: 32MB RAM or above

Windows XP/2000/ME/98SE

TEW-424UB

Utility & Driver CD-ROM

Quick Installation Guide

Package Contents

1. Before You Start

English

54Mbps

Wireless Firewall Router

(TEW-432BRP)

802.11g

Notebook with 54Mbps

Wireless PC Card

(TEW-421PC)

Cable/

DSL Modem

Workstation with 54Mbps

Wireless USB 2.0 Adapter

(TEW-424UB)

Workstation with 54Mbps

Wireless PCI Adapter

(TEW-423PI)

2. How to Install

English

1. Insert the Utility & Driver CD-

ROM into your computer's CD-

ROM Drive and then click Install

Utility.

3. Click Continue Anyway.

2. Follow the InstallShield Wizard

instructions.

Important! DO NOT install the USB adapter in the computer until instructed to

do so.

Note: Refer to the User's Guide on the Driver CD-ROM for Windows 98SE and

Windows ME installation instructions

For Windows Users

Windows XP

Note: For Windows XP, please continue to Step 3. For Windows 2000, please

skip to step 11.

English

4. Click Finish.

5. Connect the wireless adapter to an

available USB port on your

computer.

6. Click Install the software

automatically (Recommended)

and then click Next.

English

8. Select the appropriate country

domain and then click OK.

9. Click Yes.

10. Click Finish.

7. Click Continue Anyway.

English

11. Click Yes.

Windows 2000

12. Click Finish.

13. Connect the wireless adapter to

an available USB port on your

computer.

English

For detailed information regarding the TEW-424UB configuration and advanced

settings, please refer to the User's Guide included on the Utility & Driver

CD-ROM or TRENDnet's website at www.trendnet.com

Your installation is now complete.

14. Click Yes.

15. Select the appropriate country

domain and then click OK.

16. Click Yes.

1. On the bottom right-hand corner of

the screen, double-click on the

wireless client utility icon.

English

3. Wireless Configuration

2. Click Network, click the SSID that

matches your wireless access

point and then click Connect.

Wireless configuration is now complete.

For detailed information regarding the TEW-424UB configuration and advanced

settings, please refer to the User's Guide included on the Utility & Driver CD-

ROM or TRENDnet's website at www.trendnet.com

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

Q5:

A5:

I inserted the Utility & Driver CD-ROM into my computer's CD-ROM Drive and the installation

menu does not appear automatically. What should I do?

If the window does not appear automatically, click Start, click Run, and type D:\autorun where

"D" in "D:\autorun.exe" is the letter assigned to your CD-ROM Drive, and then press the ENTER

key on your keyboard.

I completed all the steps in the quick installation guide, but my Wireless USB Adapter is not

connecting to my access point. What should I do?

First, verify that the Network Name (SSID) matches your wireless router or access point's

Network Name (SSID). Second, check your TCP/IP properties to ensure that Obtain an IP address

automatically is selected. Third, open the Wireless Client Utility icon, click the Network tab and then

click Scan to check and see if there are any available wireless networks listed.

Windows is unable to recognize my hardware. What should I do?

Make sure your computer meets the minimum requirements as specified in Section 1 of this

quick installation guide. Also, you must complete the installation of the wireless configuration utility

(as described in Section 2) before connecting the Wireless USB Adapter to your computer. Lastly,

you may consider moving the Wireless USB Adapter to a different USB port of your computer.

I cannot open the wireless configuration utility. What should I do?

Access your device manager to make sure the adapter is installed properly. If you see a

networking device with a yellow question mark or exclamation point, you will need to reinstall the

device and/or the drivers. To access your device manager, right-click My Computer, click

Properties, under Hardware tab click Device Manager.

How do I install the drivers on Windows 98SE or ME?

Please refer to the User's Guide included on the Driver CD-ROM.

If you still encounter problems or have any questions regarding the TEW-424UB, please refer to the

User's Guide included on the Utility & Driver CD-ROM or contact Trendnet's Technical Support

Department.

Troubleshooting
