TRENDnet TU3-H2PIE Bedienungsanleitung

The 5Gbps USB 3.0 PCI Express Adapter, model TU3-H2PIE, adds two

super speed 5Gbps USB 3.0 ports to a tower computer.

Transfer content from USB 3.0 storage enclosures, flash drives, and

camcorders at 5Gbps speeds—10 times faster than USB 2.0.

Plug the adapter into any available PCI Express port on a Window's based

tower computer. A 4-pin power port connects to an internal power supply

and provides full power to all connected USB 3.0 devices. Backward

compatibility allows users to connect USB 2.0 devices to the USB 3.0

ports. Transfer large files in no time with two super speed 5Gbps USB 3.0

ports.

TU3-H2PIE (v1.0R)

2-Port USB 3.0 PCI Express Adapter

TU3-H2PIE

rev: 04.27.2010

Features

• 2 x USB 3.0 type A ports

• Compatible with desktop computer PCI Express card slots

• 4-pin power port connects to the tower computer's power supply to fully power connected USB devices

• Backwards compatible with USB 2.0 and USB 1.1 devices

• PCI Express Base Specification 2.0

• Electromechanical Specification Revision 2.0

• Bus Power Management Interface Specification Revision 1.2

• Supports all USB speeds: Low-speed (USB 1.0: 1.5Mbps), Full-speed (USB 1.1: 12Mbps, High-speed (USB 2.0: 480Mbps), and

Super-speed (USB 3.0: 5Gbps)

• Compatible with Windows 7, Vista, and XP

• Plug and play support

• 2-year limited warranty

network

accessories

SPECIFICATIONS

Interface

Ports

Supported OS

Data Rate

Power Consumption

• USB 3.0 • PCI Express Base Specification 2.0 • PCI Express Base Specification 2.0

• 2 x USB 3.0 Port

• Electromechanical Specification Revision 2.0

• 1 x 4-pin internal power port (cable not included)

• Bus Power Management Interface Specification Revision 1.2

• Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit)

• Super speed: 5Gbps (USB 3.0) • High speed: 480Mbps (USB 2.0) • Full speed: 12Mbps (USB 1.1) • Low speed: 1.5Mbps (USB 1.0)

• 900mA (max) per port

• 114 x 54 x12 mm (4.4 x 2.1 x 0.5 in.)

Hardware

SPECIFICATIONS

Humidity • 90% (Non-condensing)

Certifications

Dimensions (L x W x D)

Weight

Temperature

• CE, FCC

• 5°C ~ 40°C (41°F ~104°F)

• 45 g (1.6 oz.)

• Multi-Language Quick Installation Guide

CONTACT INFORMATION

RELATED PRODUCTS

PACKAGE CONTENTS

• TU3-H2PIE

• CD-ROM (Drivers)

TEG-ECTX

TU2-H5PI

Gigabit PCI Express Adapter

5-Port USB PCI Adapter

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

1-888-326-6061

www.trendnet.com

TU2-ETG USB to Gigabit Ethernet Adapter

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

TU3-H2PIE (v1.0R)

2-Port USB 3.0 PCI Express Adapter

2-Port USB 3.0 PCI

Express Adapter

(TU3-H2PIE)

2-Port USB 3.0 Express Card

(TU3-H2EC)

USB 3.0 Hard Drive Enclosure

(TU3-S35)

USB 3.0 Speed up to 5Gbps

NETWORKING SOLUTIONS
