TRENDnet TFC-110S20D3i Bedienungsanleitung

TFC-110S20D3i

rev: 11.21.2012

Intelligent 100Base-TX to 100Base-FX Dual

Wavelength Single Mode SC Fiber Converter

(20 km / 12.4 miles)

TFC-110S20D3i (v1.0R)

The TFC-110S20D3i intelligent ﬁ ber converter works with the

TFC-1600 chassis system or as a standalone unit. This converter is

a Dual Wavelength Single Mode SC-Type ﬁ ber converter that spans

distances up to 20 km (12.4 miles). This module must be used with the

TFC-110S20D5i module. Ports include 1 x 10/100Base-TX (RJ-45) port

and 1 x 100Base-FX (SC Simplex Type) port.

FEATURES

• Must use with TFC-110S20D5i

• Compliant with IEEE 802.3u 100Base-TX and 100Base-FX standards

• 1 x 10/100Base-TX RJ-45 port

• 1 x 100Base-FX single-mode bi-directional simplex-SC type ﬁ ber port

• Port level SNMP management support

• Monitor and conﬁ gure Ethernet or Fiber’s duplex mode, LLR, port on / off and receive link down information via management

module TFC-1600MM and chassis TFC-1600

• Dip switch controls: Fiber (Full / Half-Duplex), UTP (Auto negotiation / Manual), Speed (10 Mbps / 100 Mbps),

Copper (Full / Half-Duplex), LLR (Enable / Disable), and LLCF (Enabled / Disable)

• Link Loss Carry Forward (LLCF) support

• Link Loss Return (LLR) support

• Status LED indicators for Power and Link / Activity

• Removable metal enclosure

• Wall mountable

• Functions as a standalone converter or with the TFC-1600 ﬁ ber chassis

• 3-year limited warranty

PRODUCT OVERVIEW

• Must use with TFC-110S20D5i

• Port level SNMP management support

• SC-type dual-wavelength single-mode ﬁ ber port

• 10/100Base-TX RJ-45 port

• Spans distances up to 20 km (12.4 miles)

• Functions as a standalone converter or with the TFC-1600 ﬁ ber chassis

TFC-110S20D3i

rev: 11.21.2012

Intelligent 100Base-TX to 100Base-FX Dual Wavelength Single

Mode SC Fiber Converter (20 km / 12.4 miles)

TFC-110S20D3i (v1.0R)

SPECIFICATIONS

HARDWARE

Standard • IEEE 802.3 10Base-T

• IEEE 802.3u 100Base-TX/FX

Network Media • 100Base-TX: Cat. 5 EIA/TIA-568 100-ohm UPT/STP, up to 100 m

• 100Base-FX: Single-mode ﬁ ber optic cable 9/125 µm or 10/125 µm, up to 20 km

Protocol • CSMA / CD

Ports • 1 x 10/100Base-TX

• 1 x 100Base-FX (simplex SC-type)

Dip Switch • Fiber (full / half duplex)

• UTP (auto negotiation / manual)

• Speed (10 Mbps / 100 Mbps)

• Copper (full /half duplex)

• LLR (enable / disable)

• LLCF (enable / disable)

Transfer Rate • 100 Mbps (half duplex) / 200 Mbps (full duplex)

Diagnostic LEDs • Per Unit: power

• Per Port (TX): Link / Activity, FDX / HDX, Link Fail, Speed

• Per Port (FX): Link / Activity, FDX / HDX, Link Fail

Power Adapter • Input: 100~240 V 50/60 Hz, 0.2 A

• Output: 5 V DC, 1 A

Power Consumption • 2 watts (max.)

Dimensions • 120 x 88 x 25 mm (4.7 x 3.46 x 0.98 in.)

Weight • 354 g (12.5 oz)

Temperature • Operating : 0° ~ 40°C (32° ~ 104°F)

• Storage : -25° ~ 70°C (-13° ~ 158°F)

Humidity • Max 90% (non-condensing)

Certiﬁ cations • CE, FCC

MODEL NAME MEDIA WAVELENGTH OPTICAL OUTPUT POWER

(DBM)

OPTICAL INPUT POWER

(DBM)

POWER BUDGET DISTANCE

TFC-110S20D3i SMF

TX: 1310 nm

RX: 1550 nm

Min. Max. Min.

(Sensitivity) Max.

17 20 km

-14 -8 -31 0

TFC-110S20D3i

rev: 11.21.2012

Intelligent 100Base-TX to 100Base-FX Dual Wavelength Single

Mode SC Fiber Converter (20 km / 12.4 miles)

TFC-110S20D3i (v1.0R)

CONTACT INFORMATION

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web: www.trendnet.com

Email: [email protected]

1-888-326-6061

PACKAGE CONTENTS

TFC-110S20D3i

Multi-Language Quick Installation Guide

Power adapter (5 V DC, 1 A)

RELATED PRODUCTS

TFC-110S20D5i Intelligent 100Base-TX to 100Base-FX Dual

Wavelength Single Mode SC Fiber Converter

(20 km / 12.4 miles)

TFC-1600MM SNMP Management Module

TFC-1600 16-Bay Fiber Converter Chassis System

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time, without
