TRENDnet TFM-560X - DATA SHEETS Bedienungsanleitung

TFM-560X

Version 07.07.2006

Guia Rápido de Instalação Rápida Modem

Table of Contents

English ......................................................................................................

Troubleshooting .........................................................................................

1. Prepare for Installation ......................................................................

2. Product Detail ....................................................................................

3. Hardware Installation .........................................................................

4. Driver Installation ...............................................................................

5. Add A New Connection ......................................................................

Thank you for purchasing the TRENDnet TFM-560X 56K External Modem.

This guide will help you setup your 56K External Modem. Following the

installation instructions should be quick and easy. If you run into problems,

please refer to the Troubleshooting section. If you need further technical

support, please visit www.TRENDNET.com or call technical support by phone.

Verify Package Contents

Please make sure you have everything in the box:

1. Prepare for Installation

English QIG

English

Minimum System Requirements

a. Pentium 166Mhz or faster processor with at least 16MB of RAM

b. RS-232 COM port

c. Windows XP, 2000, ME, or 98SE

TFM-560X Quick Installation Guide

RJ-11 Telephone Cable

Driver CD-ROM

RS-232 Serial Cable Power Adapter (9VAC, 1A)

TRENDnet

TRENDware,USA

What's Next in Networking

TFM-560X

Version04.06.2005

56KExternal Modem Quick Installation Guide

Modemexterne 56K Guide d'installation rapide

Externes56K-Modem Kurzanleitung zur Installation

Guíade instalación rápida del módem externo de 56K

???? ??? ????? 56K ?????? ????? ?? ?? ????? ????? ????

2. Product Detail

TFM-560X has an On/Off Switch, a power adapter connector, a RS-232 port

that connects to your PC, a LINE port that connects to the Internet, and a

PHONE port that connects an analog telephone.

English

Power Adapter connector

On/Off Switch

COM RS-232 port that connects to your PC

PHONE port that connects to your analog telephone

LINE port that connects directly to the Internet

3. Hardware Installation

a. Plug the female end of the RS-232 cable into your PC's COM port. Plug the

male end of the RS-232 cable into the RS-232 port of the TFM-560X.

b. Plug one end of the telephone cord into the LINE port of the TFM-560X.

Plug the other end of telephone cord into a telephone wall jack.

c. Plug the power adapter connector to the TFM-560X's AC9V port. Plug the

power adapter to a power outlet or surge protector.

d. Turn on the TFM-560X.

e. (Optional) Plug one end of the telephone cord into the PHONE port of the

TFM-560X. Plug the other end of telephone cord into an analog telephone.

English

4. Driver Installation

Windows XP

After completing the modem hardware installation, the Found New Hardware

Wizard will appear. Please insert the CD-ROM driver into your CD-ROM.

a. Click Install the software automatically (Recommended). Click Next.

b. Select e:\drivers\ocms_xp.inf under Location and Click Next.

English

5English

c. Click Finish.

NOTE: TRENDnet's TFM-560X has been fully tested under all

supported Windows Operating Systems and has been approved for their

functionality. For Windows XP, you will see a message regarding “not

passed Windows Logo testing”. Click Continue Anyway.

6English

Windows 2000

After completing the modem hardware installation, the Found New Hardware

Wizard will appear. Please insert the CD-ROM driver into your CD-ROM.

a. Click Next.

b. Click Search for a suitable driver for my device (recommended). Click

Next.

7English

c. Click CD-ROM and click Next.

d. Click Next.

8English

NOTE: TRENDnet's TFM-560X has been fully tested under all

supported Windows Operating Systems and has been approved for their

functionality. For Windows 2000, you will see a message regarding “not

passed Windows Logo testing”. Click Yes.

e. Click Finish.
