TRENDnet TE100-P11 Bedienungsanleitung

TE100-P11

TEW-P11G

H/W: V1

Quick Installation Guide

Table of Contents

Version 12.12.2008

English ...................................................................................................... 1

1. Before You Start

2. How to Install .....................................................................................

3. Configure the Print Server .................................................................

.................................................................................

Troubleshooting ........................................................................................ 8

1. Before You Start

English

Package Contents

System Requirements

?Windows 98SE/Me/2000/XP/2003 Server/Vista

?Wired or Wireless Router

?An Available DHCP Server – routers usually have a built-in DHCP server

CD-ROM Drive

?Multi-Language

TE100-P11/TEW-P11G

Utility CD-ROM

Quick Installation

Guide

AC Power Adapter (5V DC, 2A)

English

Application

2-Port USB/Parallel Print Server

(TE100-P11)

Cable/DSL

Modem

Parallel

Printer

USB

Printer

4-Port Gigabit Firewall Router

(TWG-BRF114)

Internet

10/100Mbps

Workstation with

10/100Mbps PCI Adapter

(TE100-PCIWN)

Worstation with

10/100Mbps PCI Adapter

(TE100-PCIWA)

Cable/DSL Modem

Internet

USB

Printer

Parallel

Printer

Wireless 2-Port

USB/Parallel Print Server

(TEW-P11G)

Workstations with

Wireless N USB Adapter

(TEW-644UB) Wireless N Home Router

(TEW-652BRP)

Wireless g 54Mbps

2. How to Install

English

1. Connect a RJ-45 network cable

from the LAN port on your Router

to the LAN port of the Print Server.

4. Power ON printer.

3. Connect the AC Power Adapter to

the Print Server and then to a

power outlet.

Note: Please power off all printers before connecting them to the print server.

Then turn on each printer after you make your hardware connections.

2. Connect a Parallel or USB Printer

to the printer server.

English

1. Insert the Utility CD-ROM into

your computer's CD-ROM Drive.

2. Click Run autorun.exe (Windows

Vista only).

3. Configure the Print Server

Note: Disable any anti-virus and firewall programs before starting hardware

installation.

For Windows Users

4. Click Next.

3. Click Setup Wizard.

Note: If you have the TE100-P11, skip to step 11. If you have the TEW-P11G,

continue on step 8.

English

5. Select the print server and then

click Next.

6. If desired, change the Device

Name, Domain Name and add a

Comment (optional). Then click

Name.

7. Select the Obtain IP Address

automatically and then click Next.

8. Select the desired wireless

network and click Next.

English

10. If enabled, enter the encryption

key for your wireless network and

then click Next. This example

shows WPA2-PSK.

9. The correct wireless settings

should be automatically configured.

Then click Next.

11. Click Finish.

Print Server configuration is now complete.

English

For detailed information regarding adding printers for Windows

98SE/ME/2000/XP/2003 Server/Vista, please refer to the User's Guide on the

Utility CD-ROM or TRENDnet's website at www.trendnet.com

13. Disconnect the RJ-45 cable and

unplug the power. Then plug the

power back in (TEW-P11G only).

12. Click OK.

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet

Troubleshooting

Q1.

A1.

Q2.

A2.

Q3.

A3.

Q4.

A4.

The Setup Wizard is unable to see my printer server. What should I do?

First, double check your hardware connections; make sure that the print

server is powered ON and is properly connected. Second, click Refresh. Third,

disable any software firewall programs (e.g. ZoneAlarm). If your computer is

running Windows XP or Vista, disable the built in firewall program. Fourth, unplug

the power to the print server, wait 15 seconds, then plug the power back in.

How do I add a printer to my computer?

Please refer to the User's Guide on the CD-ROM for instructions on adding a

printer.

I configured my print server to automatically receive an IP Address from a

DHCP server but I can't log in to the browser configuration for the print server.

Open the Setup Wizard (See 3. Configure the Print Server) to locate your print

server's IP Address. Then type in the IP address into your browser.

After I successfully configured the TEW-P11G to match my wireless network

settings, I can not connect to the print server.

First, verify that the wireless settings match your wireless network settings.

Second, make sure to disconnect the Ethernet cable from the print server and

verify that the WIRELESS LED is lit.

If you still encounter problems or have any questions regarding the TE100-P11/TEW-

P11G, please refer to the User's Guide included on the Utility CD-ROM or contact

TRENDnet's Technical Support Department.
