TRENDnet TE100-S1616V Bedienungsanleitung

Preface

This manual describes how to install and use 16/24 port

Ethernet switch, TE100-S1616V/TE100-S2424V. It features

16/24 ports that auto negotiate the presence of 10/100Mbps

and full or half-duplex mode. An optional 100BASE-FX

multi-mode or single-mode module enables long-distance

connection. An optional BNC module enables backwards

compatibility.

To get the most out of this manual, you should have an

understanding of networking concepts such as bridging, IEEE

802.3 Ethernet and 100BASE-TX Fast Ethernet, and local area

networks (LAN).

For more information about these topics, please refer to the

Appendices.

In this manual, you will find:

Benefits of Ethernet switches

Features of TE100-S1616V/TE100-S2424V

LED functions illustration

Installation instructions

Configuration instructions for VLAN and port speed

Specifications

Ethernet technology, LAN, and VLAN tutorial information

2User’s Guide

Table of Contents

Preface...........................................................................1

Introduction ..................................................................3

Benefits of Switching...........................................................................3

TE100-S1616V/TE100-S2424V........................................................4

Product Features....................................................................................5

Packing List...........................................................................................7

Ports..................................................................................................10

LED Indicator.................................................................................13

Installation...................................................................18

Selecting a Site for the Switch..........................................................18

Connecting to Power..........................................................................20

Connecting to Your Network....................................20

Optional Module Installation............................................................23

Jumper Settings..............................................................................24

Switch Configuration.................................................26

Setting up Console Port Connection................................................27

VLAN...................................................................................................31

Port Setting...........................................................................................35

Auto-Negotiation............................................................................35

Flow-Control...................................................................................35

Trunking...............................................................................................41

Networking Examples.....................................................................42

User’s Guide 3

Specifications.............................................................46

Appendix A -Connector Pinouts.............................48

Appendix B -Introduction to LAN & Ethernet

Technologies..............................................................49

Appendix C –VLANs .................................................54

Introduction

Benefits of Switching

Ethernet switching technology has dramatically boosted the total

bandwidth of a network. It puts configuration flexibility and

bandwidth adaptability into the local workgroups where the

majority ofwork is generated.

It further eliminates congestion problems inherent to the

CSMA/CD protocol and improves predictable response time under

heavy network loads. Expensive routing equipment was used in the

past to reduce the congestion under heavy loads.

The new wave of object-oriented client and server applications

demands higher bandwidth and tighter integration of client

workstations with servers. The old shared-access (hub/repeater)

4User’s Guide

Ethernet technology provides neither enough bandwidth nor

predictable response time for this new wave of workgroup

computing.

Fast Ethernet switching not only satisfies both technical and

business requirements, but also preserves the user’s existing

investment in the huge 10 Base-T Ethernet installed Base.

This compatibility ensures a path for users to add, change, and

migrate to Fast Ethernet as demands emerge. It also provides a low

cost and flexible bandwidth solution directly to local workgroups

where the majority of work is generated, reducing the need for

expensive network equipment.

TE100-S1616V/TE100-S2424V

16/24-port 10/100BASE-TX Fast Ethernet Switch

TE100-S1616V/TE100-S2424V has 16/24 10/100Mbps ports with

an optional fiber-optic module, flexibly meeting fiber-optic needs.

The straight-forward design enables ease of operation while

providing superior performance.

Addressing the demand for fiber, we provide an optional multi-

mode or single-mode fiber module for TE100-

User’s Guide 5

S1616V/TE100S2424V as an optimum solution for long-distance

connectivity. The module supports one SC, ST, MT-RJ, or VF-45

port. A BNC connector is also available to address the backward

compatibility issue.

This switch represent the newest generation in Ethernet switching

technology by supporting both 10Mbps and 100Mbps speed and

half or full duplex transmission modes on the same port. By using

standard auto-negotiation, it provides a cost-effective way of

integrating legacy 10Mbps segments with 100Mbps Fast Ethernet

networks and an ideal solution for extending the distance between

two 100Mbps network segments.

TE100-S1616V/TE100-S2424V supports port-based Virtual Local

Area Networking (VLAN). This advanced feature gives the

network administrator a powerful, yet easy-to-use tool to reduce

unnecessary broadcast traffic, flexibly segment the network, and

enhance network security.

TE100-S1616V/TE100S2424V fully complies with IEEE802.3u,

100BASE-TX/FX, and IEEE802.3, 10BASE-T standards

Product Features

-16/24 ports with auto-negotiation 10/100Mbps

-Optional 1-port ST, SC, MT-RJ, VF-45, or BNC module.

6User’s Guide

-Plug-and-play

-Auto-negotiation for speed and duplex mode

-True non-blocking architecture

-Full wire speed forwarding

-Store-and-forward mechanism

-Back pressure and IEEE 802.3x compliant flow control

-Supports 2K MAC address

-Port based VLAN

-Programmable re-configuration for fixed speed and duplex modes

-One uplink port activated by the push of a button

-Front panel reset button

-Front panel status LEDs

-Standard 19" rack-mount size

User’s Guide 7

Packing List

When you unpack this product, you should find the items listed

below. Please inspect the contents, and report any apparent damage

or missing items immediately to your authorized reseller.

?? TE100-S1616V or TE100-S2424V

?? User’s Guide

?? AC power cord

?? Rack Mount Ears with screws

?? Serial Cable

8User’s Guide

Front Panel

The front panel of this switch has 16 or 24 ports, one slot for an

optional fiber or BNC module and an array of LED indicators to

provide you with instant feedback on the status of the switch.

Figure 1: Front panel of TE100-S2424V

Figure 2: Front panel of TE100-S1616V

User’s Guide 9

10 User’s Guide

Ports

TE100-S1616V is similar to TE100-S2424V except that TE100-

S1616V has 16 RJ-45 10/100 Ethernet ports while TE100-S2424V

has 24. TE100-S1616V/TE100-S2424V also has one slot for

optional module for fiber or BNC connection.

The auto-negotiation feature of TE100-S1616V/TE100-S2424V

allows communication between 10Base-T(Ethernet) and 100Base-

TX (Fast Ethernet) at full or half-duplex mode. If it is desirable to

operate at a fixed, rather than auto-negotiated media setting, please

refer to the Port Settings section on page 35.

The optional module of the switch provides an additional port for

copper BNC or fiber ST, SC, MT-RJ, or VF-45. The latter are

fiber-optic small-form-factor connectors that are smaller and easier

to use. The optional module port also allows the use of single-mode

fiber for distances up to 15 km. For information on module

installation, please refer to page 23.

The maximum range of a 100BASE-TX network connected to the

switch is 100 meters with Category 5 unshielded twisted-pair (UTP)

cable. A 10BASE-T network may range up to 100 meters with

Category 3, 4, or 5 UTP cable. As for the length of fiber link

between a switch and a Data Terminal Equipment, it is capable to

span at least 2 kilometers (1.24 Mile) using 62.5/125-micron multi-
