TRENDnet TEG-S081FMi Bedienungsanleitung

The 8-Port 100Base-FX Layer 2 Managed Switch provides

exceptional performance, ease of use and flexibility for expanding

network operations. Utilizing a robust 3.8Gbps backplane, the

switch can easily accommodate multiple networks at 2km or more

with an optional GBIC SX or LX module. Advanced management

features include SNMP, VLAN, IGMP, and Port Security.

TEG-S081FMi (1.0R)

8-Port 100Base-FX Layer 2 Managed Switch

with Mini GBIC Slot

TEG-S081FMi

rev:06.30.2010

FEATURES

gigabit

• 8 x 100Base-FX SC type Multi-Mode Fiber Port

• 1 x 1000Base GBIC Slot for optional GBIC module

• Supports switch Fabric up to 3.8GBps

• Layer 2 Management Switch with Full Software Support

• IGMP Snooping with Query Mode Support for Multi-Media Application

• Supports Broadcast Storm Filtering

• Supports Port Status Control (Status, Auto-Negotiation, Speed, Duplex and Flow Control)

• Supports Port Trunking with Flexible Load Distribution Control and Fail-Over Functions

• Supports Port-Based VLAN and IEEE 802.1Q Tag-Based VLAN

• Supports IP Multicast, Port Mirroring, Spanning Tree, SNMP and RMON

• Supports Port Security and IEEE 802.1p Class of Services

• Store-and-Forward Switching Architecture with Non-Blocking Wire-Speed Performance

• Configuration via RS-232 Console Port, Telnet, and Web Browser (HTTP)

• TFTP Firmware Upgrade via Browser

• Configuration Save and Restore Feature Support

• 19” (1U) Rack Mount Design (kit included)

• 3-Year Limited Warranty

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

SPECIFICATIONS

Software

TEG-S081FMi

Management • Web Management, RS-232 Console Management, Telnet

Trunk • IEEE 802.3ad Trunk with LACP. Max 4 Groups ( up to 4 Ports per group)

Class of Service • Supports Hi and Low Priority

QoS • Supports 8 Levels of Priority and Mapping to Hi/Low Priority Queue for Class of Service

VLAN • Up to 256 VLAN groups and up to 4094 VLAN ID

IP Multicast • IGMP Snooping up to 256 groups

Filter Database • Port Static MAC address lock, MAC filter and Port Security

Port Mirror • Up to 8 ports

Broadcast Control • None, 5%, 10%, 15%, 20%, 25%

• 2 Types of Query Mode: Enable/Disable or Auto Query

Spanning Tree • IEEE 802.1d Support

RFC Standard • RFC 1157 SNMP v1.0, RFC 1213 MIB II, Bridge MIB, RFC 1643 Ethernet Like, RFC

• 1493 Bridge MIB, RFC 1757 RMON1, RFC 1215 Trap

Interface

Dimensions

Cabling

Console Port

Protocol/Topology

Buffer Memory

Filtering Address Table

Weight

• IEEE 802.3u 100Base-FX; IEEE 802.3z Gigabit Fiber/IEEE 802.3ab 1000Base-T

• Up to 3.8Gbps

• 8 x 100Base-FX SC type Multi-Mode Fiber Port

• Operating: 0~45 C (32 ~ 113 F)

• FCC, CE

• RS-232, female 9-Pin Serial Port (M-M serial cable included)

• (CSMA/CD) / Star

• 2Mbits Data Buffer

• 440 x 160 x 44mm (17.3 x 6.3 x 1.7 inch) (W x H x D)

• 8K MAC Address Entries

• -40 ~ 70 C (-40 ~ 158 F)Storage:

• 2.2 Kg. (4.85lb.)

• 10% ~ 90% non-condensing

Bandwidth

Standards

Hardware

• IEEE 802.3x Flow Control; IEEE 802.1D Spanning Tree • IEEE 802.1q Tag-based VLAN; IEEE 802.1p Class of Service

• Link Aggregation; IEEE 802.1ad Port Trunk

• 1 x 1000Base mini GBIC slot for optional mini GBIC module (3.3V DC power)

Packet Forwarding and

Filtering Rate

• Multi-Mode: (50/125um, 62.5/125um), 2km max

• Gigabit: 1,488,000 packets per second per port

• 100M Ethernet: 148,800 packets per second per port

• Single-Mode: (8/125um, 10/125um)

• Power, Link/Activity, Full Duplex/Collision

LED Display

• Input: 100~240VAC, 50/60Hz Internal Power Supply

Power

• 17 watts

Power Consumption

Safety Emissions

Humidity

Temperature

8-Port 100Base-FX Layer 2 Managed Switch with Mini GBIC Slot

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

RELATED PRODUCTS

PACKAGE CONTENTS

TE100-S810Fi

TEG-MGBSX

TE100-S800i 8-Port 10/100Mbps Layer 2 Managed Switch

8-Port 10/100Mbps Layer 2 Managed Switch

with 100Base-FX Port

Multi-Mode Fiber Mini-GBIC Modules

• TEG-S081FMi

• Multi-language user's guide

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

NETWORKING SOLUTIONS

• Power Cord 1.2m (6ft)

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

• RS-232 Cable 1m (3.28ft)

16-Port 10/100/1000Mbps Gigabit

Web Smart Switch with Mini-GBIC Slots

(TEG-160WS)

8-Port 100base-FX SNMP Layer 2 Managed Switch

(TEG-S081FMi)

Multi-Mode Fiber

Mini-GBIC Modules

(TEG-MGBSX)

Workstations

with Gigabit Adapters

(TEG-PCBUSR)

Console Connection

(RS-232) Media Convertor

RS-232

Workstation

with Gigabit Adapter

(TEG-PCBUSR)

1000MbpsFiber 10/100Mbps

TEG-S081FMi

8-Port 100Base-FX Layer 2 Managed Switch with Mini GBIC Slot
