TEG-S40TXD

4-Port 10/100/1000Mbps

Gigabit Ethernet Switch

User’s Guide

FCC Warning

This equipment has been tested and found to comply with the

regulations for a Class A digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with this user’s guide, may

cause harmful interference to radio communications. Operation

of this equipment in a residential area is likely to cause harmful

interference, in which case the user will be required to correct

the interference at his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this

product may cause radio interference, in which case the user

may be required to take adequate measures.

VCCI Warning

This is a product of VCCI Class A Compliance.

UL Warning

a) Elevated Operating Ambient Temperature-If installed in a

closed or multi-unit rack assembly, the operating ambient

temperature of the rack environment may be greater than room

ambient. Therefore, consideration should be given to installing

the equipment in an environment compatible with the

manufacturer's maximum rated ambient temperature (Tmra).

b) Reduced Air Flow-Installation of the equipment in a rack

should be such that the amount of air flow required for safe

operation of the equipment is not compromised.

c) Mechanical Loading-Mounting of the equipment in the rack

should be such that a hazardous condition is not achieved due to

uneven mechanical loading.

d) Circuit Overloading-Consideration should be given to the

connection of the equipment to the supply circuit and the effect

that overloading of circuits might have on over current

protection and supply wiring. Appropriate consideration of

equipment nameplate ratings should be used when addressing

this concern.

e) Reliable Earthing-Reliable earthing of rack-mounted

equipment should be maintained. Particular attention should be

iii

given to supply connections other than direct connections to the

branch circuit (e.g., use of power strips).

P/N : 1907GSW604T5000

TABLE OF CONTENTS

ABOUT THIS GUIDE..................................................................1

TERMS.......................................................................................1

OVERVIEW OF THIS USER’S GUIDE...............................................1

INTRODUCTION........................................................................3

GIGABIT ETHERNET TECHNOLOGY.............................................3

SWITCHING TECHNOLOGY .........................................................4

FEATURES..................................................................................5

UNPACKING AND SETUP.........................................................8

UNPACKING...............................................................................8

SETUP ........................................................................................8

DESKTOP INSTALLATION............................................................8

RACK INSTALLATION (OPTIONAL)..............................................9

CONNECTING NETWORK CABLE...............................................10

AC POWER..............................................................................10

IDENTIFYING EXTERNAL COMPONENTS ............................13

FRONT PANEL..........................................................................13

REAR PANEL............................................................................14

LED INDICATORS.....................................................................14

TECHNICAL SPECIFICATIONS.............................................17

1

ABOUT THIS GUIDE

This user’s guide tells you how to install your 4-Port

10/100/1000Mbps Gigabit Ethernet Switch and how to connect

it to your Gigabit Ethernet network.

Terms

For simplicity, this documentation uses the terms “Switch”

(first letter upper case) to refer to this 4-Port 10/100/1000Mbps

Gigabit Ethernet Switch, and “switch” (first letter lower case) to

refer to all the Ethernet switches; including the 4-Port

10/100/1000Mbps Gigabit Ethernet Switch.

Overview of this User’s Guide

?? Introduction: Describes the Switch and its features.

?? Unpacking and Setup: Helps you get started with the

basic installation of the Switch.

?? Identifying External Components: Describes the front

panel, rear panel, and LED indicators of the Switch.

?? Technical Specifications: Lists all the technical

specifications of the Switch.
