TRENDnet TK-401R Bedienungsanleitung

TRENDnet's TK-401R 4-Port KVM Switch allows you to manage up

to 4 PCs with just one keyboard, monitor, and mouse. Switch

between multiple PCs with a simple press of a button! Eliminate the

hassle of cable swapping. Save money and space with the TK-

401R. This KVM Switch also comes with a rack-mount kit for

mounting on EIA-19” rack in the equipment room and computer lab.

Rich in features such as Hot-Plug, Auto-Scan, and Hot-Key

operations; TRENDnet TK-401R is the perfect choice for managing

multiple Pcs.

TK-401R

4-Port Rack Mount KVM Switch

TK-401R

rev:09.05.2006

• Support Microsoft Intellimouse, Microsoft Intellimouse Explorer, Logitech NetMouse, Optical Mouse, and other MS compatible

Mouse

• PS/2 Keyboard/Mouse emulation

• Support DOS, Windows 3.x/95/98/ME/NT/2000/XP, Netware, Unix, Linux, and more

• Very high video quality – up to 1920 x 1440 resolution and 200Mhz bandwidth

• No software required – easy PC selection via Push Buttons and Hot-Key Operation

• Hot-Plug feature – add or remove PC’s without powering off the KVM switch or other Pc’s

• Auto-Scan Mode for monitoring PCs, with configurable scan interval from 5~99 seconds

• Keyboard status restored when switching between Pcs

• LED Display for easy status monitoring

• Beeping sound for port switching confirmation

• EIA-19” rack-mountable (hardware included)

• 2-Year Warranty

FEATURES

BENEFITS

Integration Friendly:

Does not require driver/software for the installation and operation. Switching between PC’s with the Push

Buttons and Hot-Key operations.

Flexible:

Hot-Plug feature – add PC’s or remove connected PC’s without powering off the KVM Switch or the other

PC’s.

Cost Effective:

Manage multiple PC’s with single keyboard, monitor, and mouse. Save on equipment cost, utility, and space.

Performance:

Support very High Video Quality up to 1920 x 1440 with 200Mhz bandwidth. Keyboard status is saved for

each PC.

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

4-Port Rack Mount KVM Switch

TK-401R

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

3135 Kashiwa Street,Torrance, CA 90505 USA

Tel: 1-310-891-1100

Fax: 1-310-891-1111

Web:

Email: [email protected]

www.trendnet.com

RELATED PRODUCTS

TK-401R

NETWORKING SOLUTIONS

4-Port Rack Mount KVM Switch

TK-801R

TK-200

8-Port Rack Mount KVM Switch

2-Port KVM Switch Kit

TK-200K

TK-400

TK-400K

TK-800R

TK-C06

TK-C10

2-Port KVM Switch Kit

4-Port KVM Switch

4-Port KVM Switch Kit

8-Port Rack Mount KVM Switch

6 Feet KVM Cable (male-to-male)

10 Feet KVM Cable (male-to-male)

TK-401R

Keyboard

Monitor

Mouse

Computers/Servers

TK-8 R1

KVMw tc

S i h

NDwreS

R a U

ENe

R Dn

TK-4 R1

KVMw tc

S i h

NDwreS

R a U

ENe

R Dn

Auto-Scan Interval

Computer Port

Console Port

Keyboard State

Video Bandwidth

Power Adapter (Optional)

• Two LED indicators per port (PC Link green and PC Active red)

• 5 ~ 99 seconds

• External AC Power adapter, 12V DC, 1A (or 9V DC, 1A)

• Saved and restored

• 1 port: Keyboard and Mouse: PS/2 type mini Din 6-pin (female)

• VGA: HDDB 15-pin (female)

• Hot-Keys and Push Buttons

• 200MHz

• 4 ports: Keyboard and Mouse: PS/2 type mini Din 6-pin (female)

• VGA: HDDB 15-pin (female)

PC Selection

LED Segment

Hardware

SPECIFICATIONS

Dimensions

Weight

Temperature

Operating Humidity

Certifications

• 220 x 100 x 44.5 mm (8.7 x 4 x 1.77 inches)

• Approximately 1 Kg. (2.2 lbs)

• Operating: 0°~ 40°C (32°~ 104°F)

• Storage: -20°~ 60°C (-4°~ 140°F)

• 0%~80% (non-condensing)

• FCC, CE
