1.0 Introduction

TPE-80WS Web Smart PoE Switch is a high performance web-smart switch that provides up to 8

10/100/1000Mbps copper Ethernet ports, this device provides a great flexibility for nowadays

variety of network application but at lower cost. User doesn’t have to learn many sophisticated

management function which are usually shown in SNMP switch but just to learn some simple or

common control or setting function through either out-of-band RS232 port or Ethernet port,

however, some new, advanced and important function such as Tag-VLAN, Trunking, RSTP and

IGMP are also supported same as SNMP switch, this means, user doesn’t have to pay high cost

as tradition layer 2 SNMP switch does while he still can get advanced or common function to

meet requirement of general network application. This makes it very suitable for small or

medium size company to build up simple network at beginning phase with lower cost. Besides, a

optional long-ear accessory also makes it possible to operate in the rack mount environment.

Non-blocking and maximum wire speed performance are designed on all switched ports, it not

only supports auto-negotiation but also AUTO-MDIX function on all switched 8 10/100/1000M

RJ-45 Gigabit copper ports no matter running with half or full duplex mode, these function make

user easy to use and reduce the matching effort between straight and cross-over line issues.

TPE-80WS Web Smart PoE Switch supports both port-based and 802.1Q (tag-based) VLAN to

catch-up the application needed in incoming VLAN age. To increase bandwidth application, it

supports up to 4 trunk groups with maximum 8 ports on one Trunk, moreover, these trunk ports

are with fair-over function to provide redundant back-up when one or some of trunk ports

malfunction. Moreover, to reduced convergent time of STP protocol, Rapid STP (RSTP ) is

supported, to support multicast application IGMP is also supported. ,

Fully LED status display ease user’s installation, a reset button is also provided to make user

easy to go back to default setting.

1.1 Main Features

This switch provides the following main features:

Non-blocking, full-line speed, store-and-forward

Support jumbo frame, Max. packet length 9600 bytes

Auto-Negotiation and Auto-MDIX on all 10/100/1000M copper ports

Up to 8 10/100/1000 RJ-45 copper ports

144K byte packet buffer, 8K MAC entries

Support port-based VLAN and tag-based (802.1Q) VLAN

Support RSTP, IGMP, DHCP

Support “relocate port number” to “ http operation “

Port trunk with fail-over capability

Support flow control for both full/half duplex operations

Support Multicast storm, Broadcast Storm control as well as Flooding Control

Support port mirroring

LED display for each port to show link and activity status

Desktop and optional Rack mountable kit

Reset to default “ push button “ and field code upgradeable

1.2 Start to Manage This Switch

Either way user may start to manage this switch, web mode through Ethernet port or terminal

mode through RS232 port.

1,2,1 Web mode default setting are:

Default IPAddress: 192.168.223.100

Default IP mask: 255.255.255.0

Default gateway: 192.168.223.254

Default Password: admin

1.2.2 Terminal mode default setting are: baud rate: 115,200, attribute: 8, None, 1, None

Terminal mode operation: (password: admin)

Once terminal is connected, the basic operation rule are shown below

Press “ ? “ to find root operation page, then choose command by typing little alphabets

After enter command page, Press “ ? “ to find command parameters and format,

and type “ command ? “ to get explanation.

Type “ up “ or “ / “ to go back to previous page

2.0 Web management

After login is successfully validated, the switch’s home page will show up. The left part on the

page provides the function menus, while the right part provides the individual configuration

value or system parameters value. Functions are divided into three categories, they are

Configuration, Monitoring and Maintenance; all functions are shown briefly below

Configuration

System – system values, such as H/W, F/W version, IP, IP mask, MAC address…etc

Ports – port status and configure port parameters

Port-based VLAN – to setup the port-based VLAN

Tag-based VLAN – to configure the tag-based VLAN

Port Trunking – to build up the trunk function

Port Mirroring – to setup the port mirroring function

Quality of Service – to configure the Quality of Service function

Storm Control – to set all kinds of storm limit

LACP – to set LACP parameter

RSTP – to set RSTP parameter

IGMP – to set IGMP parameter

802.1X – to set 802.1X parameter

Monitoring:

Port Statistics – to statistic traffic on each ports

Detailed Port Statistics – to statistic more detailed traffic on each ports

LACP status – to show LACP status

RSTP status – to show RSTP status

IGMP status – to show IGMP status

Reset – to reboot the switch with/without writing default configurations

Ping – provide ping function and ping result

Maintenance

Warm Reboot – to restart system

Factory Default – to get parameter value back to factory default

Firm Upgrade – to upgrade code

Config File – to backup configuration data

Logout – to logout

2.1 Configurations

2.1.1.1 System information

The system diagram shows every common system information, they are H/W, F/W version,

MAC address, IP address, subnet mask, IP gateway, default VLAN value of management port,

name, password, timeout value, and SNMP communities…etc. Once user finish the setting, he

must press the “ Apply “ button to execute all his setting, and whenever he needs, he may press

the “ Refresh “ button to get updated status of system information.

System Configuration

Model Name 8G_PoE_Smart

MAC Address 00-0a-17-02-14-ec

F/W Version 2.0

H/W Version 1.0

DHCP Enabled

IP Address 192.168.223.110

Subnet Mask 255.255.255.0

Gateway 0.0.0.0

HTTP Listening Port Number 80 (1024 - 65535)

Tag VLAN Management Group 1

Name

Password

Inactivity Timeout (secs) 0

SNMP enabled

SNMP Trap destination 0.0.0.0

SNMP Read Community

ublic

SNMP Write Community

rivate

SNMP Trap Community

ublic

Refresh

2.1.1.2 DHCP

The default DHCP is off, so Default IP or user defined IP is used when this machine is

turning-ON, but if this switch needs an IP assigned from DHCP server, user may click the square

field and then press “ Apply “ to get an IP which will be assigned by DCHP server “. User must

be aware that if he enable DHCP from web page, and if the DHCP server is working, then after

enable DHCP, he will lose contact of web page, because the IP address has been changed.

2.1.1.3 relocate HTTP port number

The default port number of HTTP command is 80, but unauthorized user may intrude this

switch if he knows the IP of this switch, network manager may relocate this port number to other

value, from 1024 to 65535, the same idea as above, once network manager change the value of

HTTP’s port number, he will lost contact and he must regain web page by command modified as

below:

http://192.168.223.100:port_value

2.1.1.4 Tag VLAN management group ( CPU port )

At first time you turn on this device, all ports belong to default VLAN ID group (VID=1), so

they can communicate to each other, and hence any port can be used as web management port to

talk with CPU port inside, but, for example, assume user uses port 1 as web management port,

then user create VLAN ID=10 on port 7,8 and create another VLAN ID = 20 on port 5,6, now 3

VLAN groups will be shown on VALN group table after he press “ Apply “ button. If VLAN 10

and VLAN ID 20 must be isolated, then user must delete member port 5,6,7,8 in default VLAN

group( VID = 1 ). Be aware that CPU port is still remain on VID=1 group now, user can only

perform web management through one of 4 ports, that is port 1,2,3,4, but if user want to perform

web management from other port in existing different VLAN group, for example port 8 in VID

=10, then at this moment, he must go to system configuration page, and select Tag VLAN

Management Group to 10, then, press “ Apply “ command, then move RJ-45 ( web

management port ) from port 1 to port 8, then user can perform web management from new

RJ-45 port again. But if user forget what group that CPU belongs to, there are two ways to solve

this condition below.

(1) Through console port, change VLAN ID of CPU port if he gets password, or

(2) Press “Reset”button few seconds, let system return to default settings, that is,

---- >> IP address=192.168.223.100; … VID=1, all settings return to factory default

2.1.2 Ports

Port status page always shows current port status of all 8 ports. User can set link mode, enable or

disable flow control and jumbo frame, however, be noticed that the jumbo frame is global setting,

it can’t be set on individual port but on all ports at a time.A default diagram is shown below,

Port Configuration

Port Link Status Link Mode Flow Control

1 100FDX Auto Speed

2 Down Auto Speed

3 Down Auto Speed

4 Down Auto Speed

5 Down Auto Speed

6 Down Auto Speed

7 Down Auto Speed

8 Down Auto Speed

Enable Jumbo Frames

Refresh

Choose and click the ports you want to set, for example, choose port 1, and set port 1 Flow

Control enable, then press “Apply”, after execution, diagram will shown below

Port Configuration

Port Link Status Link Mode Flow Control

1 100FDX Auto Speed

2 Down Auto Speed

3 Down Auto Speed

4 Down Auto Speed

5 Down Auto Speed

6 Down Auto Speed

7 Down Auto Speed

8 Down Auto Speed

2.1.3 Port-based VLAN

Port-based VLAN is a kind of VLAN which is a group of ports marked as a kind by group ID,

different VLAN ( different ID ) can’t communicate to each other. Before the setting, user must

be aware of that there is a default Port-based VLAN, his group ID is 1, so, if user wants to set

another new port-based VLAN, better set another group ID rather than 1. After press “ Apply

“ button, the screen will show a new port-based VLAN if he add a new group or screen will

delete a port-based VLAN if he delete a group. The important thing is that port-based VLAN

is valid only within same device, it will never be valid cross the devices. A default diagram is

shown below.

Port-based VLAN (User Group) Configuration

Port-based VLAN Group (User Group) Table

Member Port

No. Group ID 1 2 3 4 5 6 7 8

Add/Edit a VLAN (User) Group

Member Port

Group ID 1 2 3 4 5 6 7 8

RefreshDelete A

Choose and click the ports you want to group, for example, choose port 1, port 2 and set their

group ID 2, then press “Apply”, after execution, diagram will shown below

Andere Handbücher für TPE-80WS - Web Smart PoE Switch

Inhaltsverzeichnis

Andere TRENDnet Schalten Handbücher

TRENDnet

TRENDnet TK-222DVK Bedienungsanleitung

TRENDnet

TRENDnet TEG-2248WS - Gigabit Web Smart Switch Bedienungsanleitung

TRENDnet

TRENDnet TK-802R Bedienungsanleitung

TRENDnet

TRENDnet TEG-S811Fi Bedienungsanleitung

TRENDnet

TRENDnet TEG-224WS - DATA SHEETS Bedienungsanleitung

TRENDnet

TRENDnet TU2-700 - DATA SHEETS Bedienungsanleitung

TRENDnet

TRENDnet TEG-30284 Bedienungsanleitung

TRENDnet

TRENDnet THA-103AC Bedienungsanleitung

TRENDnet

TRENDnet TK-1603R Bedienungsanleitung

TRENDnet

TRENDnet TE100-S24V Bedienungsanleitung

TRENDnet

TRENDnet TL2-PG284 Bedienungsanleitung

TRENDnet

TRENDnet TE100-S80g Bedienungsanleitung

TRENDnet

TRENDnet TEG-S224 - DATA SHEETS Bedienungsanleitung

TRENDnet

TRENDnet TEG-S8 - Gigabit Switch Bedienungsanleitung

TRENDnet

TRENDnet TEG-S2600I - 10/100Mbps Switch With Mini-GBIC... Bedienungsanleitung

TRENDnet

TRENDnet TE100-S24plus Bedienungsanleitung

TRENDnet

TRENDnet TEG-S80g - Switch Bedienungsanleitung

TRENDnet

TRENDnet TE100-S55Eplus - Switch Bedienungsanleitung

TRENDnet

TRENDnet TEG-S224M Bedienungsanleitung

TRENDnet

TRENDnet TEG-2248WS - Gigabit Web Smart Switch Bedienungsanleitung

TRENDnet

TRENDnet TE100-S810Fi - Switch Bedienungsanleitung

TRENDnet

TRENDnet TPE-S44 - Switch Bedienungsanleitung

TRENDnet

TRENDnet TK-205i Bedienungsanleitung

TRENDnet

TRENDnet TEG-S50G Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
