TRENDnet TPE-S44 - Switch Installations- und Betriebshandbuch
8-Port 10/100Mbps PoE Switch
TPE-S44
1.11
ŸGuide d'installation rapide (1)
ŸTechnical Specifications (4)
ŸTroubleshooting (5)
1
Configuration du système
Contenu de l'emballage
Si tout le contenu ci-dessus sont manquantes, s'il vous plaît contactez votre
revendeur.
1. Avant de commencer
ŸUn ordinateur avec un adaptateur réseau correctement installé
Ÿ
Ÿ
Ÿ
Ÿnon fourni)
ŸCâble réseau RJ-45 Cat. 5, Cat. 5e ou Cat. 6
La surface sous le commutateur doit pouvoir résister à un poids minimum
de 430g
ŸLa prise secteur doit être située à un maximum de 1,82 mètres de
l'appareil
Inspectez visuellement la prise d'alimentation et assurez-vous qu'elle est
correctement connectée à l'adaptateur secteur
Vérifiez la présence d'une source de ventilation adéquate autour du
commutateur pour une dissipation efficace de la chaleur
ŸNe placez pas d'objets lourds sur le commutateur.
ŸPériphérique alimenté par IEEE 802.3af
TPE-112GS (
ŸTPE-S44
Cordon d'alimentation
48V DC, 800mA)
ŸGuide d'installation rapide
Ÿ
ŸAdaptateur secteur (
Remarque: Le TPE-S44 ne supporte que les péripériques alimentés qui
respectent la norme IEEE 802.3af
2. LEDs
2
Couleur
Rouge
Fixe
Clignotant
Clignotant
Séquence Définition
PoE Max
System
Power
PoE Status
(Ports 1 à 4)
Link/Act
(Ports 1 à 8)
100Mbps
(Ports 1 à 8)
Vert
Eteint
Eteint
Eteint
Vert
Vert
Vert
Vert
Eteint
Fixe
Fixe
Fixe
L'appareil est hors.
Fixe
Eteint
L'appareil est sur le.
Fixe Si le Switch détecte qu'il y a 7,5W
(ou moins) decourant disponible, ce
voyant s'allumera. Ceci indique une
surtension.
Si le voyant est rouge, le port n'a pas
réussi à fournir l'alimentation.
Activité depuis cette liaison.
LAN port de données de transmission /
réception ou de 10/20Mbps
100/200Mbps (Half / Full Duplex).
Si le Switch detecte qu'il y a plus de
7,5W de courant disponible, ce voyant
ne s'allumera pas.
Si aucun périphérique alimenté n'est
branché, le voyant ne s'allume pas.
Port est débranché / Non Ethernet Link.
Rien n'est détecté sur le port.
Lorsque le Switch est relié à un
périphérique PoE et que le port fournit
correctement l'alimentation, le voyant
est vert.
Le port est relié à une activité
Ethernet / Fast Ethernet dispositif de.
Port LAN connecté à 10/20 Mbps ou
100/200Mbps (Half / Full Duplex).
Voyants
lumineux
3. Installation du matériel
Remarque : La tension maximale disponible est de 15,4 watts par port et de 30
Watts au total. Si une surcharge se produit, le Switch donnera la priorité à la
distribution de courant par port (du plus bas au plus haut). Donc, le port 1
recevra la priorité la plus importante et le port 4, la priorité la plus faible. La
fonction PoE des ports avec la priorité la plus faible sera désactivéejusqu'à ce
qu'au moins 7,5 Watts soient disponibles.
1. Branchez le cordon d'alimentation
sur l' adaptateur secteur. Branchez
l'adaptateur secteur au TPE-S44 et
à une prise de courant.
2. Branchez un câble réseau RJ-45
entre l'ordinateur et un port
Ethernet disponible sur le TPE-S44.
3
3. Branchez un câble RJ-45 cable
entre un port PoE (1 à 4) du
TPE-S44 et le port LAN du
périphérique PoE
(p. ex. le TV-IP322P)
4. Vérifiez que les voyants suivants
du panneau sont allumés: System
Power, PoE Status et Link/ACT.
Technical Specifications
Standards ŸIEEE 802.3 10Base-T
ŸIEEE 802.3u 100Base-TX
ŸIEEE 802.3af Power over Ethernet
Network Media Ÿ10Mbps: Cat 3,4,5 Unshielded Cable
Ÿ100Mbps Cat 5,5e,6 Unshielded Cable
Data Transfer Rate ŸEthernet: 10/20Mbps (half/full-duplex)
ŸFast Ethernet: 100/200Mbps (half/full-duplex)
Power 48V DC 800mA External Power Adapter
Hardware
Power Consumption Ÿ6.3 Watts max. (no Power Device (PD) connected)
Ÿ36.3 Watts max. with 30w PoE Device connected
Protocol/Topology CSMA/CD, Star
Ports
RAM Buffer/Filtering
Diagnostic LEDs
96 Kbytes/ 1K entry per device
Ÿ4 x 10/100Mbps Auto-MDIX POE Ports (1~4)
Ÿ4 x 10/100Mbps Auto-MDIX Fast Ethernet Ports (5~8)
ŸPer Unit: Power, Power MAX
ŸPer Port: Link/Activity, 100M
ŸPoE: PoE Status, Link/Activity, 100M
Dimension 171 x 98 x 29mm (6.7 x 3.7 x 1.1 in.)
Weight
ŸOperating: 0° ~ 40° C (32° ~ 104° F)
ŸStorage: -10° ~ 70° C (14° ~ 158° F)
Humidity
Temperature
10%-90% (non-condensing)
Certifications FCC, CE
430g (13.8 oz)
PoE
Power over Ethernet ŸPower budget: 30 watts (max)
ŸUp to 15.4 watts per Port
ŸPD classification Identify
ŸPoE Over Current Portection
ŸPoE Circuit Sorting Protection PoE Power on RJ-45
pin 3,6 Power+ and pin 1,2 for Power-
4
Troubleshooting
1. After connecting the Switch to a power outlet, the LEDs do not turn on.
1. Check the connection of the external power adapter to the TPE-S44
and the power outlet
2. Check that the power outlet is receiving power.
2. After I connect my PCs to the Switch, I am unable to share files.
1. Check the LEDs on the Switch. Make sure the Link/ACT LED is on.
2. Check the network cable. The minimum length of the cable is 1.5
meters and the maximum length of the cable is 100 meters.
3. Disable any software firewall program.
4. Verify that you have file sharing enabled. Please contact your Operating
System support for more information.
3. After I connect my PCs to the Switch, I can only get onto the Internet
from one computer.
The Switch was not designed to share Internet between multiple computers.
You need to get an Internet router such as the TW100-S4W1CA.
4. My 802.3af Powered device does not power on when I plug the device
into the Switch. What should I do?
1. Verify that the PoE device supports IEEE 802.3af protocol.
2. Power cycle the PoE switch. Unplug power to the Switch, wait 15
seconds, then plug the power back in.
3. Plug the device into a different port on the PoE switch.
4. Try using another RJ-45 network cable.
5. A power overload may have an occurred. Connect your 802.3af
Powered Device into port 1 and/or disconnect all other 802.3af
Powered Device.
5. Where is the uplink port located on the Switch?
Since all the ports on the Switch are Auto-MDIX, any of the ports can
be used as an uplink port.
If you still encounter problems or have any questions regarding the TPE-S44
please contact Trendnet's Technical Support Department.
5
TRENDnet warrants its products against defects in material and workmanship, under
normal use and service, for the following lengths of time from the date of purchase.
TPE-S44
If a product does not operate as warranted during the applicable warranty period,
TRENDnet shall reserve the right, at its expense, to repair or replace the defective
product or part and deliver an equivalent product or part to the customer. The
repair/replacement unit's warranty continues from the original date of purchase. All
products that are replaced become the property of TRENDnet. Replacement products
may be new or reconditioned. TRENDnet does not issue refunds or credit. Please
contact the point-of-purchase for their return policies.
TRENDnet shall not be responsible for any software, firmware, information, or memory
data of customer contained in, stored on, or integrated with any products returned to
TRENDnet pursuant to any warranty.
There are no user serviceable parts inside the product. Do not remove or attempt to
service the product by any unauthorized service center. This warranty is voided if (i) the
product has been modified or repaired by any unauthorized service center, (ii) the product
was subject to accident, abuse, or improper use (iii) the product was subject to conditions
more severe than those specified in the manual.
Warranty service may be obtained by contacting TRENDnet within the applicable
warranty period and providing a copy of the dated proof of the purchase. Upon proper
submission of required documentation a Return Material Authorization (RMA) number
will be issued. An RMA number is required in order to initiate warranty service support for
all TRENDnet products. Products that are sent to TRENDnet for RMA service must have
the RMA number marked on the outside of return packages and sent to TRENDnet
prepaid, insured and packaged appropriately for safe shipment. Customers shipping
from outside of the USA and Canada are responsible for return shipping fees. Customers
shipping from outside of the USA are responsible for custom charges, including but not
limited to, duty, tax, and other fees.
- 3 Year Limited Warranty
AC/DC Power Adapter, Cooling Fan and Power Supply carry 1 year warranty
WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE
AS WARRANTED ABOVE, THE CUSTOMER'S SOLE REMEDY SHALL BE, AT
TRENDNET'S OPTION, REPAIR OR REPLACE. THE FOREGOING WARRANTIES
Limited Warranty
AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW,
STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. TRENDNET NEITHER ASSUMES
NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER
LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR
USE OF TRENDNET'S PRODUCTS.
TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND
EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES
NOT EXIST OR WAS CAUSED BY CUSTOMER'S OR ANY THIRD PERSON'S
MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED
ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE RANGE
OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER
HAZARD.
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET
ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER
BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL,
CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND,
OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE,
PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH
DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND
OF THE PURCHASE PRICE PAID, AT TRENDNET'S OPTION. THIS DISCLAIMER OF
LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED
HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
Governing Law: This Limited Warranty shall be governed by the laws of the state of
California.
Some TRENDnet products include software code written by third party developers.
These codes are subject to the GNU General Public License ("GPL") or GNU Lesser
General Public License ("LGPL").
Go to http://www.trendnet.com/gpl or http://www.trendnet.com Download section and
look for the desired TRENDnet product to access to the GPL Code or LGPL Code. These
codes are distributed WITHOUT WARRANTY and are subject to the copyrights of the
developers. TRENDnet does not provide technical support for these codes. Please go to
http://www.gnu.org/licenses/gpl.txt or http://www.gnu.org/licenses/lgpl.txt for specific
terms of each license.
TRENDnet
20675 Manhattan Place
Torrance, CA 90501. USA
Copyright ©2011. All Rights Reserved. TRENDnet.
Andere Handbücher für TPE-S44 - Switch
5
Inhaltsverzeichnis
Sprachen:
Andere TRENDnet Schalten Handbücher
TRENDnet
TRENDnet TFU-430 Bedienungsanleitung
TRENDnet
TRENDnet TO-PG541 Bedienungsanleitung
TRENDnet
TRENDnet PoE Web Smart Switch Series Bedienungsanleitung
TRENDnet
TRENDnet TE100-S50g Bedienungsanleitung
TRENDnet
TRENDnet TK-407K - KVM Switch - USB Bedienungsanleitung
TRENDnet
TRENDnet TEG-S160TX - Gigabit Switch With 31 Gbps Switching... Bedienungsanleitung
TRENDnet
TRENDnet TEG-448WS - Switch Bedienungsanleitung
TRENDnet
TRENDnet TK-205i Bedienungsanleitung
TRENDnet
TRENDnet TU2-NU4 Bedienungsanleitung
TRENDnet
TRENDnet TEG-240WS Bedienungsanleitung
TRENDnet
TRENDnet TK-207K - KVM Switch - USB Bedienungsanleitung
TRENDnet
TRENDnet TK-802R Bedienungsanleitung
TRENDnet
TRENDnet TE100-S32plus Bedienungsanleitung
TRENDnet
TRENDnet TEG-S224TXA - 26PORT Gigabit Copper Switch 24-10/100... Bedienungsanleitung
TRENDnet
TRENDnet TE100-H8E Bedienungsanleitung
TRENDnet
TRENDnet TEG-S5g - Gigabit GREENnet Switch Bedienungsanleitung
TRENDnet
TRENDnet TU2-NU4 Bedienungsanleitung
TRENDnet
TRENDnet TK-217i Bedienungsanleitung
TRENDnet
TRENDnet TEG-448WS - Switch Bedienungsanleitung
TRENDnet
TRENDnet TPE-1016L Bedienungsanleitung
